31. INSPECT CRANKSHAFT THRUST CLEARANCE
(a) Install the crankshaft bearing cap (See page EM-
126).
(b) Using a dial indicator, measure the thrust clearance
while prying the crankshaft back and forth with a
screwdriver.
Standard thrust clearance:
0.04 to 0.24 mm (0.0016 to 0.0094 in.)
Maximum thrust clearance:
0.30 mm (0.0118 in.)
If the thrust clearance is greater than the maximum,
replace the thrust washers as a set. If necessary,
replace the crankshaft.
Thrust washer thickness:
2.43 to 2.48 mm (0.0957 to 0.0976 in.)
32. INSPECT CYLINDER BLOCK FOR WARPAGE
(a) Using a precision straight edge and feeler gauge,
measure the warpage of the contact surface of the
cylinder head gasket.
Maximum warpage:
0.07 mm (0.0028 in.)
If the warpage is greater than the maximum, replace
the cylinder block.
33. INSPECT CYLINDER BORE
(a) Visually check the cylinder for vertical scratches.
If deep scratches are present, rebore all the 6
cylinders. If necessary, replace the cylinder block.
A131818
A131819
A131820
Page 1066 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–119
EM
(b) Using a cylinder gauge, measure the cylinder bore
diameter at positions A and B in the thrust and axial
directions.
Standard diameter:
94.000 to 94.012 mm (3.7008 to 3.7013 in.)
Maximum diameter:
94.200 mm (3.7087 in.)
If the average diameter of 4 positions is greater than
the maximum, replace the cylinder block.
34. INSPECT PISTON SUB-ASSEMBLY WITH PIN
(a) Using a micrometer, measure the piston diameter at
right angles to the piston center line where the
distance from the piston end is as specified.
Distance:
9.8 mm (0.3858 in.)
Standard diameter:
93.960 to 93.980 mm (3.6992 to 3.7000 in.)
Maximum diameter:
93.830 mm (3.6941 in.)
35. INSPECT PISTON OIL CLEARANCE
(a) Measure the cylinder bore diameter in the thrust
directions.
(b) Subtract the piston diameter measurement from the
cylinder bore diameter measurement.
Standard oil clearance:
0.020 to 0.052 mm (0.0008 to 0.0020 in.)
Maximum oil clearance:
0.060 mm (0.0024 in.)
If the oil clearance is greater than the maximum,
replace all the pistons. If necessary, replace the
cylinder block.
A130802E03
A131821E02
Page 1067 of 3000

EM–1202GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
36. INSPECT RING GROOVE CLEARANCE
(a) Using a feeler gauge, measure the clearance
between a new piston ring and the wall of the ring
groove.
Ring groove clearance
If the clearance is not as specified, replace the
piston.
37. INSPECT PISTON RING END GAP
(a) Insert the piston ring into the cylinder bore.
(b) Using a piston, push the piston ring a little beyond
the bottom of the ring travel, 110 mm (4.33 in.) from
the top of the cylinder block.
(c) Using a feeler gauge, measure the end gap.
Standard end gap
Maximum end gap
If the end gap is greater than the maximum, replace
the piston ring. If the end gap is greater than the
maximum even with a new piston ring, rebore all the
6 cylinders or replace the cylinder block.
38. INSPECT PISTON PIN OIL CLEARANCE
(a) Using a caliper gauge, measure the inside diameter
of the piston pin hole.
Piston pin hole inside diameter
A131822
Item Clearance
No. 1 0.020 to 0.070 mm (0.0008 to 0.0028 in.)
No. 2 0.020 to 0.060 mm (0.0008 to 0.0024 in.)
Oil 0.070 to 0.150 mm (0.0028 to 0.0059 in.)
A106218E02
A109687
Item End Gap
No. 1 0.25 to 0.35 mm (0.0098 to 0.0138 in.)
No. 2 0.50 to 0.60 mm (0.0197 to 0.0236 in.)
Oil 0.10 to 0.40 mm (0.0039 to 0.0157 in.)
Item End Gap
No. 1 0.50 mm (0.0197 in.)
No. 2 0.85 mm (0.0335 in.)
Oil 0.60 mm (0.0236 in.)
A131823
Mark Diameter
A 22.001 to 22.004 mm (0.8662 to 0.8663 in.)
B 22.004 to 22.007 mm (0.8663 to 0.8664 in.)
C 22.007 to 22.010 mm (0.8664 to 0.8665 in.)
Page 1068 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–121
EM
(b) Using a micrometer, measure the piston pin
diameter.
Piston pin diameter
(c) Subtract the piston pin diameter measurement from
the piston pin hole diameter measurement.
