Page 865 of 3000

EM–482GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
(b) Install the exhaust manifold sub-assembly LH with
the 6 nuts in the order shown in the illustration.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
17. INSTALL NO. 2 EXHAUST MANIFOLD HEAT
INSULATOR
(a) Install the No. 2 insulator with the 3 bolts.
Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf)
18. INSTALL NO. 2 MANIFOLD STAY
(a) Install the No. 2 manifold stay with the bolt and nut
in the order shown in the illustration.
Torque: 34 N*m (347 kgf*cm, 25 ft.*lbf)
19. INSTALL OIL LEVEL GAUGE GUIDE SUB-
ASSEMBLY
(a) Install 2 new O-rings to the oil level gauge guide.
(b) Apply a light coat of engine oil to the O-rings.
(c) Push in the oil level gauge guide end into the guide
hole.
(d) Install the No. 1 oil level gauge guide with the bolt.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(e) Install the No. 2 oil level gauge guide with the bolt.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
(f) Install the oil level gauge.
20. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH
(a) Install a new gasket as shown in the illustration.
A129641E01
A140784
A140783E01
A155017
A129650E01
Page 866 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–49
EM
(b) Install the exhaust manifold sub-assembly RH with
the 6 nuts in the order shown in the illustration.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
21. INSTALL INTAKE MANIFOLD
NOTICE:
DO NOT apply oil to the bolts listed below:
(a) Set a new gasket on each cylinder head.
NOTICE:
• Align the port holes of the gasket and
cylinder head.
• Make sure that the gasket is installed in the
correct direction.
(b) Set the intake manifold on the cylinder heads.
(c) Install and tighten the 6 bolts and 4 nuts uniformly in
several steps.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
22. INSTALL NO. 2 ENGINE MOUNTING STAY RH
(a) Install the No. 2 mounting stay RH with the bolt.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
23. INSTALL IGNITION COIL ASSEMBLY
(a) Install the 6 ignition coil assemblies with the 6 bolts.
Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
24. INSTALL INTAKE AIR SURGE TANK ASSEMBLY
NOTICE:
DO NOT apply oil to the bolts listed below:
(a) Install a new gasket to the intake air surge tank.
(b) Using a 5 mm hexagon socket wrench, install the 4
bolts and 2 nuts.
Torque: Bolt
18 N*m (184 kgf*cm, 13 ft.*lbf)
Nut
16 N*m (163 kgf*cm, 12 ft.*lbf)
(c) Install the throttle body bracket, No. 1 surge tank
stay and 4 bolts.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
A140781E01
Tightening Parts
Intake Manifold and Cylinder Head Sub-assembly RH
Intake Manifold and Cylinder Head Sub-assembly LH
A134933
A162388
Tightening Parts
Surge Tank and Intake Manifold
No. 1 Surge Tank Stay and Cylinder Head Cover
No. 1 Surge Tank Stay and Surge Tank
Throttle Body Bracket and Cylinder Head Cover
Throttle Body Bracket and Surge Tank
A139209
Page 867 of 3000
EM–502GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
(d) Connect the connector.
(e) Connect the No. 1 ventilation hose.
(f) Install the clamp and connect the throttle with motor
body assembly connector.
(g) Connect the vapor feed hose.
(h) Connect the 2 water by-pass hoses to the throttle
with motor body assembly.
25. INSTALL VENTILATION HOSE
(a) Using pliers, grip the claws of the 2 clips and slide
the 2 clips to the intake air surge tank assembly and
ventilation valve.
26. INSTALL ENGINE HANGERS
(a) Install the 4 bolts, and 2 engine hangers.
27. REMOVE ENGINE STAND
28. INSTALL DRIVE PLATE AND RING GEAR SUB-
ASSEMBLY (See page EM-13)
29. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for
2WD)
HINT:
See page AX-166.
30. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY (for
4WD)
HINT:
(See page AX-167).
31. INSTALL TRANSFER STIFFENER PLATE RH (See
page AX-168)
A129467
A129464E04
A162372
A129635E01
Page 868 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–51
EM
32. INSTALL MANIFOLD STAY
(a) Install the bolt, nut, and manifold stay.
Torque: 34 N*m (347 kgf*cm, 25 ft.*lbf)
33. INSTALL ENGINE FRONT MOUNTING BRACKET
(See page AX-167)
34. INSTALL STARTER ASSEMBLY (See page ST-13)
35. INSTALL ENGINE WIRE
36. INSTALL FRONT DRIVE SHAFT ASSEMBLY LH (See
page DS-17)
37. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH (for
2WD) (See page DS-17)
38. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH (for
4WD) (See page DS-17)
39. INSTALL FRONT FRAME ASSEMBLY
(a) Install the engine mounting insulators RH and LH
with the 2 nuts.
Torque: 95 N*m (969 kgf*cm, 70 ft.*lbf)
(b) Install the engine mounting insulator FR with the
bolt.
