Page 1513 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–130U151E AUTOMATIC TRANSAXLE – TRANSMISSION WIRE AX TRANSMISSION U151E AUTOMATIC TRANSAXLE TRANSMISSION WIRE COMPONENTS C119004E05

Page 1514 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – TRANSMISSION WIREAX–131 AX REMOVAL 1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL 2. REMOVE ENGINE UNDER COVER NO.1 3. DRAIN AUTOMATIC TRANSAXLE FLUID (a) Remove

Page 1515 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–132U151E AUTOMATIC TRANSAXLE – TRANSMISSION WIRE AX 6. REMOVE TRANSMISSION WIRE (a) Disconnect the transmission wire connector. (b) Remove the bolt and transmission wire. (c) Remove the O-rin

Page 1516 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – TRANSMISSION WIREAX–133 AX (c) Using a new gasket, install the oil pan to the transaxle case with the 18 bolts. Torque: 7.8 N*m (80 kgf*cm, 69 in.*lbf) NOTICE: Apply

Page 1517 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–20U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM AX MONITOR DRIVE PATTERN 1. MONITOR DRIVE PATTERN FOR ECT TEST (a) Perform this drive pattern as one method to simulate the detection

Page 1518 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–21 AX HINT: *1: Drive at such a speed in the uppermost gear, to engage lock-up. The vehicle can be driven at a speed lower than that in

Page 1519 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–136U151E AUTOMATIC TRANSAXLE – VALVE BODY ASSEMBLY AX REMOVAL 1. REMOVE ENGINE UNDER COVER NO.1 2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL 3. DRAIN AUTOMATIC TRANSAXLE FLUID (See pag

Page 1520 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – VALVE BODY ASSEMBLYAX–137 AX 6. REMOVE VALVE BODY OIL STRAINER ASSEMBLY (a) Remove the 3 bolts and oil strainer. NOTICE: Be careful when removing the oil strainer as