Standard oil clearance:
0.001 to 0.007 mm (0.00004 to 0.00028 in.)
Maximum oil clearance:
0.015 mm (0.0006 in.)
If the oil clearance is greater than the maximum,
replace the piston and piston pin as a set.
(d) Using a caliper gauge, measure the inside diameter
of the connecting rod bushing.
Bushing inside diameter
(e) Subtract the piston pin diameter measurement from
the bushing inside diameter measurement.
Standard oil clearance:
0.005 to 0.011 mm (0.0002 to 0.0004 in.)
Maximum oil clearance:
0.030 mm (0.0012 in.)
If the oil clearance is greater than the maximum,
replace the bushing. If necessary, replace the
connecting rod and piston pin as a set.
A106219E02
Mark Diameter
A 21.997 to 22.000 mm (0.8660 to 0.8661 in.)
B 22.000 to 22.003 mm (0.8661 to 0.8663 in.)
C 22.003 to 22.006 mm (0.8663 to 0.8664 in.)
A109689
Mark Diameter
A 22.005 to 22.008 mm (0.8663 to 0.8665 in.)
B 22.009 to 22.011 mm (0.8665 to 0.8666 in.)
C 22.012 to 22.014 mm (0.8666 to 0.8667 in.)
A131824E01
Page 1069 of 3000

EM–1222GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
39. INSPECT CONNECTING ROD
(a) Using a rod aligner and feeler gauge, check the
connecting rod alignment.
(1) Check for out-of-alignment.
Maximum out-of-alignment:
0.05 mm (0.0020 in.) per 100 mm (3.94 in.)
If the out-of-alignment is greater than the
maximum, replace the connecting rod
assembly.
(2) Check for twist.
Maximum twist:
0.15 mm (0.0059 in.) per 100 mm (3.94 in.)
If the twist is greater than the maximum,
replace the connecting rod assembly.
40. INSPECT CONNECTING ROD BOLT
(a) Using vernier calipers, measure the tension portion
diameter of the bolt.
Standard diameter:
7.2 to 7.3 mm (0.284 to 0.287 in.)
Minimum diameter:
7.0 mm (0.276 in.)
If the diameter is less than the minimum, replace the
bolt.
41. INSPECT CRANKSHAFT
(a) Inspect for circle runout.
(1) Clean the crank journal.
(2) Place the crankshaft on V-blocks.
(3) Using a dial indicator, measure the circle runout
at the center journal.
Maximum circle runout:
0.06 mm (0.0024 in.)
If the circle runout is greater than the
maximum, replace the crankshaft.
A109690
A109691E01
A109692
A109693
Page 1070 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–123
EM
(b) Inspect the main journals.
(1) Using a micrometer, measure the diameter of
each main journal.
Standard journal diameter:
60.988 to 61.000 mm (2.4011 to 2.4016 in.)
If the diameter is not as specified, check the oil
clearance. If necessary, replace the crankshaft.
(2) Check each main journal for taper and out-of-
round as shown in the illustration.
Maximum taper and out-of-round:
0.02 mm (0.0008 in.)
If the taper and out-of-round is greater than the
maximum, replace the crankshaft.
(c) Inspect the crank pin.
(1) Using a micrometer, measure the diameter of
each crank pin.
Crankshaft pin diameter:
52.992 to 53.000 mm (2.0863 to 2.0866 in.)
If the diameter is not as specified, check the oil
clearance. If necessary, replace the crankshaft.
(2) Check each crank pin for taper and out-of-
round as shown in the illustration.
Maximum taper and out-of-round:
0.02 mm (0.0008 in.)
If the taper and out-of-round is greater than the
maximum, replace the crankshaft.
42. INSPECT CRANKSHAFT OIL CLEARANCE
(a) Check the crank journal and bearing for pitting and
scratches.
(b) Install the crankshaft bearing (See page EM-126).
(c) Place the crankshaft on the cylinder block.
(d) Lay a strip of Plastigage across each journal.
(e) Examine the front marks and numbers and install
the bearing caps on the cylinder block.
HINT:
A number is marked on each main bearing cap to
indicate the installation position.
(f) Install the main bearing cap (See page EM-126).
NOTICE:
Do not turn the crankshaft.
(g) Remove the main bearing caps (See page EM-76).
(h) Measure the Plastigage at its widest point.
Standard oil clearance:
0.026 to 0.047 mm (0.0010 to 0.0019 in.)
Maximum oil clearance:
0.050 mm (0.0020 in.)
If the oil clearance is greater than the maximum,
replace the bearings. If necessary, replace the
crankshaft.
