2006 LAND ROVER FRELANDER 2 Repair Manual

change language wiper fluid child lock suspension oil reset keyless entry

Page 2825 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 105
Climate control
R
ELECTRIC SUNROOF
Operation
1. Front switch, closes or tilts the sunroof.
2. Rear switch, fully ope ns or closes the
sunroof.
The panoramic sunroof can only be operated
w

105
Climate control
R
ELECTRIC SUNROOF
Operation
1. Front switch, closes or tilts the sunroof.
2. Rear switch, fully ope ns or closes the
sunroof.
The panoramic sunroof can only be operated
with the ignition on.
Tilt
With the roof closed, press and release the
front of the switch. The sunroof will move to
the tilted position automatically. It can be
stopped at any point by pressing the button
again. Fully open
With the sunroof closed, press and release the
rear of the switch. The sunroof will move to the
fully open position auto matically. It can be
stopped at any point by pressing the button
again.
Close
• From the fully open position, press and
release the front of the switch. The roof will
return to the closed position automatically.
• From the tilted positi on, press and hold the
rear of the switch. Keep the switch pressed
until the roof is fully closed.
Anti-trap mechanism
If the sunroof encounters resistance when
closing it will stop, a nd then open slightly. This
is to prevent serious injury or damage to the
mechanism.
Override
The anti-trap mechanism can be overridden to
allow the roof to be closed when movement is
restricted by dirt or ice. To override the
anti-trap mechanism, press and hold the front
of the switch until the roof reaches the closed
position.
WARNING
Extreme care must be taken to ensure
that none of the oc cupants have any
part of their body in a position where it
could be trapped by the panoramic sunroof
when closing. Although an anti-trap
mechanism is fitted, serious injuries can
occur.
2
1
E81262
WARNING
The anti-trap mechanism does not
operate when closing the roof from the
tilted position. The sunroof can cause
serious injury should a body part become
trapped. Always ensure th at the sunroof is free
from obstructions before closing.
CAUTION
Wherever possible remove any snow,
ice, dirt, leaves etc. from the sunroof
mechanism before closing. Failure to do
so may damage the sunroof mechanism.

Page 2826 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Climate control
106
L
Calibration
If the battery is disconnected, or the power
supply is interrupted, whilst the sunroof is
partially open it will need to be recalibrated.
Once the battery is re

Page 2827 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 107
Convenience features
R
Convenience featuresSUN VISORS
CLOCK
The clock is set through the audio system.
Setting the clock - Premium audio
1. Switch on the audio system, by pressing
the volume r

Page 2828 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Convenience features
108
L
3. Rotate the control to select Clock and
press to confirm selection.
4. Use the rotary control to adjust the Time
Mode (12 or 24 hr), press to confirm
selection

Page 2829 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 109
Convenience features
R
6. Use the rotary control to adjust the
minutes and press to confirm selection.
7. Once the time has been set, OK will be
highlighted. Press the rotary control to

Page 2830 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Convenience features
110
L
AUXILIARY POWER SOCKETS
CAUTIONS
Only Land Rover approved accessories
should be plugged into the power
sockets. Using any other equipment
may damage the vehicles ele

Page 2831 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 111
Convenience features
R
CUP HOLDERS
1. Bottle holders.
2. Cup holders.
E82051
11
11
2
2
2
2
WARNINGS
The cup and bottle holders should only
be used for soft cont ainers. Containers
which ar

Page 2832 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Convenience features
112
L
STORAGE COMPARTMENTS
1. Coin/trinket trays.
2. Map pockets.
3. Storage compartments.
4. Glove box.
5. Rear armrest storage compartment.
E82050
1
3
1
1
2
3
1
4
3
2
3
