CYLINDER BLOCK
EM-91
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
A widely use engine stand can be used.
NOTE:
This example is an engine stand for holding at transaxle
mounting side with flywheel (M/T models) or drive plate (A/T
models) removed.
3. Drain engine oil. Refer to LU-8, "
Changing Engine Oil" .
4. Drain engine coolant by removing water drain plug from inside of
engine.
5. Remove cylinder head. Refer to EM-70, "
CYLINDER HEAD" .
6. Remove knock sensor.
CAUTION:
Carefully handle knock sensor avoiding shocks.
7. Remove crankshaft position sensor (POS).
CAUTION:
Avoid impacts such as a dropping.
Do not disassemble.
Keep it away from metal particles.
Do not place sensor in a location where it is exposed to
magnetism.
8. Remove clutch cover and clutch disc (M/T models). Refer to CL-16, "
CLUTCH DISC, CLUTCH COVER
AND FLYWHEEL" .
9. Remove flywheel (M/T models) or drive plate (A/T models).
Secure crankshaft with a stopper plate, and remove mounting
bolts.
Using the following TORX socket, loosen mounting bolts.
CAUTION:
Be careful not to damage contact surface for clutch disc of
flywheel (M/T models).
PBIC0085E
PBIC2716E
PBIC2191E
Flywheel (M/T models)
: size T55 (commercial service tool)
Drive plate (A/T models)
: size E20
PBIC2352E
Page 146 of 4555
![NISSAN X-TRAIL 2005 Service Repair Manual EM-92
[QR]
CYLINDER BLOCK
NOTE:
The flywheel, two block construction, allows movement in response to transaxle side pressure, or when
twisted in its rotational direction. Therefore, some amount of n NISSAN X-TRAIL 2005 Service Repair Manual EM-92
[QR]
CYLINDER BLOCK
NOTE:
The flywheel, two block construction, allows movement in response to transaxle side pressure, or when
twisted in its rotational direction. Therefore, some amount of n](/manual-img/5/57403/w960_57403-145.png)
EM-92
[QR]
CYLINDER BLOCK
NOTE:
The flywheel, two block construction, allows movement in response to transaxle side pressure, or when
twisted in its rotational direction. Therefore, some amount of noise is normal.
10. Remove pilot converter using pilot bushing puller (special ser-
vice tool) or suitable tool. (A/T models)
NOTE:
M/T models have no pilot bushing.
11. Remove piston and connecting rod assembly with the following procedure:
Before removing piston and connecting rod assembly, check the connecting rod side clearance. Refer
to EM-107, "
CONNECTING ROD SIDE CLEARANCE" .
a. Position crankshaft pin corresponding to connecting rod to be removed onto the bottom dead center.
b. Remove connecting rod cap.
c. Using a hammer handle or similar tool, push piston and connect-
ing rod assembly out to the cylinder head side.
CAUTION:
Be careful not to damage the cylinder wall, resulting from
an interference of the connecting rod big end.
12. Remove connecting rod bearings.
CAUTION:
When removing them, note the installation position. Keep them in the correct order.
13. Remove piston rings form piston.
Use a piston ring expander (commercial service tool).
CAUTION:
When removing piston rings, be careful not to damage
the piston.
Be careful not to damage piston rings by expanding
them excessively.
14. Remove piston from connecting rod with the following procedure:
SBIA0274E
PBIC0259E
PBIC0087E
Page 147 of 4555
CYLINDER BLOCK
EM-93
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
a. Using snap ring pliers, remove snap ring.
b. Heat piston to 60 to 70°C (140 to 158°F) with a industrial use
drier or equivalent.
c. Push out piston pin with stick of outer diameter approximately 19
mm (0.75 in).
15. Remove lower cylinder block mounting bolts.
Loosen them in reverse order as shown in the figure, and
remove them.
Use TORX socket (size E14) for bolts No. 1 to 10.
Before loosening lower cylinder block mounting bolts, mea-
sure crankshaft end play. Refer to EM-107, "
CRANKSHAFT
END PLAY" .
16. Remove lower cylinder block.
Use a seal cutter (special service tool: KV10111100) or equivalent tool to cut liquid gasket for removal.
CAUTION:
Be careful not to damage the mounting surface.
17. Remove crankshaft.
PBIC1638E
PBIC1639E
PBIC0262E
KBIA0063E
Page 148 of 4555
![NISSAN X-TRAIL 2005 Service Repair Manual EM-94
[QR]
CYLINDER BLOCK
CAUTION:
Be careful not damage or deform signal plate mounted on
crankshaft.
When setting crankshaft on a flat floor surface, use a
block of wood to avoid interference be NISSAN X-TRAIL 2005 Service Repair Manual EM-94
[QR]
CYLINDER BLOCK
CAUTION:
Be careful not damage or deform signal plate mounted on
crankshaft.
When setting crankshaft on a flat floor surface, use a
block of wood to avoid interference be](/manual-img/5/57403/w960_57403-147.png)
EM-94
[QR]
CYLINDER BLOCK
CAUTION:
Be careful not damage or deform signal plate mounted on
crankshaft.