NOTICE:
Completely remove the Plastigage after the
measurement.
A109694
A109695
A122109E01
A131830E01
Page 1071 of 3000

EM–1242GR-FE ENGINE MECHANICAL – ENGINE UNIT
EM
(i) If replacing a bearing, replace it with one having the
same number. If the number of the bearing cannot
be determined, select the correct bearing by adding
together the numbers imprinted on the cylinder
block and crankshaft, then refer to the table below
for the appropriate bearing number. There are 5
sizes of standard bearings, marked "1", "2", "3", "4"
and "5" accordingly.
Journal bearings:
HINT:
EXAMPLE: Cylinder block "11" + Crankshaft "06" =
Total number 17 (Use bearing "3")
Crankshaft main journal diameter
Standard upper bearing center wall thickness
(No. 1 and No. 4 journal)
Standard lower bearing center wall thickness
(No. 1 and No. 4 journal)
A125230E02
Cylinder
block +
Crankshaft0 - 5 6 - 11 12 - 17 18 - 23 24 - 28
Bearing to
be used"1" "2" "3" "4" "5"
Mark Diameter
"00" 60.999 to 61.000 mm (2.4015 to 2.4016 in.)
"01" 60.998 to 60.999 mm (2.4015 to 2.4015 in.)
"02" 60.997 to 60.998 mm (2.4015 to 2.4015 in.)
"03" 60.996 to 60.997 mm (2.4014 to 2.4015 in.)
"04" 60.995 to 60.996 mm (2.4014 to 2.4014 in.)
"05" 60.994 to 60.995 mm (2.4013 to 2.4014 in.)
"06" 60.993 to 60.994 mm (2.4013 to 2.4013 in.)
"07" 60.992 to 60.993 mm (2.4013 to 2.4013 in.)
"08" 60.991 to 60.992 mm (2.4012 to 2.4013 in.)
"09" 60.990 to 60.991 mm (2.4012 to 2.4012 in.)
"10" 60.989 to 60.990 mm (2.4011 to 2.4012 in.)
"11" 60.988 to 60.989 mm (2.4011 to 2.4011 in.)
Mark Thickness
"1" 2.500 to 2.503 mm (0.0984 to 0.0985 in.)
"2" 2.503 to 2.506 mm (0.0985 to 0.0987 in.)
"3" 2.506 to 2.509 mm (0.0987 to 0.0988 in.)
"4" 2.509 to 2.512 mm (0.0988 to 0.0989 in.)
"5" 2.512 to 2.515 mm (0.0989 to 0.0990 in.)
Mark Thickness
"1" 2.478 to 2.481 mm (0.0976 to 0.0977 in.)
"2" 2.481 to 2.484 mm (0.0977 to 0.0978 in.)
"3" 2.484 to 2.487 mm (0.0978 to 0.0979 in.)
"4" 2.487 to 2.490 mm (0.0979 to 0.0980 in.)
"5" 2.490 to 2.493 mm (0.0980 to 0.0981 in.)
Page 1072 of 3000

2GR-FE ENGINE MECHANICAL – ENGINE UNITEM–125
EM
Standard upper bearing center wall thickness
(No. 2 and No. 3 journal)
Standard lower bearing center wall thickness
(No. 2 and No. 3 journal)
43. INSPECT CRANKSHAFT BEARING CAP SET BOLT
(a) Using vernier calipers, measure the minimum
diameter of the compressed thread at the
measuring point.
Standard diameter:
10.8 to 11.0 mm (0.4252 to 0.4331 in.)
Minimum diameter:
10.7 mm (0.4213 in.)
Measuring Point:
40 mm (1.57 in.)
If the diameter is less than the minimum, replace the
bolt.
Mark Thickness
"1" 2.478 to 2.481 mm (0.0976 to 0.0977 in.)
"2" 2.481 to 2.484 mm (0.0977 to 0.0978 in.)
"3" 2.484 to 2.487 mm (0.0978 to 0.0979 in.)
"4" 2.487 to 2.490 mm (0.0979 to 0.0980 in.)
"5" 2.490 to 2.493 mm (0.0980 to 0.0981 in.)
Mark Thickness
"1" 2.500 to 2.503 mm (0.0984 to 0.0985 in.)
"2" 2.503 to 2.506 mm (0.0985 to 0.0987 in.)
"3" 2.506 to 2.509 mm (0.0987 to 0.0988 in.)
"4" 2.509 to 2.512 mm (0.0988 to 0.0989 in.)
"5" 2.512 to 2.515 mm (0.0989 to 0.0990 in.)
A125160E02
