TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER UNITTF–35 TF (c) Using SST(s), install the CTR differential lock sleeve to the transfer case. SST 09950-60010 (09951-00610), 09950-70010 (09951-07150) (d) Using snap ring p

Page 2026 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–36TRANSFER – TRANSFER UNIT TF 32. INSTALL TRANSFER EXTENSION HOUSING SUB- ASSEMBLY (a) Apply sealant 1281 to the transfer extension housing sub-assembly in continuous beaded from of 1.2 mm

Page 2027 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER UNITTF–37 TF 35. INSTALL TRANSFER DYNAMIC DAMPER (a) Install the transfer dynamic damper to the transfer extension housing sub-assembly with the 3 bolts. Torque: 26 N*m (260

Page 2028 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–38TRANSFER – TRANSFER UNIT TF 39. INSTALL TRANSFER COVER GASKET (a) Install a new transfer cover gasket to the transfer case. C082798

Page 2029 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER OILTF–3 TF TRANSFER OIL ON-VEHICLE INSPECTION 1. INSPECT TRANSFER OIL (a) Remove the No. 1 plug and gasket. (b) Check the oil level is within 0 - 5 mm (0 - 0.20 in.) below t

Page 2030 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER ASSEMBLYTF–7 TF DRIVE LINE TRANSFER TRANSFER ASSEMBLY COMPONENTS C118798E04

Page 2031 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TF–8TRANSFER – TRANSFER ASSEMBLY TF REMOVAL 1. REMOVE ENGINE AND TRANSAXLE HINT: (See page EM-26) 2. REMOVE AUTOMATIC TRANSMISSION WITH TRANSFER HINT: (See page AX-164) 3. REMOVE NO. 1 TRANSFER

Page 2032 of 3000

TOYOTA SIENNA 2007 Service Repair Manual TRANSFER – TRANSFER ASSEMBLYTF–9 TF INSTALLATION 1. INSTALL TRANSFER ASSEMBLY (a) Apply sealant 1281 to the transaxle assembly and transfer assembly in continuous beaded from of 1.2 mm diamete
