Page 1929 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–188U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 28. INSPECT INPUT SHAFT ENDPLAY HINT: (See page AX-204) 29. REMOVE TRANSAXLE HOUSING (a) Remove the 16 bolts. (b) Tap on the circumf

Page 1930 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–189 AX 33. REMOVE DIFFERENTIAL GEAR ASSEMBLY (a) Remove the differential gear assembly from the transaxle case. 34. REMOVE OVERDRIVE BRAKE

Page 1931 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–190U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 38. REMOVE UNDERDRIVE PLANETARY GEAR ASSEMBLY (a) Remove the bolt and pawl shaft clamp. (b) Remove the parking lock pawl shaft. (c)

Page 1932 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–191 AX 40. REMOVE UNDERDRIVE CLUTCH ASSEMBLY (a) Remove the underdrive clutch assembly, thrust bearing and bearing race from the transaxle

Page 1933 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–192U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Remove the flange, 4 discs and 4 plates from the transaxle case. 43. INSPECT UNDERDRIVE CLUTCH DISC NO.2 HINT: (See page AX-201

Page 1934 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–193 AX 48. REMOVE GOVERNOR APPLY GASKET NO.1 (a) Using a screwdriver, remove the 3 apply gaskets. 49. REMOVE BRAKE APPLY TUBE (a) Remove th

Page 1935 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–194U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Remove the thrust needle roller bearing and thrust bearing race from the rear planetary sun gear assembly. (c) Remove the plan

Page 1936 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–195 AX 56. REMOVE PLANETARY CARRIER THRUST WASHER NO.1 (a) Remove the planetary carrier thrust washer No.1 from the planetary gear assemb
