Page 2937 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 217
Type approval
R
E84303

Page 2938 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Audio introduction
218
L
Audio introductionRADIO RECEPTION
Some interference is to be expected from time
to time during a journey. Occasionally it may be
necessary to retune the audio unit to of

Page 2939 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 219
Audio unit overview
R
Audio unit overviewAUDIO UNIT OVERVIEW
Premium audio overview
1. On or off and volume control
• Press to switch on or off
• Rotate to adjust volume
2. Information d

Page 2940 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Audio unit overview
220
L
17. INFO button
• Press and release for traffic
announcements
• Press and hold for news
announcements
18. Tone and volume settings button
• Press and releas

Page 2941 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 221
Audio unit overview
R
Standard audio overview
1. On or off and volume control
• Press to switch on or off
• Rotate to adjust volume
2. Radio station presets or CD disc selection
3. Inf

Page 2942 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Audio unit overview
222
L
Basic audio functions
• Press rotary control to switch audio unit
on or off.
• Rotate control to adjust volume or to
adjust menu settings levels.
• Press and re

Page 2943 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 223
Audio unit operation
R
Audio unit operationON OR OFF CONTROL
Press the on or off control to switch the audio
unit on. Press again to switch off.
VOLUME CONTROL
Rotate the volume control to incre

223
Audio unit operation
R
Audio unit operationON OR OFF CONTROL
Press the on or off control to switch the audio
unit on. Press again to switch off.
VOLUME CONTROL
Rotate the volume control to increase or
decrease the audio unit volume. The volume
can be set between 0 and 35.
When the audio unit is turned on, the
previously set volume level will be
implemented.
Note: The standard audio unit can be used with
the engine off, but the maximum volume level
will be restricted.
Automatic Volume Control (AVC)
The AVC feature adjusts the volume level to
compensate for the changes in road noise as
the vehicle speed increases or decreases.
Note: The AVC setting represents the volume
increase and not the volume level.
If the AVC level is set to Off, there will be no
volume increase. With a low level setting, the
volume increase at speed will be minimal. If a
high level setting is used, there will be a
noticeable increase of volume at speed.
The AVC setting required will depend upon the
expected speed and the expected road
conditions.
Use the following proce dure to set the AVC
level.
1. Press and hold the tone button to access
the volume settings menu.
2. Press the tone button repeatedly until AVC
Level is displayed.
3. Rotate the volume control to select the
required AVC setting.
Reset volume settings
The following procedure will reset all of the
volume settings to the original factory values.
1. Press and hold the tone button to access
the volume settings menu.
2. Repeatedly press the tone button to scroll
through the menu until the Reset volume
settings message is displayed.
3. Rotate the volume control to highlight YES
or NO as required.
4. On premium audio un its, press the tone
button to confirm your choice and exit the
menu. On standard audio units, your
choice is confirme d by pressing the MENU
button.
AUDIO CONTROL
Depending on the specification of the audio
system fitted to your vehicle, the following
audio control settings are available from the
tone menu.
Surround sound settings
1. Press and release th e tone button to
display the current surround sound
setting.
2. Rotate the volume control to highlight 3
Channel or Stereo as required.
Bass response adjustment
1.Press the tone button repeatedly until the
current Bass setting is displayed.
2. Rotate the volume control to increase or
decrease the level.
Treble response adjustment
1. Press the tone button repeatedly until the
current Treble setting is displayed.
2. Rotate the volume control to increase or
decrease the level.

Page 2944 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Audio unit operation
224
L
Balance adjustment
1. Press the tone button repeatedly until the
current Balance setting is displayed.
2. Rotate the volume control to adjust sound
level to the rig