When setting crankshaft on a flat floor surface, use a
block of wood to avoid interference between signal plate
and the floor surface.
Do not remove signal plate unless it is necessary to do
so.
NOTE:
When removing or installing signal plate, use TORX socket (size
T30).
18. Pull rear oil seal out from rear end of crankshaft.
NOTE:
When replacing rear oil seal without removing lower cylinder block, use a screwdriver to pull it out from
between crankshaft and cylinder block.
CAUTION:
Be careful not to damage crankshaft and cylinder block.
19. Remove main bearings and thrust bearings from cylinder block and lower cylinder block.
CAUTION:
Identify installation positions, and store them without mixing them up.
ASSEMBLY
1. Fully air-blow engine coolant and engine oil passages in cylinder block, cylinder bore and crankcase to
remove any foreign material.
CAUTION:
Use a goggles to protect your eye.
2. Install each plug to cylinder block as shown in the figure.
Apply liquid gasket to the thread of water drain plug “A”.
Use Genuine Liquid Gasket or equivalent.
NOTE:
Do not apply liquid gasket to the thread of plug “B”.
Tighten each plug as specified below.
3. Install main bearings and thrust bearings with the following procedure:
a. Remove dust, dirt, and engine oil on the bearing mating surfaces of cylinder block and lower cylinder
block.
SBIA0275E
PBIC2770E
Part Washer Tightening torque
A No 9.8 N·m (1.0 kg-m, 87 in-lb)
B Yes 53.9 N·m (5.5 kg-m, 40 ft-lb)
Page 149 of 4555
![NISSAN X-TRAIL 2005 Service Repair Manual CYLINDER BLOCK
EM-95
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
b. Install thrust bearings to the both sides of the No. 3 journal hous-
ing on cylinder block.
Install thrust bearings with the oil groove facing NISSAN X-TRAIL 2005 Service Repair Manual CYLINDER BLOCK
EM-95
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
b. Install thrust bearings to the both sides of the No. 3 journal hous-
ing on cylinder block.
Install thrust bearings with the oil groove facing](/manual-img/5/57403/w960_57403-148.png)
CYLINDER BLOCK
EM-95
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
b. Install thrust bearings to the both sides of the No. 3 journal hous-
ing on cylinder block.
Install thrust bearings with the oil groove facing crankshaft
arm (outside).
c. Install the main bearings paying attention to the direction.
Main bearing with an oil hole and groove goes on cylinder
block. The one without them goes on lower cylinder block.
Only main bearing (on cylinder block) for No. 3 journal has dif-
ferent specifications.
Before installing main bearings, apply new engine oil to the
bearing surface (inside). Do not apply new engine oil to the
back surface, but thoroughly clean it.
When installing, align main bearing stopper to the notch.
Ensure the oil holes on cylinder block and those on the corre-
sponding bearing are aligned.
4. Install signal plate to crankshaft if removed.
a. Position crankshaft and signal plate using a dowel pin, and
tighten mounting bolts.
b. Remove dowel pin.
CAUTION:
Be sure to remove dowel pin.
NOTE:
Dowel pin of crankshaft and signal plate is provided as a set for
each. If dowel pin is not available (when reusing crankshaft and
signal), use M6 bolt [length 10 mm (0.39 in) or more] as a substi-
tute.
5. Install crankshaft to cylinder block.
While turning crankshaft by hand, make sure that it turns smoothly.
6. Install lower cylinder block with the following procedure:
a. Apply liquid gasket with a tube presser (special service tool:
WS39930000) to lower cylinder block as shown in the figure.
Use Genuine Liquid Gasket or equivalent.
CAUTION:
After liquid gasket is applied, rear oil seal installation must
be finished within 5 minutes. Therefore, the following pro-
cedure must be performed quickly.
NOTE:
Lower cylinder block cannot be replaced as a single part,
because it is machined together with cylinder block.
b. Tighten lower cylinder block mounting bolts with the following
procedure:
i. Apply new engine oil to threads and seat surfaces of mounting bolts.
PBIC0264E
PBIC2193E
SBIA0278E
SBIA0279E
Page 150 of 4555
![NISSAN X-TRAIL 2005 Service Repair Manual EM-96
[QR]
CYLINDER BLOCK
ii. Tighten M8 bolts in numerical order from No. 11 to 22 in the fig-
ure.
NOTE:
There are more processes to complete the tightening of mount-
ing bolts. However stop proce NISSAN X-TRAIL 2005 Service Repair Manual EM-96
[QR]
CYLINDER BLOCK
ii. Tighten M8 bolts in numerical order from No. 11 to 22 in the fig-
ure.
NOTE:
There are more processes to complete the tightening of mount-
ing bolts. However stop proce](/manual-img/5/57403/w960_57403-149.png)
EM-96
[QR]
CYLINDER BLOCK
ii. Tighten M8 bolts in numerical order from No. 11 to 22 in the fig-
ure.
