Page 881 of 3000
EM–762GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
DISASSEMBLY
1. REMOVE OIL FILLER CAP SUB-ASSEMBLY
(a) Remove the oil filler cap sub-assembly and oil filler
gasket.
2. REMOVE SPARK PLUG
(a) Remove the spark plugs.
3. REMOVE OIL PAN DRAIN PLUG
(a) Remove the oil pan drain plug and oil pan drain plug
gasket.
4. REMOVE VENTILATION VALVE SUB-ASSEMBLY
(a) Remove the ventilation valve sub-assembly.
5. REMOVE CAMSHAFT POSITION SENSOR
(a) Remove the 4 bolts and 4 camshaft position
sensors.
A129654
A129655
A129656E04
Page 882 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–77
EM
6. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY
(a) Remove the 4 bolts and 4 camshaft oil control
valves.
7. REMOVE CRANKSHAFT POSITION SENSOR
(a) Remove the bolt and crankshaft position sensor.
8. REMOVE NO. 1 OIL PIPE
(a) Remove the 2 oil pipe unions, gaskets and oil pipe.
(b) Remove the oil control valve filter LH and gaskets.
9. REMOVE OIL PIPE
(a) Remove the bolt.
(b) Remove the 2 oil pipe unions and oil pipe.
(c) Remove the oil control valve filter RH and gaskets.
A129662E06
A129663
A135726E01
A134878E01
Page 883 of 3000
EM–782GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
10. REMOVE CYLINDER BLOCK WATER DRAIN COCK
SUB-ASSEMBLY
(a) Remove the cylinder block water drain cocks from
the cylinder block.
(b) Remove the cylinder block water drain cock plugs
from the water drain cocks.
11. REMOVE OIL FILTER ELEMENT
(a) Remove the drain plug.
NOTICE:
Do not remove the O-ring from the oil filter cap.
(b) Connect the hose to the pipe.
(c) Insert the pipe with the hose into the oil filter cap.
(d) Make sure that the oil is completely drained and
remove the pipe and O-ring.
A135829E03
A129666
A129667E01
Page 884 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–79
EM
(e) Using SST, remove the oil filter cap sub-assembly.
SST 09228-06501
(f) Remove the oil filter element and O-ring from the oil
filter cap sub-assembly.
NOTICE:
Do not use any tools when removing the O-ring
to prevent the O-ring groove from being
damaged.
12. REMOVE CRANKSHAFT PULLEY
(a) Using SST, loosen the crankshaft pulley bolt.
SST 09213-70011 (09213-70020), 09330-00021
(b) Using SST, remove the crankshaft pulley bolt and
crankshaft pulley.
SST 09950-50013 (09951-05010, 09952-05010,
09953-05020, 09954-05021)
A129668E01
A106167E01
A120690E02
A120691E02
Page 885 of 3000
EM–802GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
13. REMOVE OIL COOLER ASSEMBLY
(a) Remove the bolt, 2 clamps, and 4 clips and
disconnect the 2 water by-pass hoses.
(b) Remove the union bolt, oil cooler assembly, and O-
ring.
14. REMOVE NO. 1 OIL COOLER BRACKET
(a) Remove the 3 bolts, 3 nuts, and oil cooler pipe with
No. 1 oil cooler bracket.
(b) Remove the bolt, 2 nuts, No. 1 oil cooler bracket,
and gasket.
(c) Using a "TORX" socket wrench E8, remove the 2
stud bolts.
15. REMOVE NO. 1 FRONT ENGINE MOUNTING
BRACKET LH
(a) Remove the 6 bolts and No. 1 front engine mounting
bracket LH.
(b) Using a "TORX" socket wrench E8, remove the 2
stud bolts.
A136291
A136292
A136293
A136294E01
A129672
Page 886 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–81
EM
16. REMOVE WATER INLET HOUSING
(a) Remove the 2 nuts, water inlet and thermostat.
(b) Remove the gasket.
(c) Remove the drain cock plug.
(d) Remove the drain cock assembly.
(e) Remove the 2 stud bolts.
(f) Separate the No. 1 water by-pass hose.
(g) Remove the 2 bolts, nut, and water inlet housing.
(h) Remove the 2 O-rings.
17. REMOVE WATER OUTLET
(a) Remove the 2 bolts, 4 nuts and water outlet.
(b) Remove the 2 gaskets and O-ring.
A129673
A134879E01
A129675
A129676E01
A129677
Page 887 of 3000
EM–822GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
18. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY
(for Bank 1)
(a) Remove the 12 bolts, seal washer, cylinder head
cover sub-assembly and cylinder head cover
gasket.
(b) Remove the 3 gaskets.
19. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY
(for Bank 2)
(a) Remove the 12 bolts, seal washer, cylinder head
cover sub-assembly and cylinder head cover
gasket.
NOTICE:
The baffle plate is located on the back of the
portion shown in the illustration. Do not damage
the baffle plate when removing the head cover.
(b) Remove the 3 gaskets.
20. REMOVE NO. 2 OIL PAN SUB-ASSEMBLY
(a) Remove the 16 bolts and 2 nuts.
A129679
A129699
A129678E02
A129705
A129680E01
Page 888 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–83
EM
(b) Insert the blade of SST between the oil pans. Cut
through the applied sealer and remove the No. 2 oil
pan sub-assembly.
SST 09032-00100
NOTICE:
Be careful not to damage the contact surfaces of
the oil pans.
(c) Using a "TORX" socket wrench E6, remove the 2
stud bolts.
21. REMOVE OIL STRAINER SUB-ASSEMBLY
(a) Remove the bolt, 2 nuts, oil strainer sub-assembly
and gasket.
(b) Using a "TORX" socket wrench E6, remove the 2
stud bolts.
22. REMOVE OIL PAN SUB-ASSEMBLY
(a) Remove the 16 bolts and 2 nuts.
HINT:
Be sure to clean the bolts and stud bolts and check
the threads for cracks or other damage.
(b) Remove the oil pan sub-assembly by prying
between the oil pan sub-assembly and cylinder
block sub-assembly with a screwdriver.
NOTICE:
Be careful not to damage the contact surfaces of
the cylinder block and oil pan.
HINT:
Tape the screwdriver tip before use.
A120816E01
A129681
A162634E01
A129683E01
