U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–43
AX
P0766Shift Solenoid "D" Performance (Shift
Solenoid Valve S4)1. Shift solenoid valve S4 remains open
or closed
2. Valve body is blocked (Brake control
valve)
3. Automatic transaxle (clutch, brake or
gear, etc.)Comes on DTC storedAX-74
P0771Shift Solenoid "E" Performance (Shift
Solenoid Valve SR)1. Shift solenoid valve SR remains open
or closed
2. Valve body is blocked
3. Automatic transaxle (clutch, brake or
gear etc.)Comes on DTC storedAX-78
P0776Pressure Control Solenoid "B"
Performance (Shift Solenoid Valve SL2)1. Shift solenoid valve SL2 remains open
or closed
2. Valve body is blocked
3. Automatic transaxle (clutch, brake or
gear etc.)Comes on DTC storedAX-82
P0778Pressure Control Solenoid "B" Electrical
(Shift Solenoid Valve SL2)1. Open or short in shift solenoid valve
SL2 circuit
2. Shift solenoid valve SL2
3. ECMComes on DTC storedAX-87
P0793 Intermediate Shaft Speed Sensor "A"1. Open or short in transmission
revolution sensor NC (speed sensor NC)
circuit
2. Transmission revolution sensor NC
(speed sensor NC)
3. ECMComes on DTC storedAX-91
P0796Pressure Control Solenoid "C"
Performance (Shift Solenoid Valve SL3)1. Shift solenoid valve SL3 remains open
or closed
2. Valve body is blocked
3. Automatic transaxle (clutch, brake or
gear etc.)Comes on DTC storedAX-95
P0798Pressure Control Solenoid "C" Electrical
(Shift Solenoid Valve SL3)1. Open or short in shift solenoid valve
SL3 circuit
2. Shift solenoid valve SL3
3. ECMComes on DTC storedAX-100
P0982Shift Solenoid "D" Control Circuit Low
(Shift Solenoid Valve S4)1. Short in shift solenoid valve S4 circuit
2. Shift solenoid valve S4
3. ECMComes on DTC storedAX-104
P0983Shift Solenoid "D" Control Circuit High
(Shift Solenoid Valve S4)1. Open in shift solenoid valve S4 circuit
2. Shift solenoid valve S4
3. ECMComes on DTC storedAX-104
P0985Shift Solenoid "E" Control Circuit Low
(Shift Solenoid Valve SR)1. Short in shift solenoid valve SR circuit
2. Shift solenoid valve SR
3. ECMComes on DTC storedAX-107
P0986Shift Solenoid "E" Control Circuit High
(Shift Solenoid Valve SR)1. Open in shift solenoid valve SR circuit
2. Shift solenoid valve SR
3. ECMComes on DTC storedAX-107
P2714Pressure Control Solenoid "D"
Performance (Shift Solenoid Valve SLT)1. Shift solenoid valve SLT remains
closed
2. Valve body is blocked
3. Automatic transaxle (clutch, brake or
gear etc.)Comes on DTC stored
AX-110
P2716Pressure Control Solenoid "D" Electrical
(Shift Solenoid Valve SLT)1. Open or short in shift solenoid valve
SLT circuit
2. Shift solenoid valve SLT
3. ECMComes on DTC storedAX-116
P2769Torque Converter Clutch Solenoid Circuit
Low (Shift Solenoid Valve DSL)1. Short in shift solenoid valve DSL
circuit
2. Shift solenoid valve DSL
3. ECMComes on DTC storedAX-120 DTC Code Detection Item Trouble Area MIL *1 Memory *2 See page
Page 1410 of 3000
AX–44U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM
AX
P2770Torque Converter Clutch Solenoid Circuit
High (Shift Solenoid Valve DSL)1. Open in shift solenoid valve DSL
circuit
2. Shift solenoid valve DSL
3. ECMComes on DTC storedAX-120 DTC Code Detection Item Trouble Area MIL *1 Memory *2 See page
Page 1411 of 3000

