Page 1857 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–182U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 5. REMOVE SPEED SENSOR (a) Remove the 2 bolts and the 2 speed sensors from the transaxle assembly. 6. REMOVE TRANSAXLE CASE NO.1 PL

Page 1858 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–183 AX 9. INSPECT TRANSMISSION OIL CLEANER MAGNET (a) Remove the magnets and use them to collect any steel chips. Examine the chips and pa

Page 1859 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–184U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 13. REMOVE TRANSMISSION VALVE BODY ASSEMBLY (a) Support the valve body assembly and remove the 17 bolts and valve body assembly. 14

Page 1860 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–185 AX 18. REMOVE C-3 ACCUMULATOR PISTON (a) Remove the spring from the C-3 accumulator piston. (b) Apply compressed air (392 kPa, 4.0 kgf

Page 1861 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–186U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 20. REMOVE B-3 ACCUMULATOR PISTON (a) Apply compressed air (392 kPa, 4.0 kgf/cm 2, 57 psi) to the oil hole and remove the B-3 accum

Page 1862 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–187 AX 24. REMOVE MANUAL VALVE LEVER SUB-ASSEMBLY (a) Using a chisel and hammer, cut off and remove the spacer. (b) Using a pin punch ( 35

Page 1863 of 3000

TOYOTA SIENNA 2007 Service Repair Manual AX–188U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 28. INSPECT INPUT SHAFT ENDPLAY HINT: (See page AX-204) 29. REMOVE TRANSAXLE HOUSING (a) Remove the 16 bolts. (b) Tap on the circumf

Page 1864 of 3000

TOYOTA SIENNA 2007 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–189 AX 33. REMOVE DIFFERENTIAL GEAR ASSEMBLY (a) Remove the differential gear assembly from the transaxle case. 34. REMOVE OVERDRIVE BRAKE
