Page 2921 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REAR FINAL DRIVE ASSEMBLY
RFD-31
C
E
F
G
H
I
J
K
L
MA
B
RFD

3. Using the drift below, drive an oil seal until it becomes flush with
the case end.
CAUTION:
Do not reuse oil seals.
Apply multi-purpo

Page 2922 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual RFD-32
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationEDS001ZE
Drive Gear VibrationEDS001ZF
To ta l P r e l o a dEDS001ZJ
Side Gear Cleara

RFD-32
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationEDS001ZE
Drive Gear VibrationEDS001ZF
To ta l P r e l o a dEDS001ZJ
Side Gear Clearance AdjustmentEDS001ZG
Drive Pinion Gear Preload AdjustmentEDS001ZH
Side Bearing Preload AdjustmentEDS001ZI
THRUST WASHER FOR ADJUSTMENT OF SIDE GEAR BACK CLEARANCEEDS002V9
*: Always check with the Parts Department for the latest parts information.
DRIVE PINION GEAR PRELOAD ADJUSTING SHIMEDS002VA
*: Always check with the Parts Department for the latest parts information.Applied model QR20DE, QR25DE, YD22DDTi
Final drive modelR145
Drive gear pitch diameter 145
Gear ratio2.466
Number of teeth (Drive gear/Drive pinion) 37/15
Oil capacity (approx.)
0.55 (1 lmp pt.)
Number of pinion gears2
Drive pinion adjustment spacer type Collapsible
Vibration limit at drive gear back 0.05 mm (0.0020 in) or less
Total preload with oil seal installed 1.33 - 2.15 N·m (0.14 - 0.21 kg-m,12 - 19 in-lb)
Drive gear backlash 0.10 - 0.15 mm (0.0039 - 0.0059 in)
Side gear back clearance 0.2 mm (0.008 in) or less. Every gear shall rotate smoothly with no abnormal feeling of drag.
Adjustment of drive pinion gear Collapsible spacer
Drive pinion gear preload 0.69 - 1.17 N·m (0.07 - 0.11 kg-m,7 - 10 in-lb)
Adjustment of side bearing Adjusting shim
Side bearing preload 0.64 - 0.98 N·m (0.07 - 0.09 kg-m,6 - 8 in-lb)
Thickness Part number* Thickness Part number*
0.74 mm (0.0291 in)
0.77 mm (0.0303 in)
0.80 mm (0.0315 in)38424 4N200
38424 4N201
38424 4N2020.83 mm (0.0327 in)
0.86 mm (0.0339 in)38424 4N203
38424 4N204
Thickness Part number* Thickness Part number*
1.70 mm (0.0669 in)
1.73 mm (0.0681 in)
1.76 mm (0.0693 in)
1.79 mm (0.0705 in)
1.82 mm (0.0717 in)
1.85 mm (0.0728 in)
1.88 mm (0.0740 in)
1.91 mm (0.0752 in)
1.94 mm (0.0764 in)
1.97 mm (0.0776 in)38154 4N200
38154 4N201
38154 4N202
38154 4N203
38154 4N204
38154 4N205
38154 4N206
38154 4N207
38154 4N208
38154 4N2092.00 mm (0.0787 in)
2.03 mm (0.0799 in)
2.06 mm (0.0811 in)
2.09 mm (0.0823 in)
2.12 mm (0.0835 in)
2.15 mm (0.0846 in)
2.18 mm (0.0858 in)
2.21 mm (0.0870 in)
2.24 mm (0.0882 in)38154 4N210
38154 4N211
38154 4N212
38154 4N213
38154 4N214
38154 4N215
38154 4N216
38154 4N217
38154 4N218

Page 2923 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
RFD-33
C
E
F
G
H
I
J
K
L
MA
B
RFD

ADJUSTING SHIM FOR SIDE BEARING PRELOADEDS002VB
*: Always check with the Parts Department for the latest parts information.Thi

Page 2924 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual RFD-34
SERVICE DATA AND SPECIFICATIONS (SDS)

Page 2925 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual FAX-1
FRONT AXLE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION FA X
A
B
FA X

FRONT AXLE
PRECAUTIONS .......................................................... 2
Caution ....................

FAX-1
FRONT AXLE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION FA X
A
B
FA X

FRONT AXLE
PRECAUTIONS .......................................................... 2
Caution ..................................................................... 2
PREPARATION ........................................................... 3
Special Service Tools (SST) ..................................... 3
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 6
NVH Troubleshooting Chart ..................................... 6
FRONT WHEEL HUB AND KNUCKLE ...................... 7
On-Vehicle Inspection .............................................. 7
FRONT WHEEL BEARINGS ................................ 7
Removal and Installation .......................................... 7
REMOVAL ............................................................. 7
INSPECTON AFTER REMOVAL .......................... 8
INSTALLATION ..................................................... 8
Disassembly and Assembly ..................................... 8
DISASSEMBLY ..................................................... 8
INSPECTION AFTER DISASSEMBLY ................. 9
ASSEMBLY ........................................................... 9FRONT DRIVE SHAFT ............................................. 11
Removal and Installation ........................................ 11
REMOVAL ........................................................... 11
INSPECTION AFTER REMOVAL ....................... 12
INSTALLATION ................................................... 12
Disassembly and Assembly .................................... 13
DISASSEMBLY ................................................... 13
INSPECTION AFTER DISASSEMBLY ................ 14
ASSEMBLY ......................................................... 15
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 19
Wheel Bearing ........................................................ 19
Drive Shaft .............................................................. 19
ZF100SS86, ZF100SS86F, ZF100SS86F+B ...... 19
Dynamic Damper .................................................... 19

Page 2926 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual FAX-2
PRECAUTIONS

PRECAUTIONSPFP:00001
CautionEDS0005P
When installing rubber parts, final tightening must be carried out under unladen condition* with tires on
ground.
Oil will shorten the life o

Page 2927 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual PREPARATION
FAX-3
C
E
F
G
H
I
J
K
L
MA
B
FA X

PREPARATIONPFP:00002
Special Service Tools (SST)EDS0005Q
Tool number
Tool nameDescription
KV401 04100
AttachmentRemoving wheel hub and bearing
assembly

Page 2928 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual FAX-4
PREPARATION

KV40106200
Drift
a: 114.3 mm (4.50 in) dia.
b: 105.3 mm (4.15 in) dia.Removing wheel bearings, installing splash
guards
KV401047S0
Drift set
KV40104710
Drift
a: 76.3 mm (3.004
