(j) Remove the bolt and bracket.
DISASSEMBLY
1. REMOVE GENERATOR CLUTCH PULLEY
(a) Using a screwdriver, remove the generator pulley
cap.
(b) Set SST (A) and (B).
SST 09820-63020
(c) Clamp SST (A) in a vise.
NOTICE:
Be sure to fix the flat surface of SST (A) in a
vise.
A162685
A128068E01
A128069E01
A160961E01
Page 1354 of 3000
2GR-FE CHARGING – GENERATORCH–19
CH
(d) Place the rotor shaft end into SST (A).
(e) Fit SST (B) to the clutch pulley.
(f) Loosen the pulley by turning SST (B) in the direction
shown in the illustration.
NOTICE:
Hold the generator assembly tightly.
(g) Remove the generator assembly from SST.
(h) Remove the clutch pulley from the rotor shaft.
2. REMOVE GENERATOR REAR END COVER
(a) Place the generator assembly on the clutch pulley.
(b) Remove the 3 nuts and generator rear end cover.
A135194E01
A135195E01
A135196E01
A135197
A128071
Page 1355 of 3000
CH–202GR-FE CHARGING – GENERATOR
CH
3. REMOVE GENERATOR TERMINAL INSULATOR
(a) Remove the terminal insulator from the generator
coil.
4. REMOVE GENERATOR BRUSH HOLDER ASSEMBLY
(a) Remove the 2 screws and brush holder from the
generator coil.
5. REMOVE GENERATOR COIL ASSEMBLY
(a) Remove the 4 bolts.
(b) Using SST, remove the generator coil assembly.
SST 09950-40011 (09951-04020, 09952-04010,
09953-04020, 09954-04010, 09955-04071,
09957-04010, 09958-04011)
6. REMOVE GENERATOR ROTOR ASSEMBLY
(a) Remove the generator washer.
A128072
A128073
A128074
A118275E01
A118365E01
Page 1356 of 3000

CH–162GR-FE CHARGING – GENERATOR
CH
REMOVAL
1. REMOVE V-BANK COVER SUB-ASSEMBLY (See
page EM-28)
2. REMOVE FRONT WHEEL RH
3. REMOVE NO. 1 ENGINE UNDER COVER (See page
EM-26)
4. REMOVE FRONT FENDER APRON SEAL RH (See
page EM-26)
5. DRAIN ENGINE COOLANT (See page CO-6)
6. REMOVE NO. 2 AIR CLEANER INLET (See page EM-
28)
7. REMOVE BATTERY (See page EM-26)
8. REMOVE FRONT BUMPER ASSEMBLY (See page
ET-3)
9. REMOVE FRONT BUMPER ENERGY ABSORBER
10. REMOVE NO. 1 AIR CLEANER INLET (See page EM-
28)
11. DISCONNECT RADIATOR RESERVE TANK HOSE OR
PIPE (See page CO-28)
12. DISCONNECT NO. 1 RADIATOR HOSE (See page CO-
28)
13. DISCONNECT NO. 2 RADIATOR HOSE (See page CO-
29)
14. REMOVE HOOD LOCK RELEASE LEVER
PROTECTOR (See page CO-29)
15. REMOVE HOOD LOCK ASSEMBLY (See page CO-29)
16. REMOVE HOOD LOCK SUPPORT SUB-ASSEMBLY
(See page CO-29)
17. DISCONNECT COOLING FAN ECU CONNECTOR
(See page CO-30)
18. REMOVE RADIATOR UPPER SUPPORT SUB-
ASSEMBLY (See page CO-30)
19. DISCONNECT NO. 2 OIL COOLER OUTLET TUBE
SUB-ASSEMBLY (See page CO-31)
20. REMOVE HEADLIGHT ASSEMBLY RH (See page LI-
69)
21. REMOVE RADIATOR SIDE DEFLECTOR RH (See
page CO-31)
22. REMOVE HEADLIGHT BRACKET RH (See page CO-
32)
23. REMOVE PRESSURE FEED TUBE ASSEMBLY (See
page CO-32)
Page 1357 of 3000
2GR-FE CHARGING – GENERATORCH–17
CH
24. REMOVE RADIATOR SUPPORT CUSHION (See page
CO-32)
25. REMOVE NO. 1 RADIATOR SUPPORT (See page CO-
32)
26. REMOVE RADIATOR ASSEMBLY WITH FAN
SHROUD AND FAN MOTOR (See page CO-33)
27. REMOVE V-RIBBED BELT (See page EM-6)
28. REMOVE GENERATOR ASSEMBLY
(a) Remove the terminal cap.
(b) Remove the nut and disconnect the wire harness
from terminal B.
(c) Disconnect the generator connector from the
generator assembly.
(d) Disconnect the connector from the compressor and
magnetic clutch.
(e) Disconnect the 2 wire harness clamps.
(f) Remove the 2 bolts.
(g) Remove the bolt from the cylinder block.
(h) Disconnect the wire harness clamp and remove the
generator assembly.
(i) Remove the bolt and wire harness clamp stay.
A162681
A162682
A162683E01
A162684