U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–45
AX
DESCRIPTION
The park/neutral position switch detects the shift lever position and sends signals to the ECM.
MONITOR DESCRIPTION
These DTCs indicate a problem with the park/neutral position switch and the wire harness in the park/
neutral position switch circuit.
The park/neutral position switch detects the shift lever position and sends a signal to the ECM.
For security, the park/neutral position switch detects the shift lever position so that engine can be started
only when the shift lever is in the P or N position
The park/neutral position switch sends a signal to the ECM according to the shift position (P, R, N or D).
The ECM determines that there is a problem with the switch or related parts if in receives more than 1
position signal simultaneously. The ECM will turn on the MIL and store the DTC.
MONITOR STRATEGY
DTC P0705Transmission Range Sensor Circuit Malfunc-
tion (PRNDL Input)
DTC No. DTC Detection Condition Trouble Area
P0705(A) Any 2 or more signals of the following are ON
simultaneously (2-trip detection logic)
• P input signal is ON.
• N input signal is ON.
• R input signal is ON.
• D input signal is ON.
• 3 input signal is ON.
• 2 input signal is ON.
(B) Any 2 or more signals of the following are ON
simultaneously (2-trip detection logic)
• NSW (STAR) input signal is ON.
• R input signal is ON.
• D input signal is ON.
• 3 input signal is ON.
• 2 input signal is ON.
(C) All switches are OFF simultaneously for NSW
(STAR), P, R, N, D, 3, 2 positions (2-trip detection
logic).
(D) Both 1 and 2 conditions are met (2-trip detection
logic)
1. One of the following conditions are met
(a) NSW (STAR) input signal is ON.
(b) P input signal is ON.
(c) N input signal is ON.
(d) R input signal is ON.
2. One of the following conditions are met
(a) 4 input signal is ON.
(b) L input signal is ON.• Short in park/neutral position switch circuit
• Park/neutral position switch
•ECM
Related DTCs P0705: Park/neutral position switch/Verify switch input
Required sensors/Components Park/neutral position switch
Frequency of operation Continuous
DurationCondition (A), (B), (D)
2 sec.
Condition (C)
60 sec.
MIL operation 2 driving cycles
Sequence of operation None
Page 1412 of 3000

AX–46U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM
AX
TYPICAL ENABLING CONDITIONS
All:
TYPICAL MALFUNCTION THRESHOLDS
1. One of the following conditions are met: Condition (A), (B), (C) and (D)
Condition (A):
Condition (B):
Condition (C):
Condition (D):
Both of the following conditions (1) or (2) are met:
COMPONENT OPERATING RANGE
The monitor will run whenever this DTC is not present. None
Ignition switchON
Battery voltage10.5 V or more
Number of the following signal input at the same time 2 or more
P switchON
N switchON
R switchON
D switchON
3 switchON
2 switchON
Number of the following signal input at the same time 2 or more
NSW (STAR) switchON
R switchON
D switchON
3 switchON
2 switchON
NSW (STAR) switchOFF
P switchOFF
N switchOFF
R switchOFF
D switchOFF
3 switchOFF
2 switchOFF
(1) One of the following conditions are met -
NSW (STAR) switchON
P switchON
R switchON
N switchON
(2) One of the following conditions are met -
4 shift position switchON
L shift position switchON
Park/neutral Position switch The park/neutral position switch sends only one signal to the ECM.
Page 1413 of 3000
U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–47
AX
WIRING DIAGRAM
C160583E01
Page 1414 of 3000

