TOYOTA SIENNA 2007 Service Repair Manual SEAT – FRONT POWER SEAT CONTROL SYSTEMSE–5 SE B168177E01

Page 298 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SE–6SEAT – FRONT POWER SEAT CONTROL SYSTEM SE B168178E01

Page 299 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SEAT – FRONT POWER SEAT CONTROL SYSTEMSE–7 SE 1. SIGNAL COMMUNICATION TABLE Driver Side Power Seat (with Memory) B168179E01 Transmitting ECU (Transmitter)Receiving ECU Signals Communication meth

Page 300 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SE–8SEAT – FRONT POWER SEAT CONTROL SYSTEM SE Main body ECUPower seat control switch and ECU• Driver side door courtesy light switch signal • Key unlock warning switch signal • Ignition

Page 301 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SE–98SEAT – REAR NO. 2 SEAT ASSEMBLY (for Power Seat Type LH Side) SE REMOVAL 1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL 2. REMOVE REAR NO. 2 SEAT LEG SIDE GARNISH SUB-ASSEMBLY (a) Dis

Page 302 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SEAT – REAR NO. 2 SEAT ASSEMBLY (for Power Seat Type LH Side)SE–99 SE (c) Pull the lever under the No. 2 seat cushion sub- assembly and remove the rear No. 2 seat assembly. DISASSEMBLY 1. REMOVE

Page 303 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SE–100SEAT – REAR NO. 2 SEAT ASSEMBLY (for Power Seat Type LH Side) SE 5. REMOVE REAR NO. 2 SEAT HEADREST SUPPORT ASSEMBLY LH (a) Remove the 2 pads. (b) Remove the 2 clips. (c) Remove the 23 ho

Page 304 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SEAT – REAR NO. 2 SEAT ASSEMBLY (for Power Seat Type LH Side)SE–101 SE 7. REMOVE NO. 2 SEATBACK COVER SUB-ASSEMBLY WITH PAD (a) Disconnect the connectors. (b) Disengage the 3 clamps and remove
