Page 1329 of 3000

TOYOTA SIENNA 2007 Service Repair Manual ST–62GR-FE STARTING – STARTER ST (c) Remove the 2 bolts and the starter. DISASSEMBLY 1. REMOVE REPAIR SERVICE STARTER KIT (a) Remove the nut and disconnect the lead wire from the repair service

Page 1330 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE STARTING – STARTERST–7 ST 3. REMOVE STARTER ARMATURE PLATE (a) Remove the starter armature plate from the starter yoke. 4. REMOVE DRIVE HOUSING STARTER BEARING COVER (a) Using a screw

Page 1331 of 3000

TOYOTA SIENNA 2007 Service Repair Manual ST–82GR-FE STARTING – STARTER ST INSPECTION 1. INSPECT STARTER ASSEMBLY NOTICE: These tests must be performed within 3 to 5 seconds to avoid burning out the coil. (a) Perform the pull-in test.

Page 1332 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE STARTING – STARTERST–9 ST 2. INSPECT REPAIR SERVICE STARTER KIT (a) Check the plunger. (1) Push in the plunger and check that it returns quickly to its original position. If necessary, r

Page 1333 of 3000

TOYOTA SIENNA 2007 Service Repair Manual ST–102GR-FE STARTING – STARTER ST (d) Using a vernier caliper, measure the commutator's length. Standard length: 3.3 to 4.0 mm (0.1299 to 0.1575 in.) If the length is greater than the maxim

Page 1334 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE STARTING – STARTERST–11 ST 2. INSTALL STARTER ARMATURE ASSEMBLY (a) Apply grease to the plate washer and the armature shaft. (b) Install the starter armature to the starter commutator e

Page 1335 of 3000

TOYOTA SIENNA 2007 Service Repair Manual ST–122GR-FE STARTING – STARTER ST 6. INSTALL STARTER YOKE ASSEMBLY (a) Align the key of the starter yoke with the keyway of repair service starter kit. (b) Install the starter yoke with the 2 t

Page 1336 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE STARTING – STARTERST–13 ST INSTALLATION 1. INSTALL STARTER ASSEMBLY (a) Install the starter with the 2 bolts. Torque: 37 N*m (380 kgf*cm, 26 ft.*lbf) for bolt (b) Connect the starter conn
