(c) Remove the 6 nuts and front exhaust pipe
assembly.
4. REMOVE HEATED OXYGEN SENSOR (for Bank 2
Sensor 2)
(a) Using SST, remove the heated oxygen sensor from
the front exhaust pipe assembly.
SST 09224-00010
INSPECTION
1. INSPECT HEATED OXYGEN SENSOR (for Bank 1
Sensor 2)
(a) Measure the resistance of the sensor.
Standard resistance
If the resistance is not as specified, replace the
sensor.
A162483
A163269E01
A161881E02
Tester Connection Specified Condition
1 (HT) - 2 (+B) 11 to 16
at 20C (68F)
1 (HT) - 4 (E1) 10 k
or higher
Page 1202 of 3000

EC–342GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 2WD)
EC
2. INSPECT HEATED OXYGEN SENSOR (for Bank 2
Sensor 2)
(a) Measure the resistance of the sensor.
Standard resistance
If the resistance is not as specified, replace the
sensor.
INSTALLATION
1. INSTALL HEATED OXYGEN SENSOR (for Bank 2
Sensor 2)
(a) Using SST, install the heated oxygen sensor to the
front exhaust pipe.
SST 09224-00010
Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) for use
with SST
44 N*m (449 kgf*cm, 32 ft.*lbf) for use
without SST
HINT:
• Use a torque wrench with a fulcrum length of 30
cm (11.81 in.).
• Make sure that SST and a wrench are connected
in a straight line.
2. INSTALL FRONT EXHAUST PIPE ASSEMBLY
(a) Check the compression springs.
(1) Check the compression springs using vernier
calipers.
Specified length:
38.86 mm (1.5299 in.)
HINT:
If the result is not as specified, replace the
compression spring.
(b) Install the gasket.
(1) Install a new gasket by hand onto the front
exhaust pipe assembly.
(2) Using a plastic hammer and wooden block, tap
in the new gasket until its surface is flush with
the front exhaust pipe.
NOTICE:
• Be careful with the installation direction
of the gasket.
• Do not damage the gasket.
• Do not reuse the gasket.
A161881E04
Tester Connection Specified Condition
3 (HT) - 2 (+B) 11 to 16
at 20C (68F)
3 (HT) - 4 (E1) 10 k
or higher
A163271E01
A077857
A076194E04
Page 1203 of 3000
2GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 2WD)EC–35
EC
• To ensure a proper seal, do not use the
exhaust pipe to force the gasket on to the
front exhaust pipe.
(c) Install 2 new gaskets to the front exhaust pipe
assembly.
(d) Install the front exhaust pipe assembly with the 4
nuts.
Torque: 62 N*m (632 kgf*cm, 46 ft.*lbf)
(e) Install the front exhaust pipe assembly with the 2
compression springs and 2 bolts.
Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
(f) Install the No. 1 exhaust pipe support bracket with 2
new nuts.
Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
A162908
A162949
Page 1204 of 3000
EC–362GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 2WD)
EC
(g) Connect the heated oxygen sensor (for Bank 2
sensor 2) connector.
3. INSTALL HEATED OXYGEN SENSOR (for Bank 1
Sensor 2)
(a) Using SST, install the heated oxygen sensor.
SST 09224-00010
Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) for use
with SST
44 N*m (449 kgf*cm, 32 ft.*lbf) for use
without SST
HINT:
• Use a torque wrench with a fulcrum length of 30
cm (11.81 in.).
• Make sure that SST and a wrench are connected
in a straight line.
(b) Connect the heated oxygen sensor (for Bank 1
Sensor 2) connector.
4. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
5. INSPECT FOR EXHAUST GAS LEAK
A165516
A162954E01
Page 1205 of 3000
2GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 4WD)EC–37
EC
ENGINE
2GR-FE EMISSION CONTROL
HEATED OXYGEN SENSOR (for 4WD)
COMPONENTS
A162953E01
Page 1206 of 3000
EC–382GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 4WD)
EC
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
2. REMOVE HEATED OXYGEN SENSOR (for Bank 1
Sensor 2)
(a) Disconnect the sensor connector under the center
console.
(b) Using SST, remove the heated oxygen sensor.
SST 09224-00010
3. REMOVE FRONT EXHAUST PIPE ASSEMBLY
(a) Disconnect the heated oxygen sensor (for Bank 2
Sensor 2) connector.
(b) Remove the 2 bolts, 4 nuts and front exhaust pipe
assembly.
4. REMOVE HEATED OXYGEN SENSOR (for Bank 2
Sensor 2)
(a) Using SST, remove the heated oxygen sensor from
the front exhaust pipe assembly.
A163385E02
A162957
A163269E01
Page 1207 of 3000

2GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 4WD)EC–39
EC
INSPECTION
1. INSPECT HEATED OXYGEN SENSOR (for Bank 1
Sensor 2)
(a) Measure the resistance of the sensor.
Standard resistance
If the resistance is not as specified, replace the
sensor.
2. HEATED OXYGEN SENSOR (for Bank 2 Sensor 2)
(a) Measure the resistance of the sensor.
Standard resistance
If the resistance is not as specified, replace the
sensor.
INSTALLATION
1. INSTALL HEATED OXYGEN SENSOR (for Bank 2
Sensor 2)
(a) Using SST, install the heated oxygen sensor to the
front exhaust pipe.
SST 09224-00010
Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) for use
with SST
44 N*m (449 kgf*cm, 32 ft.*lbf) for use
without SST
HINT:
• Use a torque wrench with a fulcrum length of 30
cm (11.81 in.).
• Make sure that SST and a wrench are connected
in a straight line.
2. INSTALL FRONT EXHAUST PIPE ASSEMBLY
(a) Install 2 new gaskets to the front exhaust pipe
assembly.
A161881E02
Tester Connection Specified Condition
1 (HT) - 2 (+B) 11 to 16
at 20C (68F)
1 (HT) - 4 (E1) 10 k
or higher
A161881E04
Tester Connection Specified Condition
3 (HT) - 2 (+B) 11 to 16
at 20C (68F)
3 (HT) - 4 (E1) 10 k
or higher
A163271E01
Page 1208 of 3000
EC–402GR-FE EMISSION CONTROL – HEATED OXYGEN SENSOR (for 4WD)
EC
(b) Install the front exhaust pipe assembly with the 2
