TIRE AND WHEEL – TIRE PRESSURE WARNING ECUTW–89
TW
(b) Install the tire pressure warning ECU with the screw.
2. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-
ASSEMBLY
HINT:
Refer to the instructions for INSTALLATION of the
instrument panel safety pad (See page IP-14).
3. CONNECT CABLE TO BATTERY NEGATIVE
TERMINAL
4. REGISTER TRANSMITTER ID
HINT:
See page TW-20.
5. INSPECT TIRE PRESSURE WARNING SYSTEM
HINT:
See page TW-25.
6. INITIALIZE SYSTEM
NOTICE:
• Be sure to register the transmitter IDs of all tires
in the ECU before initialization.
• Be sure to inflate all tires to the proper inflation
pressure before initialization.
HINT:
See page TW-23.
C156706
Page 2346 of 3000

TIRE AND WHEEL – TIRE PRESSURE WARNING SYSTEMTW–31
TW
PROBLEM SYMPTOMS TABLE
HINT:
• Use the table below to help determine the cause of the
problem symptom. The potential causes of the symptoms
are listed in order of probability in the "Suspected Area"
column of the table. Check each symptom by checking the
suspected areas in the order they are listed. Replace parts
as necessary.
• Inspect the fuses and relays related to this system before
inspecting the suspected areas below.
TIRE PRESSURE WARNING SYSTEM:
Symptom Suspected Area See page
Tire pressure warning light does not illuminate, despite
tire pressure decreasingInitializationTW-23
Check DATA LIST (Tire inflation pressure)TW-35
ID code check (Registration)TW-20
Tire pressure warning light illuminated (Goes off during
initial check)ECU power source circuitTW-77
Tire pressure warning light circuitTW-74
Tire pressure warning light illuminated (Comes on
during initial check)Check DATA LIST (Tire inflation pressure)TW-35
Tire pressure warning light circuitTW-74
ID code check (Registration)TW-20
Initialization cannot be done Tire pressure reset switch circuitTW-72
DTC check cannot be doneECU power source circuitTW-77
TC and CG terminal circuitTW-79
Page 2347 of 3000

