Page 137 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – U151F AUTOMATIC TRANSAXLEPP–33 PP RECOMMENDED TOOLS 09011-12301 Socket Wrench 30 mm 09031-00030 Pin Punch 09031-00040 Pin Punch . 09040-00011 Hexagon Wrench Set (09043-20050) Socke

Page 138 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–34PREPARATION – U151F AUTOMATIC TRANSAXLE PP 09905-00013 Snap Ring Pliers

Page 139 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – U151F AUTOMATIC TRANSAXLEPP–35 PP EQUIPMENT Straight edge Torque wrench Vernier calipers Dial indicator with magnetic base Slide calipers Chain block Feeler gauge Plastic hammer Pr

Page 140 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–36PREPARATION – U151F AUTOMATIC TRANSAXLE PP LUBRICANT Automatic transaxle fluid Dry fill Drain and refill9.0 liter (9.5 US qts, 7.9 lmp.qts) 3.6 liter (3.8 US qts, 3.2 lmp.qts)ATF type T-IV

Page 141 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – U151F AUTOMATIC TRANSAXLEPP–37 PP SSM 08833-00070 Adhesive 1324, THREE BOND 1324 or equivalent 08833-00080 Adhesive 1344 THREE BOND 1344 LOCTITE 242 or equivalent

Page 142 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – TRANSFERPP–37 PP RECOMMENDED TOOLS 09040-00011 Hexagon Wrench Set (09043-20060) Socket Hexagon Wrench 6 09904-00010 Expander Set (09904-00020) No. 1 Claw 09905-00013 Snap Ring Plie

Page 143 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PP–38PREPARATION – TRANSFER PP EQUIPMENT To r q u e w r e n c h Dial gauge with magnetic base V-block Universal engine lifter

Page 144 of 3000

TOYOTA SIENNA 2007 Service Repair Manual PREPARATION – TRANSFERPP–39 PP LUBRICANT Item Capacity Classification Transfer oil 0.9 litters (0.95 US qts, 0.71 lmp.qts) Hypoid gear oil SAE 90 (GL-5)
