2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–15
ES
BASIC INSPECTION
When a malfunction is not confirmed by the DTC check,
troubleshooting should be carried out in all circuits
considered to be possible causes of the problem. In many
cases, by carrying out the basic engine check shown in the
following flowchart, the location of the problem can be found
quickly and efficiently. Therefore, using this check is essential
when engine troubleshooting.
NOTICE:
Carry out this check with the engine stopped and ignition
switch off.
Result
NG
OK
NG
OK
NG
OK
(a) Visually check that the air filter is not excessively
contaminated with dirt or oil.
NG
OK
(a) Check the idling speed (See page EM-2).
1CHECK BATTERY VOLTAGE
Result Proceed to
11 V or more OK
Below 11 V NG
CHARGE OR REPLACE BATTERY
2CHECK WHETHER ENGINE CRANKS
PROCEED TO PROBLEM SYMPTOMS
TA B L E
3CHECK WHETHER ENGINE STARTS
GO TO STEP 6
4CHECK AIR FILTER
REPLACE AIR FILTER
5CHECK IDLING SPEED
Page 778 of 3000
ES–162GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
NG
OK
(a) Check the fuel pressure (See page FU-7).
NG
OK
(a) Check for sparks (See page ES-217).
NG
OKTROUBLESHOOT IDLING SPEED AND
PROCEED TO NEXT STEP
6CHECK FUEL PRESSURE
TROUBLESHOOT FUEL PRESSURE AND
PROCEED TO NEXT STEP
7CHECK FOR SPARKS
TROUBLESHOOT SPARK AND PROCEED
TO NEXT STEP
PROCEED TO PROBLEM SYMPTOMS TABLE
Page 779 of 3000
ES–4862GR-FE ENGINE CONTROL SYSTEM – CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY
ES
ON-VEHICLE INSPECTION
1. INSPECT CAMSHAFT TIMING CONTROL VALVE
ASSEMBLY
(a) Connect the intelligent tester to the DLC3.
(b) Turn the ignition switch to the ON position.
(c) Start the engine and warm it up.
(d) Select the intelligent tester from the ACTIVE TEST
menu.
(e) Check the engine speed when the OCV (camshaft
timing oil control valve) is operated by the intelligent
tester.
OK
E144486E01
Condition Specified Condition
VVT system is OFF (OCV is OFF) Normal engine speed
VVT system is ON (OCV is ON) Rough idle or engine stalled
Page 780 of 3000

2GR-FE ENGINE CONTROL SYSTEM – CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLYES–487
ES
REMOVAL
1. REMOVE WINDSHIELD WIPER MOTOR ASSEMBLY
HINT:
(See page WW-4)
2. REMOVE FRONT OUTER COWL TOP PANEL SUB-
ASSEMBLY (See page EM-27)
3. DRAIN ENGINE COOLANT (See page CO-6)
4. REMOVE V-BANK COVER SUB-ASSEMBLY (See
page EM-28)
5. REMOVE NO. 2 AIR CLEANER INLET (See page EM-
28)
6. REMOVE NO. 1 AIR CLEANER INLET (See page EM-
28)
7. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See
page ES-493)
8. REMOVE AIR CLEANER CASE SUB-ASSEMBLY (See
page EM-28)
9. REMOVE INTAKE AIR SURGE TANK ASSEMBLY
(See page ES-521)
10. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY (for Bank 1 Exhaust Side)
(a) Disconnect the camshaft timing oil control valve
assembly connector.
(b) Remove the bolt and camshaft timing oil control
valve assembly.
(c) Remove the O-ring from the camshaft timing oil
control valve.
11. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY (for Bank 1 Intake Side)
(a) Disconnect the camshaft timing oil control valve
assembly connector.
(b) Remove the bolt and camshaft timing oil control
valve assembly.
(c) Remove the O-ring from the camshaft timing oil
control valve.
A135698
A135697
Page 781 of 3000
ES–4882GR-FE ENGINE CONTROL SYSTEM – CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY
ES
12. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY (for Bank 2 Exhaust Side)
(a) Disconnect the camshaft timing oil control valve
assembly connector.
(b) Remove the bolt and camshaft timing oil control
valve assembly.
(c) Remove the O-ring from the camshaft timing oil
control valve.
13. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY (for Bank 2 Intake Side)
(a) Disconnect the camshaft timing oil control valve
assembly connector.
(b) Remove the bolt and camshaft timing oil control
valve assembly.
(c) Remove the O-ring from the camshaft timing oil
control valve.
A135695
A135696
Page 782 of 3000
ED–232ENGINE HOOD / DOOR – BACK DOOR SUPPORT
ED
INSTALLATION
1. REMOVE BACK DOOR STAY SUB-ASSEMBLY LH
(a) Install the stay with the bolts to the door panel.
Torque: 19.5 N*m (200 kgf*cm, 14 ft.*lbf) for
door side
(b) Install the stay with the 2 bolts to the body panel.
Torque: 17.5 N*m (180 kgf*cm, 13 ft.*lbf) for
body side
Page 783 of 3000
ENGINE HOOD / DOOR – BACK DOOR SUPPORTED–233
ED
DISPOSAL
HINT:
On the RH side, use the same procedures as on the LH side.
1. DISPOSE OF BACK DOOR STAY SUB-ASSEMBLY LH
(a) Horizontally fix the stay in a vise with the piston-rod
pulled out.
(b) Wearing safety glasses, gradually cut a part
between A and B as shown in the illustration using a
metal saw to gradually release the gas.
Dimensions
NOTICE:
Although the gas inside the damper stay is
colorless, odorless and harmless, there is a
possibility that metal debris from cutting could
enter the assembly. Therefore, cover it with
cloth or something similar.
B065104E10
ab
80 mm (3.15 in.) 20 mm (0.80 in.)
Page 784 of 3000

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–17
ES
REGISTRATION
NOTICE:
The Vehicle Identification Number (VIN) must be input
into the replacement ECM.
HINT:
The VIN is a 17-digit alphanumeric vehicle identification
number. The intelligent tester is required to register the VIN.
1. INPUT INSTRUCTIONS
(a) The general VIN input instructions using the
intelligent tester are shown below:
(b) The arrow buttons (UP, DOWN, RIGHT and LEFT)
and numerical buttons (0 to 9) are used to input the
VIN.
(c) Cursor Operation
To move the cursor around the tester screen, press
the RIGHT and LEFT buttons.
(d) Alphabetical Character Input
(1) Press the UP and DOWN buttons to select the
desired alphabetical character.
(e) Numerical Character Input
(1) Press the numerical button corresponding to
the number that you want to input.
HINT:
Numerical characters can be selected by using
the UP and DOWN buttons.
(f) Correction
(1) When correcting the input character(s), put the
cursor onto the character using the RIGHT and
LEFT buttons.
(2) Select or input the correct character using the
UP and DOWN buttons, or the numerical
buttons.
(g) Finishing Input Operation
(1) Make sure that the input VIN matches the
vehicle VIN after input.
(2) Press the ENTER button on the tester.
2. READ VIN (Vehicle Identification Number)
(a) The VIN reading process is shown in the flowchart
below. Reading the VIN stored in the ECM is
necessary when comparing it to the VIN provided
with the vehicle.
(b) Read the VIN using the intelligent tester.
(c) Check the vehicle's VIN.
(d) Connect the intelligent tester to the DLC3.
(e) Turn the ignition switch to the ON position.
(f) Turn the tester ON.
