TOYOTA SIENNA 2007 Service Repair Manual AIR CONDITIONING – AIR CONDITIONING UNITAC–185 AC 25. REMOVE ECM (See page ES-498) 26. REMOVE FRONT FENDER GARNISH RH HINT: See page ET-35. 27. REMOVE INSTRUMENT PANEL REINFORCEMENT (a) Remove t

Page 2930 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AC–186AIR CONDITIONING – AIR CONDITIONING UNIT AC 28. REMOVE LOWER DEFROSTER NOZZLE ASSEMBLY (a) Release the 4 claw fittings and remove the lower defroster nozzle assembly. 29. REMOVE AIR CONDI

Page 2931 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AIR CONDITIONING – AIR CONDITIONING UNITAC–187 AC 4. REMOVE NO. 2 AIRMIX DAMPER SERVO SUB- ASSEMBLY (for Automatic Air Conditioning System) (a) Remove the 3 screws and the No. 2 airmix damper s

Page 2932 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AC–188AIR CONDITIONING – AIR CONDITIONING UNIT AC 9. REMOVE COOLER EXPANSION VALVE (a) Remove the cooler expansion valve from the No. 1 cooler evaporator sub-assembly. (b) Remove the 2 O-rings

Page 2933 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AIR CONDITIONING – AIR CONDITIONING UNITAC–189 AC 13. REMOVE NO. 1 AIR DUCT (a) Release the 4 claw fittings and remove the No. 1 air duct. 14. REMOVE NO. 1 COOLER THERMISTOR (a) Disengage the c

Page 2934 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AC–26AIR CONDITIONING – AIR CONDITIONING SYSTEM (for Automatic Air Conditioning Sys- tem) AC DESCRIPTION This sensor detects the cabin temperature that is used as the basis for temperature contr

Page 2935 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AIR CONDITIONING – AIR CONDITIONING SYSTEM (for Automatic Air Conditioning Sys- tem)AC–27 AC (c) Select the item below in the DATA LIST, and read the display on the intelligent tester. DATA LIS

Page 2936 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AC–28AIR CONDITIONING – AIR CONDITIONING SYSTEM (for Automatic Air Conditioning Sys- tem) AC NG OK (a) Disconnect the connector from the A/C amplifier. (b) Disconnect the connector from the A/C
