Page 2217 of 3000
SUSPENSION – FRONT STABILIZER BAR (for 2WD)SP–29
SP
INSPECTION
1. INSPECT FRONT STABILIZER LINK ASSEMBLY LH
(a) As shown in the illustration, flip the ball joint stud
back and forth 5 times, before installing the nut.
(b) Using a torque wrench, turn the nut continuously at
a rate of 2 to 4 seconds per 1 turn and take the
torque reading on the 5th turn.
Turning torque:
0.05 to 1.96 N*m (0.5 to 20kgf*cm, 0.4 to 17.4
in.*lbf)
C066721
Page 2218 of 3000

SUSPENSION – FRONT STABILIZER BAR (for 4WD)SP–37
SP
INSTALLATION
1. INSTALL FRONT STABILIZER BAR
2. INSTALL NO. 1 FRONT STABILIZER BAR BUSHING
(a) Install the 2 front stabilizer bar bush No.1 to the
stabilizer bar front.
NOTICE:
Install the bushings with the slit facing on the
rear side of the vehicle.
HINT:
Install the bushing to the outer side of the bushing
stopper on the stabilizer bar as shown in the
illustration.
3. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH
HINT:
(See page EM-48)
4. INSTALL MANIFOLD STAY
HINT:
(See page EM-51)
5. INSTALL STEERING INTERMEDIATE SHAFT
ASSEMBLY
HINT:
(See page PS-21)
6. INSTALL RACK & PINION POWER STEERING GEAR
ASSEMBLY
HINT:
(See page PS-21)
7. CONNECT PRESSURE FEED TUBE ASSEMBLY
HINT:
(See page PS-21)
SST 09023-12701
8. INSTALL TIE ROD ASSEMBLY LH
HINT:
(See page AH-4)
9. INSTALL TIE ROD ASSEMBLY RH
HINT:
Remove the RH side by the same procedures as the LH
side.
10. INSTALL NO. 1 FRONT STABILIZER BRACKET LH
(a) Install the front stabilizer bracket No.1 LH with the 2
bolts.
Torque: 17 N*m (173 kgf*cm, 12 ft.*lbf)
11. INSTALL NO. 1 FRONT STABILIZER BRACKET RH
HINT:
Install the RH side by the same procedures as the LH
side.
12. INSTALL CENTER EXHAUST PIPE ASSEMBLY
HINT:
(See page EX-10)
F044967E01
F044966
Page 2219 of 3000
SP–38SUSPENSION – FRONT STABILIZER BAR (for 4WD)
SP
13. INSTALL FRONT STABILIZER LINK ASSEMBLY LH
HINT:
(See page AH-4)
14. INSTALL FRONT STABILIZER LINK ASSEMBLY RH
HINT:
Install the RH side by the same procedures as the LH
side.
15. INSTALL FRONT WHEELS
16. INSPECT CENTER FRONT WHEEL
17. INSPECT STEERING WHEEL CENTER POINT
18. ADD POWER STEERING FLUID
19. BLEED POWER STEERING FLUID
HINT:
(See page PS-6)
20. CHECK POWER STEERING FLUID LEAKAGE
21. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT
HINT:
(See page SP-4)
Page 2220 of 3000

SUSPENSION – FRONT STABILIZER BAR (for 4WD)SP–35
SP
REMOVAL
1. REMOVE FRONT WHEELS
2. REMOVE FRONT STABILIZER LINK ASSEMBLY LH
HINT:
(See page SP-26)
3. REMOVE FRONT STABILIZER LINK ASSEMBLY RH
HINT:
Remove the RH side by the same procedures as the LH
side.
4. REMOVE CENTER EXHAUST PIPE ASSEMBLY
HINT:
(See page EX-8)
5. REMOVE NO. 1 FRONT STABILIZER BRACKET LH
(a) Remove the 2 bolts, the front stabilizer bracket No.1
LH and the front stabilizer bracket No.2 LH.
6. REMOVE NO. 1 FRONT STABILIZER BRACKET RH
HINT:
Remove the RH side by the same procedures as the LH
side.
7. SEPARATE TIE ROD ASSEMBLY LH
HINT:
(See page AH-4)
SST 09628-62011
8. SEPARATE TIE ROD ASSEMBLY RH
SST 09628-62011
HINT:
Remove the RH side by the same procedures as the LH
side.
9. SEPARATE PRESSURE FEED TUBE ASSEMBLY
HINT:
(See page PS-21)
SST 09023-12701
10. SEPARATE STEERING INTERMEDIATE SHAFT
ASSEMBLY
HINT:
(See page PS-21)
11. REMOVE RACK & PINION POWER STEERING GEAR
ASSEMBLY
HINT:
(See page PS-21)
12. REMOVE MANIFOLD STAY
HINT:
(See page EM-39)
13. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY RH
HINT:
(See page EM-37)
14. REMOVE NO. 1 FRONT STABILIZER BAR BUSHING
F044966
Page 2221 of 3000
SP–36SUSPENSION – FRONT STABILIZER BAR (for 4WD)
SP
15. REMOVE FRONT STABILIZER BAR
INSPECTION
1. INSPECT FRONT STABILIZER LINK ASSEMBLY LH
(a) As shown in the illustration, flip the ball joint stud
back and forth 5 times, before installing the nut.
(b) Using a torque wrench, turn the nut continuously at
a rate of 2 to 4 seconds per 1 turn and take the
torque reading on the 5th turn.
Turning torque:
0.05 to 1.96 N*m (0.5 to 20 kgf*cm, 0.4 to 17.4
in.*lbf)
C066721
Page 2222 of 3000