Torque: 87 N*m (887 kgf*cm, 64 ft.*lbf)
A155023
A163266E01
A155019
Page 869 of 3000
EM–522GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
(c) Install the engine mounting insulator RR with the 2
bolts.
Torque: 78 N*m (795 kgf*cm, 58 ft.*lbf)
(d) Connect the connector and clamp.
40. INSTALL POWER STEERING LINK (See page PS-39)
41. INSTALL FRONT STABILIZER BAR
HINT:
(See page SP-36).
42. REMOVE ENGINE HANGERS
(a) Remove the 4 bolts and 2 engine hangers.
43. INSTALL VANE PUMP ASSEMBLY
(a) Install the vane pump with the 2 bolts and nut.
Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
(b) Install the 2 pressure feed tube clamp nuts.
Torque: 7.8 N*m (80 kgf*cm, 69 in.*lbf)
(c) Connect the power steering oil pressure switch
connector.
44. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE
(a) Set the engine assembly with transaxle on the
engine lifter.
(b) Install the engine assembly to the vehicle.
A155018
A155022
A129635E01
A139216
A155024
Page 870 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–53
EM
(c) Install the frame side rail plates RH and LH with the
6 bolts and 2 nuts.
Torque: A
85 N*m (867 kgf*cm, 63 ft.*lbf)
B
32 N*m (329 kgf*cm, 24 ft.*lbf)
(d) Install the front suspension member brace rear RH
and LH with the 6 bolts and 2 nuts.
Torque: A
85 N*m (867 kgf*cm, 63 ft.*lbf)
B
32 N*m (329 kgf*cm, 24 ft.*lbf)
45. RECONNECT SUCTION HOSE SUB-ASSEMBLY (See
page AC-231)
46. RECONNECT DISCHARGE HOSE SUB-ASSEMBLY
(See page AC-232)
47. INSTALL STEERING INTERMEDIATE SHAFT SUB-
ASSEMBLY (See page SR-10)
48. INSTALL FRONT AXLE ASSEMBLY LH (See page DS-
18)
49. INSTALL FRONT AXLE ASSEMBLY RH
HINT:
Use the same procedures described for the LH side.
50. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM
LH (See page DS-18)
51. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM
RH
HINT:
Use the same procedures described for the LH side.
52. INSTALL TIE ROD ASSEMBLY LH (See page DS-18)
53. INSTALL TIE ROD ASSEMBLY RH
HINT:
Use the same procedures described for the LH side.
54. INSTALL FRONT SPEED SENSOR LH (See page DS-
18)
55. INSTALL FRONT SPEED SENSOR RH
HINT:
Use the same procedures described for the LH side.
56. INSTALL FRONT AXLE HUB NUT LH (See page DS-
19)
57. INSTALL FRONT AXLE HUB NUT RH
HINT:
Use the same procedures described for the LH side.
A162364
A162363
Page 871 of 3000
EM–542GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLY
EM
58. INSTALL FRONT STABILIZER LINK ASSEMBLY LH
(See page DS-19)
59. INSTALL FRONT STABILIZER LINK ASSEMBLY RH
HINT:
Use the same procedures described for the LH side.
60. INSTALL PROPELLER WITH CENTER BEARING
SHAFT ASSEMBLY (See page PR-9)
61. FULLY TIGHTEN PROPELLER WITH CENTER
BEARING SHAFT ASSEMBLY (See page PR-10)
62. INSTALL FRONT EXHAUST PIPE ASSEMBLY (for
2WD)
(a) Install the front exhaust pipe assembly (See page
EX-4).
63. INSTALL FRONT EXHAUST PIPE ASSEMBLY (for
4WD)
(a) Install front exhaust pipe assembly (See page EX-
10).
64. INSTALL CENTER EXHAUST PIPE ASSEMBLY
(a) Install center exhaust pipe assembly (See page EX-
10).
65. CONNECT ENGINE WIRE
(a) Install the 2 bolts and 2 ground cables.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
A163267
Page 872 of 3000
2GR-FE ENGINE MECHANICAL – ENGINE ASSEMBLYEM–55
EM
(b) Install the bolt and 2 clamps to the body.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
(c) Connect the wire to the engine room junction block.
Then, install it with the nut.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
(d) Install the engine wire to the body with the 2 nuts.
Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
66. CONNECT NO. 1 OIL RESERVOIR TO PUMP HOSE
(a) Using pliers, grip the claws of the clip and slide the
clip to connect the No. 1 oil reservoir to pump hose
to the oil reservoir tank.
67. CONNECT RETURN TUBE SUB-ASSEMBLY
(a) Using pliers, grip the claws of the 2 clips and slide
the 2 clips to connect 2 return tube sub-assemblies.
NOTICE:
Take care not to damage the hose protector.
68. CONNECT TRANSMISSION CONTROL CABLE
ASSEMBLY
(a) Connect the control cable to the control cable
clamp.
A155030
A155037
A155029
A052327
C090579
