Page 2009 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER UNITTF–19 TF (d) When the roller comes off due to deformation of the gauge, completely remove the roller and remaining inner races of the center differential case tapered

Page 2010 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–20TRANSFER – TRANSFER UNIT TF (c) Using a press, remove the driven pinion, transfer driven pinion rear bearing inner race and transfer pinion bearing spacer. NOTICE: • Put shop cloths aro

Page 2011 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER UNITTF–21 TF INSPECTION 1. INSPECT PRELOAD (a) Using SST(s) and a torque wrench, check the initial torque within the backlash range. SST 09326-20011 Torque: 0.9 to 1.4 N*m (

Page 2012 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–22TRANSFER – TRANSFER UNIT TF REASSEMBLY 1. INSTALL TRANSFER DRIVEN PINION REAR BEARING (a) Using SST(s) and a press, install the transfer driven pinion rear bearing outer race to the trans

Page 2013 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER UNITTF–23 TF 7. INSTALL DRIVEN PINION (a) Install the driven pinion to the transfer case. (b) Install a new transfer pinion bearing spacer and anew transfer driven pinion re

Page 2014 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–24TRANSFER – TRANSFER UNIT TF (d) If the preload is insufficient, even though the tightening torque of the transfer gear nut exceeds the maximum of the standard value., loosen the transfer

Page 2015 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER UNITTF–25 TF 11. INSTALL TRANSFER RING GEAR MOUNTING CASE (a) Install the transfer ring gear mounting case to the transfer case. NOTICE: Damage to the spline, the bearing

Page 2016 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–26TRANSFER – TRANSFER UNIT TF (d) With SST and the transfer RH bearing sub- assembly in close contact, install the transfer RH bearing retainer sub-assembly together with SST into the trans
