TOYOTA SIENNA 2007 Service Repair Manual CO–342GR-FE COOLING – RADIATOR
CO
24. REMOVE RADIATOR ASSEMBLY WITH FAN
SHROUD AND FAN MOTOR
(a) Remove the 2 bolts and separate the condenser
assembly from the radiator assembly with fan
shr

Page 1250 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE COOLING – RADIATORCO–35
CO
28. DISCONNECT INLET SUB-ASSEMBLY
(a) Disconnect the inlet hose from the radiator.
(b) Remove the bolt and inlet sub-assembly from the
radiator.
DISASSEMBLY
1.

Page 1251 of 3000

TOYOTA SIENNA 2007 Service Repair Manual CO–362GR-FE COOLING – RADIATOR
CO
(c) Using SST, uncrimp the lock plate by squeezing the
handle until stopped by the stopper bolt.
SST 09230-01010
(d) Lightly tap the bracket of the radiator (o

Page 1252 of 3000

TOYOTA SIENNA 2007 Service Repair Manual CO–62GR-FE COOLING – COOLANT
CO
COOLANT
REPLACEMENT
1. REMOVE NO. 1 ENGINE UNDER COVER (See page
EM-26)
2. REMOVE V-BANK COVER SUB-ASSEMBLY (See
page EM-28)
3. DRAIN ENGINE COOLANT
(a) Loosen

Page 1253 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE COOLING – COOLANTCO–7
CO
4. ADD ENGINE COOLANT
(a) Tighten the radiator drain cock plug by hand.
(b) Tighten the 2 cylinder block drain cock plugs.
Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf)

Page 1254 of 3000

TOYOTA SIENNA 2007 Service Repair Manual CO–82GR-FE COOLING – COOLANT
CO
(j) Bleed air from the cooling system.
(1) Warm up the engine until the thermostat opens.
While the thermostat is open, circulate the
coolant for several minute

Page 1255 of 3000

TOYOTA SIENNA 2007 Service Repair Manual 2GR-FE COOLING – RADIATORCO–37
CO
REASSEMBLY
1. INSTALL LOWER RADIATOR TANK
(a) After checking that there are no foreign objects in
the lock plate groove, install a new O-ring without
twisting

Page 1256 of 3000

TOYOTA SIENNA 2007 Service Repair Manual CO–382GR-FE COOLING – RADIATOR
CO
(e) Lightly press SST against the lock plate in the order
shown in the illustration. After repeating this
procedure a few times, fully crimp the lock plate by