TW–32TIRE AND WHEEL – TIRE PRESSURE WARNING SYSTEM
TW
TERMINALS OF ECU
1. CHECK TIRE PRESSURE WARNING ECU
HINT:
Inspect the connectors from the back side while the
connectors are connected.
(a) Disconnect the tire pressure warning antenna and
receiver connector.
(b) Measure the voltage according to the value(s) in the
table below.
(c) Connect the tire pressure warning antenna and
receiver connector.
(d) Measure the voltage and resistance according to
the value(s) in the table below. If the result is not as
specified, the ECU may have a malfunction.
E129452E15
Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
T15-1 (CLSW) - T15-9 (GND) L-O - W-BTire pressure warning
reset switch• Ignition switch ON
• Tire pressure warning
reset switch on8.5 to 15 V
T15-1 (CLSW) - T15-9 (GND) L-O - W-BTire pressure warning
reset switch• Ignition switch ON
• Tire pressure warning
reset switch OFFBelow 1.5 V
T15-2 (SPD) - T15-9 (GND) V-W - W-B Vehicle speed signal Vehicle is running Pulse generation
T15-5 (IND) - T15-9 (GND) GR-L - W-BTire pressure warning light
output signal• Ignition switch ON
• Tire pressure warning
light offBelow 0.5 V
T15-5 (IND) - T15-9 (GND) GR-L - W-BTire pressure warning
reset switchAfter ignition switch is
turned ON, tire pressure
warning light illuminates
for 3 seconds.2.2 to 4.4 V
T15-6 (RF5V) - T15-9 (GND) P-L - W-BTire pressure warning
antenna and receiver
power sourceIgnition switch ON 11 to 14 V
T15-7 (IG) - T15-9 (GND) B-R - W-B IG power source Ignition switch ON 11 to 14 V
T15-10 (SIL) - T15-9 (GND) W - W-B Diagnostic communication Ignition switch ON 8 to 14 V
T15-11 (GND2) - T15-9 (GND) P - W-BTire pressure warning
antenna and receiver
groundAlways Below 1
T15-12 (RDA) - T15-9 (GND) G-B - W-BTire pressure warning
antenna and receiver
signalIgnition switch ON 11 to 14 V
Page 2348 of 3000
TIRE AND WHEEL – TIRE PRESSURE WARNING SYSTEMTW–33
TW
(e) Using an oscilloscope, check the waveform 1.
(1) Waveform 1 (Reference)
(2) Waveform 2 (Reference)
F047507E08
Item Contents
Terminal SPD - GND
Tool setting 5 V/DIV, 200 ms./DIV.
Vehicle condition While driving at approximately 12 mph (20 km/h)
C107353E04
Item Contents
Terminal SIL - Body ground
Tool setting 5 V/DIV., 1 ms./DIV.
Vehicle condition Communicating using intelligent tester
Page 2349 of 3000
TW–90TIRE AND WHEEL – TIRE PRESSURE WARNING RESET SWITCH
TW
SUSPENSION & AXLE
TIRE AND WHEEL
TIRE PRESSURE WARNING RESET SWITCH
COMPONENTS
C155499E01
Page 2350 of 3000
TIRE AND WHEEL – TIRE PRESSURE WARNING RESET SWITCHTW–91
TW
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
2. REMOVE FRONT DOOR SCUFF PLATE LH
3. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH
4. REMOVE LOWER INSTRUMENT PANEL FINISH
PANEL SUB-ASSEMBLY LH (See page IP-6)
5. REMOVE TIRE PRESSURE WARNING RESET
SWITCH
(a) Disengage the 2 claws and remove the tire pressure
warning reset switch from the lower instrument
panel finish panel sub-assembly LH.
INSPECTION
1. INSPECT TIRE PRESSURE WARNING RESET
SWITCH
(a) Remove the tire pressure warning reset switch.
(b) Measure the resistance between terminals 1 and 2
of the tire pressure warning reset switch when the
tire pressure warning switch is ON and OFF.
Standard resistance
If the result is not as specified, replace the tire
pressure warning reset switch.
C156708
C107260E01Switch Condition Specified Condition
ON Below 1
OFF 10 k or higher
Page 2351 of 3000
TW–92TIRE AND WHEEL – TIRE PRESSURE WARNING RESET SWITCH
TW
INSTALLATION
1. INSTALL TIRE PRESSURE WARNING RESET
SWITCH
(a) Engage the 2 claws to install the tire pressure
warning reset switch to the lower instrument panel
finish panel sub-assembly LH.
2. INSTALL LOWER INSTRUMENT PANEL FINISH
PANEL SUB-ASSEMBLY LH
3. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH
4. INSTALL FRONT DOOR SCUFF PLATE LH
5. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
6. INSPECT TIRE PRESSURE WARNING SYSTEM
HINT:
See page TW-25.
C156708
Page 2352 of 3000

TW–34TIRE AND WHEEL – TIRE PRESSURE WARNING SYSTEM
TW
DIAGNOSIS SYSTEM
1. CHECK BATTERY VOLTAGE
Standard voltage:
11 to 14 V
If the voltage is below 11 V, recharge the battery before
proceeding.
2. CHECK DLC3
(a) The ECU uses the ISO 15765-4 for communication
protocol. The terminal arrangement of the DLC3
complies with SAE J1962 and matches the ISO
15765-4 format.
NOTICE:
*: Before measuring the resistance, leave the
vehicle as is for at least 1 minute and do not
operate the ignition switch, any other switches
or the doors.
(b) If the result is not as specified, DLC3 may have a
malfunction. Repair or replace the harness and
connector.
HINT:
Connect the cable of the intelligent tester to DLC3,
turn the ignition switch to the ON position and
attempt to use the tester. If the display indicates that
a communication error has occurred, there is a
problem either with the vehicle or with the tester.
• If communication is normal when the tester is
connected to another vehicle, inspect DLC3 of
the original vehicle.
• If communication is still not possible when the
tester is connected to another vehicle, the
problem may be in the tester itself. Consult the
Service Department listed in the tester's
instruction manual.
H100769E16
Symbols (Terminal No.) Terminal Description Condition Specified Condition
SIL (7) - SG (5) Bus "+" line During transmission Pulse generation
CG (4) - Body ground Chassis ground Always Below 1
SG (5) - Body ground Signal ground Always Below 1
BAT (16) - Body ground Battery positive Always 11 to 14 V
CANH (6) - CANL (14) CAN bus line Ignition switch off* 54 to 69
CANH (6) - CG (4) HIGH-level CAN bus line Ignition switch off* 200 or higher
CANL (14) - CG (4) LOW-level CAN bus line Ignition switch off* 200
or higher
CANH (6) - BAT (16) HIGH-level CAN bus line Ignition switch off* 6 k
or higher
CANL (14) - BAT (16) LOW-level CAN bus line Ignition switch off* 6 k
or higher
