Page 1225 of 3000
EX–62GR-FE EXHAUST – EXHAUST PIPE (for 2WD)
EX
(d) Install the 2 compression springs and 2 bolts.
Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
(e) Connect the heated oxygen sensor (for bank 2
sensor 2) connector.
4. INSTALL NO. 1 EXHAUST PIPE SUPPORT BRACKET
(a) Install the No. 1 exhaust pipe support bracket to oil
pan sub-assembly with 2 new nuts.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(b) Loosen the No. 1 exhaust pipe support bracket
bolts.
(c) Install the clamp to No. 1 exhaust pipe support
bracket.
(d) Retighten the No. 1 exhaust pipe support bracket
bolts.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(e) Install the clamp with the bolt.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
A162482
Page 1226 of 3000
2GR-FE EXHAUST – EXHAUST PIPE (for 2WD)EX–7
EX
5. INSTALL TAIL EXHAUST PIPE ASSEMBLY
(a) Install a new gasket to the center exhaust pipe
assembly.
(b) Connect the 3 exhaust pipe supports, and install the
tail exhaust pipe assembly.
(c) Install 2 new bolts.
Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
6. INSTALL HEATED OXYGEN SENSOR (for Bank 1
Sensor 2) (See page EC-36)
7. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
8. INSPECT FOR EXHAUST GAS LEAK
If exhaust gas is leaking, repair the leak. Replace
damaged parts as necessary.
A162909
A162481
Page 1227 of 3000
2GR-FE EXHAUST – EXHAUST PIPE (for 4WD)EX–7
EX
ENGINE
2GR-FE EXHAUST
EXHAUST PIPE (for 4WD)
COMPONENTS
A162160E01
Page 1228 of 3000
EX–82GR-FE EXHAUST – EXHAUST PIPE (for 4WD)
EX
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
2. REMOVE HEATED OXYGEN SENSOR (for Bank 1
Sensor 2) (See page EC-38)
3. REMOVE TAIL EXHAUST PIPE ASSEMBLY
(a) Remove the 2 bolts.
(b) Disconnect the 4 exhaust pipe supports and remove
the tail exhaust pipe assembly.
(c) Remove the gasket from the center exhaust pipe
assembly.
4. REMOVE CENTER EXHAUST PIPE ASSEMBLY
(a) Remove the 2 bolts and 2 nuts.
A162161
Page 1229 of 3000
2GR-FE EXHAUST – EXHAUST PIPE (for 4WD)EX–9
EX
(b) Disconnect the 2 exhaust pipe supports and remove
the center exhaust pipe assembly.
(c) Remove the gaskets from the center exhaust pipe
assembly and the front exhaust pipe assembly.
5. REMOVE FRONT EXHAUST PIPE ASSEMBLY
(a) Disconnect the heated oxygen sensor (for bank 2
sensor 2) connector.
(b) Remove the 4 nuts and front exhaust pipe
assembly.
A162162
A162163
Page 1230 of 3000
EX–102GR-FE EXHAUST – EXHAUST PIPE (for 4WD)
EX
(c) Remove the gasket from the front exhaust pipe
assembly.
6. REMOVE NO. 1 EXHAUST PIPE SUPPORT BRACKET
(a) Remove the bolt and No. 1 exhaust pipe support
bracket.
7. REMOVE HEATED OXYGEN SENSOR (for Bank 2
Sensor 2) (See page EC-38)
A162181
Page 1231 of 3000
2GR-FE EXHAUST – EXHAUST PIPE (for 4WD)EX–11
EX
INSTALLATION
1. INSTALL HEATED OXYGEN SENSOR (for Bank 2
Sensor 2) (See page EC-39)
2. INSTALL FRONT EXHAUST PIPE ASSEMBLY
(a) Install a new gasket to the front exhaust pipe
assembly.
(b) Install the front exhaust pipe assembly with the 2
nuts.
Torque: 62 N*m (632 kgf*cm, 46 ft.*lbf)
3. INSTALL CENTER EXHAUST PIPE ASSEMBLY
(a) Install 2 new gaskets to the center exhaust pipe
assembly.
(b) Connect the 2 exhaust pipe supports, and install the
center exhaust pipe assembly.
(c) Install 2 new bolts and 2 nuts.
Torque: Bolt
43 N*m (438 kgf*cm, 32 ft.*lbf)
Nut
62 N*m (632 kgf*cm, 46 ft.*lbf)
A162667
Page 1232 of 3000
EX–122GR-FE EXHAUST – EXHAUST PIPE (for 4WD)
EX4. INSTALL NO. 1 EXHAUST PIPE SUPPORT BRACKET
(a) Install the No. 1 exhaust pipe support bracket to oil
pan sub-assembly with 2 new nuts.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(b) Loosen the No. 1 exhaust pipe support bracket
bolts.
(c) Install the clamp to No. 1 exhaust pipe support
bracket.
(d) Retighten the No. 1 exhaust pipe support bracket
bolts.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(e) Install the clamp with a new bolt.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(f) Connect the heated oxygen sensor (for bank 2
sensor 2) connector.
A162162
A162668
