TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – 2GR-FE CHARGINGPP–19
PP
RECOMMENDED TOOLS
09082-00040 TOYOTA Electrical Tester
(09083-00150) Test Lead Set

Page 10 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–20PREPARATION – 2GR-FE CHARGING
PP
EQUIPMENT
Ammeter
Ohmmeter
To r q u e w r e n c h
Vernier calipers
Pin (
1 mm)

Page 11 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – BRAKE CONTROLPP–55
PP
EQUIPMENT
Torque wrench
Oscilloscope

Page 12 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–56PREPARATION – BRAKE CONTROL
PP
LUBRICANT
Item Capacity Classification
Brake fluid - SAE J1703 or FMVSS No. 116 DOT3

Page 13 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–72PREPARATION – CRUISE CONTROL
PP
EQUIPMENT
To r q u e w r e n c h

Page 14 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–82PREPARATION – WINDSHIELD / WINDOWGLASS
PP
SSM
08850-00801 Windshield Glass Adhesive Set
or equivalent

Page 15 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SERVICE SPECIFICATIONS – STANDARD BOLTSS–3
SS
HOW TO DETERMINE NUT STRENGTH
Nut Type
HINT:
• *: Nut with 1 or more marks on one side surface of the nut.
• Use a nut with the same nut strengt

Page 16 of 3000

TOYOTA SIENNA 2007 Service Repair Manual SS–30SERVICE SPECIFICATIONS – U151E AUTOMATIC TRANSAXLE
SS
TORQUE SPECIFICATIONS
Part Tightened N*m kgf*cm ft*lbf
Park/neutral position switch Nut 6.9 70 61 in.*lbf
Bolt 5.4 55 48 in.*lbf
Contro

SS–30SERVICE SPECIFICATIONS – U151E AUTOMATIC TRANSAXLE
SS
TORQUE SPECIFICATIONS
Part Tightened N*m kgf*cm ft*lbf
Park/neutral position switch Nut 6.9 70 61 in.*lbf
Bolt 5.4 55 48 in.*lbf
Control shaft lever x Control shaft 13 130 9
Shift control cable x Control shaft lever 13 130 9
Transaxle housing x Engine block A bolt 64 653 47
B bolt 46 470 34
C bolt 43 439 32
Torque converter clutch x Drive plate 41 413 35
Flywheel housing under cover x Automatic transaxle 7.8 80 69 in.*lbf
Engine mounting bracket FR x Transaxle 64 653 47
Oil filler tube x Transaxle5.5 56 49 in.*lbf
Control cable bracket No. 1 x Transaxle 12 122 9
Control cable bracket No. 2 x Transaxle 12 122 9
Oil cooler tube clamp x Control cable bracket 5.5 56 49 in.*lbf
Oil cooler inlet tube x Transaxle27 275 20
Oil cooler outlet tube x Transaxle 27 275 20
Starter x Transaxle37 377 27
Starter wire x Starter9.8 100 87 in.*lbf
Wire harness x Transaxle13 133 10
Wire harness clamp x Transaxle8.4 86 74 in.*lbf
Speed sensor (NC) x Transaxle11 11 5 8
Speed sensor (NT) x Transaxle11 11 2 8
Air cleaner x Air cleaner hose5.0 51 44 in.*lbf
Drain plug x Oil pan49 500 36
Transmission wire x Transaxle5.4 55 48 in.*lbf
ATF temperature sensor x Valve body 6.6 67 58 in.*lbf
Oil pan x Transaxle7.8 80 69 in.*lbf
Solenoid valve x Valve body A B bolt 11 110 8
C D bolt 6.6 67 58 in.*lbf
Valve body x Transaxle11 11 0 8
Oil strainer x Valve body11 11 0 8
Floor shift assembly x Body21 214 15
Control cable x Body12 122 9
Engine mount bracket RR x Transfer stiffener plate RH 34 350 25
Oil cooler assembly x Body Nut
7.0 71 62 in.*lbf
bolt
Differential gear lube apply tube x Transaxle housing 9.8 100 87 in.*lbf
Front planetary gear lock nut
210 to 3502,141 to
3,569155 to 258
Brake apply tube clamp x Transaxle case 5.4 55 48 in.*lbf
Transaxle case No. 1 plug x Transaxle rear cover 7.4 75 65 in.*lbf
Transaxle rear cover x Transaxle case Bolt A 19 190 14
Other bolt 25 250 18
Pawl shaft clamp x Transaxle case 9.8 100 87 in.*lbf
Oil pump assembly x Transaxle case 22 226 16
