Page 1497 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–11 AX (6) Check the lock-up mechanism. • Drive in D position (5th gear), at a steady speed (lock-up ON). • Lightly depress the accel

Page 1498 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–12U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM AX (d) 2 position test: Shift into the 2 position and fully depress the accelerator pedal and check the following points. (1) Check u

Page 1499 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE FLUIDAX–123 AX AUTOMATIC TRANSAXLE FLUID ON-VEHICLE INSPECTION 1. CHECK FLUID LEVEL HINT: Drive the vehicle so that the engine and transaxle are a

Page 1500 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–13 AX MECHANICAL SYSTEM TESTS 1. PERFORM MECHANICAL SYSTEM TESTS (a) Measure the stall speed. The object of this test is to check the ove

Page 1501 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–14U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM AX (b) Measure the time lag. (1) When the shift lever is shifted while the engine is idling, there will be a certain time lapse or la

Page 1502 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEMAX–15 AX HYDRAULIC TEST 1. PERFORM HYDRAULIC TEST (a) Measure the line pressure. NOTICE: • Perform the test at the normal operating ATF (

Page 1503 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–16U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE SYSTEM AX (9) Disconnect the connector of the transmission wire. HINT: Disconnect the connector only when performing the D position stall

Page 1504 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–124U151E AUTOMATIC TRANSAXLE – PARK / NEUTRAL POSITION SWITCH AX TRANSMISSION U151E AUTOMATIC TRANSAXLE PARK / NEUTRAL POSITION SWITCH COMPONENTS C126420E01