AX–48U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM
AX
INSPECTION PROCEDURE
(a) Disconnect the park/neutral position switch connector.
(b) Measure resistance according to the value(s) in the table
below when the shift lever is moved to each position.
Standard resistance
NG
OK
(a) Connect the park/neutral position switch connector.
(b) Disconnect the transmission control switch connector of
shift lock control unit assembly.
(c) Measure resistance according to the value(s) in the table
below when the shift lever is moved to each position.
Standard resistance
NG
OK
1INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY
C110340E20
Shift Position Tester Connection Specified Condition
P
2 - 6 and 4 - 5Below 1
Except P 10 k or higher
R
2 - 1Below 1
Except R 10 k or higher
N
2 - 9 and 4 - 5Below 1
Except N 10 k or higher
D and 4
2 - 7Below 1
Except D and 4 10 k or higher
3
2 - 3Below 1
Except 3 10 k or higher
2 and L
2 - 8Below 1
Except 2 and L 10 k or higher
REPLACE PARK/NEUTRAL POSITION
SWITCH ASSEMBLY
2INSPECT SHIFT LOCK CONTROL UNIT ASSEMBLY
G025493E01
Shift Position Tester Connection Specified Condition
D 2 - 9 Below 1
410 k or higher
D 3 - 9 10 k
or higher
4
Below 1
2 5 - 10 Below 1
L10 k or higher
2 4 - 10 10 k
or higher
L
Below 1
REPLACE SHIFT LOCK CONTROL UNIT
ASSEMBLY
Page 1415 of 3000

U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–49
AX
(a) Connect the transmission control switch connector of
shift lock control unit assembly.
(b) Turn the ignition switch to the ON position, and measure
the voltage according to the value(s) in the table below
when the shift lever is moved to each position.
Standard voltage
HINT:
*: The voltage will drop slightly due to lighting up of the
back up light.
NG
OK
3CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM)
C131058E03
Shift Position Tester Connection Specified Condition
P and N
E10-8 (NSW (STAR)) - Body groundBelow 1 V
Except P and N11 to 14 V
P
E5-23 (P) - Body ground11 to 14 V
Except PBelow 1 V
N
E5-22 (N) - Body ground11 to 14 V
Except NBelow 1 V
R
E5-11 (R) - Body ground11 to 14 V
*
Except RBelow 1 V
D and 4
E5-21 (D) - Body ground11 to 14 V
Except D and 4Below 1 V
4
E5-20 (4) - Body ground11 to 14 V
Except 4Below 1 V
3
E5-19 (3) - Body ground11 to 14 V
Except 3Below 1 V
2 and L
E5-10 (2) - Body ground11 to 14 V
Except 2 and LBelow 1 V
L
E5-9 (L) - Body ground11 to 14 V
Except LBelow 1 V
REPAIR OR REPLACE HARNESS OR
CONNECTOR
REPLACE ECM
Page 1416 of 3000

AX–50U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM
AX
DESCRIPTION
The ATF (Automatic Transmission Fluid) temperature sensor converts the fluid temperature into a
resistance value which is input into the ECM.
The ECM applies a voltage to the temperature sensor through ECM terminal THO1.
The sensor resistance changes with the transmission fluid temperature. As the temperature becomes
higher, the sensor resistance decreases.
One terminal of the sensor is grounded so that the sensor resistance decreases and the voltage goes
down as the temperature becomes higher.
The ECM calculates the fluid temperature based on the voltage signal.
DTC P0710Transmission Fluid Temperature Sensor "A"
Circuit
DTC P0712Transmission Fluid Temperature Sensor "A"
Circuit Low Input
DTC P0713Transmission Fluid Temperature Sensor "A"
Circuit High Input
DTC No. DTC Detection Condition Trouble Area
P0710(a) and (b) are detected momentarily within 0.5 sec.
when neither P0712 nor P0713 is detected (1-trip
detection logic)
(a) ATF temperature sensor resistance is less than 79
.
(b) ATF temperature sensor resistance is more than
156 k
.
HINT:
Within 0.5 sec., the malfunction switches from (a) to (b)
or from (b) to (a)• Open or short in ATF temperature sensor circuit
• Transmission wire (ATF temperature sensor)
•ECM
G031389E12
