Page 2777 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 57
Seat belts
R
USING SEAT BELTS DURING
PREGNANCY
Position the lap strap co mfortably across the
hips beneath the abdomen. Place the diagonal
part of the seat belt be tween the breasts and to

Page 2778 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Supplementary restraints system
58
L
Supplementary restraints systemPRINCIPLE OF OPERATION
Introduction
In the event of a collision the airbag control unit
monitors the rate of de celeration caused

Page 2779 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 59
Supplementary restraints system
R
Airbags
1. Drivers airbag.
2. Front passenger airbag.
3. Seat mounted side airbags.
4. Curtain airbags.
5. Knee-bolster airbag.
E82660
34
3
5
21
WARNINGS

Page 2780 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Supplementary restraints system
60
L
Note: The location points of airbags fitted to
the vehicle are marked by the word AIRBAG
embossed into the trim.
Always contact your Land Rover
Dealer/Auth

Supplementary restraints system
60
L
Note: The location points of airbags fitted to
the vehicle are marked by the word AIRBAG
embossed into the trim.
Always contact your Land Rover
Dealer/Authorised repairer if :-
• An airbag inflates.
• The front or sides of the vehicle are
damaged.
• Any part of the SRS shows signs of
cracking or damage, including trim
covering airbags.
Airbag operation
Airbags cannot deploy co rrectly if they are
obstructed. Examples of obstructions are :-
• Any part of an occupa nts body in contact
with, or close to, an airbag cover. •
Objects placed on, or close to, an airbag
cover.
• Clothing, sun screens, or other material
hanging from grab handles.
• Clothing, cushions, or other material,
covering seat mounted airbags.
• Seat covers which are not approved by
Land Rover, or specifically designed for
use with seat mounted airbags.
This list is not exhaustive, and it remains the
responsibility of the driv er and passengers to
ensure that the airbags are not obstructed in
any way.
Deployment and deflation
In the event of a collision the airbag control
system monitors the ra te, and direction of
deceleration. If required to supplement the seat
belts, airbags will be deployed as appropriate.
Front airbags
The front passenger's, and driver's airbags are
able to deploy in two stages depending on the
severity of the frontal impact. In a severe
impact the airbags inflate fully to offer
maximum protection. In a lesser impact full
deployment is not require d, so the airbags are
partially inflated.
Side and curtain airbags
Side and curtain airbag s are designed to offer
increased protection for the torso and head in
a side impact. The curtain airbags deflate at a
slower rate than the front, or side airbags to
afford greater protection from serious head
injuries.
Phone systems should only be
installed by qualified persons familiar
with the operation of, and
requirements for, vehicles fitted with SRS. If
you are in any doubt, seek advice from your
Land Rover Dealer/Authorised repairer.
WARNINGS
For the airbags to operate correctly the
roof lining and door post trims must
be in good condition, correctly fitted,
and free from obstructi on. Any damage, wear,
or incorrect fitment shoul d be referred to your
Land Rover Dealer/Aut horised repairer as
soon as possible for ex amination and repair.
Do not allow passe ngers to obstruct
the operation of the airbags by placing
any part of their person, or any
objects, in contact with, or close to, an airbag
module. Airbags deploy at very high speeds,
and can cause serious inju ry or death if objects
or occupants are within the area of
deployment.
WARNINGS

Page 2781 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 61
Supplementary restraints system
R
Airbag deployment effectsAIRBAG WARNING LAMP
The airbag warning indicator is
mounted in the instrument pack,
and will illuminate as a bulb check
when the igni

Page 2782 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Supplementary restraints system
62
L
DISABLING THE PASSENGER AIRBAG
Note: The passenger airbag should be disabled
only when a rearward fa cing child restraint if
fitted to the front passenger s

Page 2783 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual 63
Supplementary restraints system
R
Operational status indicator
The passenger airbag operational status
indicator illuminates yellow when the airbag
has been disabled.
Note: The indicator wil

Page 2784 of 3229

LAND ROVER FRELANDER 2 2006 Repair Manual Child safety
64
L
Child safetyCHILD SEATS
It is very important for all infants and children
under 12 years of age to be restrained in a
suitable child safety seat appropriate to their
age and siz

Child safety
64
L
Child safetyCHILD SEATS
It is very important for all infants and children
under 12 years of age to be restrained in a
suitable child safety seat appropriate to their
age and size. If it is essential that a child travels in the front
passenger seat, Land Ro ver recommends that
the following preparations are made before
fitting the child restraint.
• Disable the front pass enger airbag. See
DISABLING THE PASSENGER AIRBAG
(page 62).
• Adjust the front passenger seat fully
rearwards.
• Adjust the lumbar support to its minimum
support position.
• Adjust the seat cushion to its highest
position. If cushion rake adjustment is
possible, adjust it to its lowest position.
• Adjust the seat be lt adjustable upper
anchorage to its lowest position.
This symbol is affixed to the end of the facia on
the passenger side. Its purpose is to warn
against the use of a rear facing child seat when
the front passenger ai rbag is fitted and
operational.
WARNINGS
Do not use a child restraint on a seat
with an operational airbag in front of
it. There is a risk of death or serious injury
when the airbag deploys.
Crash statistics show that children are
safest when properly restrained on
the rear seat.
Do not use a forward facing child seat
until the child using it is above the
minimum weight of 9 kg (20 lb.) and able to
sit up unaided. Up to the age of two, a child's
spine and neck are not sufficiently developed
to avoid injury in a frontal impact.
Do not allow a baby or infant to be
held or carried on the lap. The force of
a crash can increase effective body weight by
as much as thirty times, making it
impossible to hold onto the child. Children
typically require the use of a booster seat
appropriate to their age and size, thereby
enabling the seat belts to be properly fitted,
reducing the risk of injury in a crash.
Children could be enda ngered in a crash if
their child restraints are not properly secured
in the vehicle.
Do not use a child seat that hooks
over the seat back. This type of seat
cannot be satisfactorily secured and is
unlikely to be safe for your child.
WARNING
Original text according to ECE R94.
01. Extreme hazard! Do not use a
rearward facing child restraint on a seat
protected by an operational airbag in front of
it!
E79258