SUSPENSION – FRONT STABILIZER BAR (for 4WD)SP–37
SP
INSTALLATION
1. INSTALL FRONT STABILIZER BAR
2. INSTALL NO. 1 FRONT STABILIZER BAR BUSHING
(a) Install the 2 front stabilizer bar bush No.1 to the
stabilizer bar front.
NOTICE:
Install the bushings with the slit facing on the
rear side of the vehicle.
HINT:
Install the bushing to the outer side of the bushing
stopper on the stabilizer bar as shown in the
illustration.
3. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH
HINT:
(See page EM-48)
4. INSTALL MANIFOLD STAY
HINT:
(See page EM-51)
5. INSTALL STEERING INTERMEDIATE SHAFT
ASSEMBLY
HINT:
(See page PS-21)
6. INSTALL RACK & PINION POWER STEERING GEAR
ASSEMBLY
HINT:
(See page PS-21)
7. CONNECT PRESSURE FEED TUBE ASSEMBLY
HINT:
(See page PS-21)
SST 09023-12701
8. INSTALL TIE ROD ASSEMBLY LH
HINT:
(See page AH-4)
9. INSTALL TIE ROD ASSEMBLY RH
HINT:
Remove the RH side by the same procedures as the LH
side.
10. INSTALL NO. 1 FRONT STABILIZER BRACKET LH
(a) Install the front stabilizer bracket No.1 LH with the 2
bolts.
Torque: 17 N*m (173 kgf*cm, 12 ft.*lbf)
11. INSTALL NO. 1 FRONT STABILIZER BRACKET RH
HINT:
Install the RH side by the same procedures as the LH
side.
12. INSTALL CENTER EXHAUST PIPE ASSEMBLY
HINT:
(See page EX-10)
F044967E01
F044966
Page 2223 of 3000
SP–38SUSPENSION – FRONT STABILIZER BAR (for 4WD)
SP
13. INSTALL FRONT STABILIZER LINK ASSEMBLY LH
HINT:
(See page AH-4)
14. INSTALL FRONT STABILIZER LINK ASSEMBLY RH
HINT:
Install the RH side by the same procedures as the LH
side.
15. INSTALL FRONT WHEELS
16. INSPECT CENTER FRONT WHEEL
17. INSPECT STEERING WHEEL CENTER POINT
18. ADD POWER STEERING FLUID
19. BLEED POWER STEERING FLUID
HINT:
(See page PS-6)
20. CHECK POWER STEERING FLUID LEAKAGE
21. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT
HINT:
(See page SP-4)
Page 2224 of 3000

SUSPENSION – REAR COIL SPRINGSP–41
SP
REMOVAL
1. REMOVE REAR WHEEL
2. REMOVE SKID CONTROL SENSOR WIRE (for 2WD)
(a) Disconnect the skid control sensor connector.
(b) Remove the bolt and disconnect the bracket from
the rear axle beam assembly.
HINT:
Separate the RH side by the same procedures as
the LH side.
3. SEPARATE SPEED SENSOR REAR LH (for 4WD)
(a) Remove the bolt and speed sensor rear LH.
4. SEPARATE SPEED SENSOR REAR RH (for 4WD)
HINT:
Separate the RH side by the same procedures as the LH
side.
5. REMOVE EXHAUST PIPE ASSEMBLY TAIL
HINT:
• 2WD DRIVE TYPE (See page EX-2)
• 4WD DRIVE TYPE (See page EX-8)
6. REMOVE PROPELLER W/CENTER BEARING SHAFT
ASSEMBLY (for 4WD)
HINT:
(See page PR-2)
7. SEPARATE REAR DRIVE SHAFT ASSEMBLY LH (for
4WD)
(a) Place matchmarks on the rear drive shaft assembly
LH and differential flange.
(b) Remove the 4 nuts and 4 washers, separate rear
drive shaft assembly LH.
8. SEPARATE REAR DRIVE SHAFT ASSEMBLY RH (for
4WD)
HINT:
Separate the RH side by the same procedures as the LH
side.
9. REMOVE DIFFERENTIAL CARRIER ASSEMBLY
REAR (for 4WD)
HINT:
(See page DF-8)
G023899
G023898
G023905E01
