(d) Connect the connector.
(e) Connect the No. 1 ventilation hose.
(f) Install the clamp and connect the throttle with motor
body assembly connector.
(g) Connect the vapor feed hose.
(h) Connect the 2 water by-pass hoses to the throttle
with motor body assembly.
25. INSTALL VENTILATION HOSE
(a) Using pliers, grip the claws of the 2 clips and slide
the 2 clips to the intake air surge tank assembly and
ventilation valve.
26. INSTALL ENGINE HANGERS
(a) Install the 4 bolts, and 2 engine hangers.
27. REMOVE ENGINE STAND
28. INSTALL DRIVE PLATE AND RING GEAR SUB-
ASSEMBLY (See page EM-13)
29. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for
2WD)
HINT:
See page AX-166.
30. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for
4WD)
HINT:
(See page AX-167).
31. INSTALL TRANSFER STIFFENER PLATE RH (See
page AX-168)
A129467
A129464E04
A162372
A129635E01
Page 1010 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–51
EM
32. INSTALL MANIFOLD STAY
(a) Install the bolt, nut, and manifold stay.
Torque: 34 N*m (347 kgf*cm, 25 ft.*lbf)
33. INSTALL ENGINE FRONT MOUNTING BRACKET
(See page AX-167)
34. INSTALL STARTER ASSEMBLY (See page ST-13)
35. INSTALL ENGINE WIRE
36. INSTALL FRONT DRIVE SHAFT ASSEMBLY LH (See
page DS-17)
37. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH (for
2WD) (See page DS-17)
38. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH (for
4WD) (See page DS-17)
39. INSTALL FRONT FRAME ASSEMBLY
(a) Install the engine mounting insulators RH and LH
with the 2 nuts.
Torque: 95 N*m (969 kgf*cm, 70 ft.*lbf)
(b) Install the engine mounting insulator FR with the
bolt.
Torque: 87 N*m (887 kgf*cm, 64 ft.*lbf)
A155023
A163266E01
A155019
Page 1011 of 3000
EM–522GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
(c) Install the engine mounting insulator RR with the 2
bolts.
Torque: 78 N*m (795 kgf*cm, 58 ft.*lbf)
(d) Connect the connector and clamp.
40. INSTALL POWER STEERING LINK (See page PS-39)
41. INSTALL FRONT STABILIZER BAR
HINT:
(See page SP-36).
42. REMOVE ENGINE HANGERS
(a) Remove the 4 bolts and 2 engine hangers.
43. INSTALL VANE PUMP ASSEMBLY
(a) Install the vane pump with the 2 bolts and nut.
Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
(b) Install the 2 pressure feed tube clamp nuts.
Torque: 7.8 N*m (80 kgf*cm, 69 in.*lbf)
(c) Connect the power steering oil pressure switch
connector.
44. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE
(a) Set the engine assembly with transaxle on the
engine lifter.
(b) Install the engine assembly to the vehicle.
A155018
A155022
A129635E01
A139216
A155024
Page 1012 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–53
EM
(c) Install the frame side rail plates RH and LH with the
6 bolts and 2 nuts.
Torque: A
85 N*m (867 kgf*cm, 63 ft.*lbf)
B
32 N*m (329 kgf*cm, 24 ft.*lbf)
(d) Install the front suspension member brace rear RH
and LH with the 6 bolts and 2 nuts.
Torque: A
85 N*m (867 kgf*cm, 63 ft.*lbf)
B
32 N*m (329 kgf*cm, 24 ft.*lbf)
45. RECONNECT SUCTION HOSE SUB-ASSEMBLY (See
page AC-231)
46. RECONNECT DISCHARGE HOSE SUB-ASSEMBLY
(See page AC-232)
47. INSTALL STEERING INTERMEDIATE SHAFT SUB-
ASSEMBLY (See page SR-10)
48. INSTALL FRONT AXLE ASSEMBLY LH (See page DS-
18)
49. INSTALL FRONT AXLE ASSEMBLY RH
HINT:
Use the same procedures described for the LH side.
50. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM
LH (See page DS-18)
51. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM
RH
HINT:
Use the same procedures described for the LH side.
52. INSTALL TIE ROD ASSEMBLY LH (See page DS-18)
53. INSTALL TIE ROD ASSEMBLY RH
HINT:
Use the same procedures described for the LH side.
54. INSTALL FRONT SPEED SENSOR LH (See page DS-
18)
55. INSTALL FRONT SPEED SENSOR RH
HINT:
Use the same procedures described for the LH side.
56. INSTALL FRONT AXLE HUB NUT LH (See page DS-
19)
57. INSTALL FRONT AXLE HUB NUT RH
HINT:
Use the same procedures described for the LH side.
A162364
A162363
Page 1013 of 3000
EM–542GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
58. INSTALL FRONT STABILIZER LINK ASSEMBLY LH
(See page DS-19)
59. INSTALL FRONT STABILIZER LINK ASSEMBLY RH
HINT:
Use the same procedures described for the LH side.
60. INSTALL PROPELLER WITH CENTER BEARING
SHAFT ASSEMBLY (See page PR-9)
61. FULLY TIGHTEN PROPELLER WITH CENTER
BEARING SHAFT ASSEMBLY (See page PR-10)
62. INSTALL FRONT EXHAUST PIPE ASSEMBLY (for
2WD)
(a) Install the front exhaust pipe assembly (See page
EX-4).
63. INSTALL FRONT EXHAUST PIPE ASSEMBLY (for
4WD)
(a) Install front exhaust pipe assembly (See page EX-
10).
64. INSTALL CENTER EXHAUST PIPE ASSEMBLY
(a) Install center exhaust pipe assembly (See page EX-
10).
65. CONNECT ENGINE WIRE
(a) Install the 2 bolts and 2 ground cables.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
A163267
Page 1014 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–55
EM
(b) Install the bolt and 2 clamps to the body.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
(c) Connect the wire to the engine room junction block.
Then, install it with the nut.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
(d) Install the engine wire to the body with the 2 nuts.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
66. CONNECT NO. 1 OIL RESERVOIR TO PUMP HOSE
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the No. 1 oil reservoir to pump hose
to the oil reservoir tank.
67. CONNECT RETURN TUBE SUB-ASSEMBLY
(a) Using pliers, grip the claws of the 2 clips and slide
the 2 clips to connect 2 return tube sub-assemblies.
NOTICE:
Take care not to damage the hose protector.
68. CONNECT TRANSMISSION CONTROL CABLE
ASSEMBLY
(a) Connect the control cable to the control cable
clamp.
A155030
A155037
A155029
A052327
C090579
Page 1015 of 3000
EM–562GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
(b) Install the transmission control cable assembly to
the control shaft lever with the nut.
Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf)
(c) Connect the transmission control cable assembly to
the bracket with a new clip.
69. CONNECT FUEL TUBE SUB-ASSEMBLY
(a) Push in the fuel tube connector to the fuel pipe until
the fuel tube makes a "click" sound.
NOTICE:
• Check for damage or contamination on the
connected part of the pipe.
• Check if the pipe and the connector are
securely connected by trying to pull them
apart.
(b) Install the No. 1 fuel pipe clamp.
70. CONNECT NO. 1 OIL COOLER OUTLET HOSE
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the No. 1 oil cooler outlet hose to the
No. 1 oil cooler outlet tube.
D025414E04
C089134E02
B012944
A155045
A155031
Page 1016 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–57
EM
71. CONNECT NO. 1 OIL COOLER INLET HOSE
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the No. 1 oil cooler inlet hose to the
No. 1 oil cooler inlet tube.
72. CONNECT HEATER WATER INLET HOSE B
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the heater water inlet hose to water
outlet.
73. CONNECT HEATER WATER OUTLET HOSE B
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the heater water outlet hose to water
outlet.
74. INSTALL RADIATOR INLET HOSE
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the radiator inlet hose to the water
outlet.
75. INSTALL RADIATOR OUTLET HOSE
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the radiator outlet hose to the water
inlet.
A155032
A155043
A155044
A155046