NOTE:
There are more processes to complete the tightening of mount-
ing bolts. However stop procedure here to install rear oil seal.
c. Install rear oil seal. Refer to EM-68, "
Removal and Installation of Rear Oil Seal" .
d. Restart tightening of lower cylinder block mounting bolts with the following procedure:
i. Tighten M10 bolts in numerical order from No. 1 to 10.
ii. Turn M10 bolts 60 degrees clockwise (angle tightening) in order
from No. 1 to 10 in the figure.
CAUTION:
Check and confirm the tightening angle by using an angle
wrench (special service tool) or protractor. Avoid judgment
by visual inspection without the tool.
After installing mounting bolts, make sure that crankshaft can be rotated smoothly by hand.
Wipe off completely any protruding liquid gasket on front side of engine.
Check crankshaft end play. Refer to EM-107, "CRANKSHAFT END PLAY" .
7. Install piston to connecting rod with the following procedure:
a. Using snap ring pliers, install new snap ring to the groove of the piston rear side.
Insert it fully into groove to install.
b. Assemble piston to connecting rod.
Using an industrial use drier or similar tool, heat the piston until the piston pin can be pushed in by hand
without excess force [approx. 60 to 70 °C (140 to 158 °F)]. From the front to the rear, insert piston pin
into piston and connecting rod. : 25.1 N·m (2.6 kg-m, 19 ft-lb)
KBIA0063E
: 39.2 N·m (4.0 kg-m, 29 ft-lb)
KBIA0063E
KBIA0065E
Page 151 of 4555
![NISSAN X-TRAIL 2005 Service Repair Manual CYLINDER BLOCK
EM-97
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
Assemble so that the front mark on the piston head and the oil
holes and the cylinder number on connecting rod are posi-
tioned as shown in the f NISSAN X-TRAIL 2005 Service Repair Manual CYLINDER BLOCK
EM-97
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
Assemble so that the front mark on the piston head and the oil
holes and the cylinder number on connecting rod are posi-
tioned as shown in the f](/manual-img/5/57403/w960_57403-150.png)
CYLINDER BLOCK
EM-97
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM
Assemble so that the front mark on the piston head and the oil
holes and the cylinder number on connecting rod are posi-
tioned as shown in the figure.
c. Install new snap ring to the groove of the piston front side.
Insert it fully into groove to install.
After installing, make sure that connecting rod moves
smoothly.
8. Using a piston ring expander (commercial service tool), install piston rings.
CAUTION:
Be careful not to damage piston.
Position each ring with the gap as shown in the figure refer-
ring to the piston front mark.
Install second ring with the stamped surface facing upward.
NOTE:
If there is no stamped mark on piston ring, no specific orienta-
tion is required for installation.
9. Install connecting rod bearings to connecting rod and connecting rod cap.
When installing connecting rod bearings, apply new engine oil to the bearing surface (inside). Do not
apply new engine oil to the back surface, but thoroughly clean it.
When installing, align the connecting rod bearing stopper pro-
trusion with the cutout of connecting rod and connecting rod
cap to install.
Ensure the oil hole on connecting rod and that on the corre-
sponding bearing are aligned.
10. Install piston and connecting rod assembly to crankshaft.
Position crankshaft pin corresponding to connecting rod to be installed onto the bottom dead center.
Apply new engine oil sufficiently to the cylinder bore, piston and crankshaft pin.
Match the cylinder position with the cylinder number on connecting rod to install.
PBIC2194E
Stamped mark:
To p r i n g : —
Second ring : 2F
PBIC2195E
PBIC0266E
Page 152 of 4555
![NISSAN X-TRAIL 2005 Service Repair Manual EM-98
[QR]
CYLINDER BLOCK
Using a piston ring compressor (special service tool) or suit-
able tool, install piston with the front mark on the piston head
facing the front of the engine.
CAUTION:
B NISSAN X-TRAIL 2005 Service Repair Manual EM-98
[QR]
CYLINDER BLOCK
Using a piston ring compressor (special service tool) or suit-
able tool, install piston with the front mark on the piston head
facing the front of the engine.
CAUTION:
B](/manual-img/5/57403/w960_57403-151.png)
EM-98
[QR]
CYLINDER BLOCK
Using a piston ring compressor (special service tool) or suit-
able tool, install piston with the front mark on the piston head
facing the front of the engine.
CAUTION:
Be careful not to damage the cylinder wall and crankshaft
pin, resulting from an interference of the connecting rod
big end.
11. Install connecting rod cap.
Match the stamped cylinder number marks on connecting rod
with those on connecting rod cap to install.
12. Tighten connecting rod bolt with the following procedure:
a. Apply new engine oil to the threads and seats of connecting rod bolts.
b. Tighten bolts.
c. Then turn all bolts 90 degrees clockwise (Angle tightening).
CAUTION:
Check and confirm the tightening angle by using an angle
wrench (special service tool) or protractor. Avoid judge-
ment by visual inspection without the tool.
After tightening connecting rod bolt, make sure that crankshaft rotates smoothly.
Check the connecting rod side clearance. Refer to EM-107, "CONNECTING ROD SIDE CLEARANCE" .
13. Install flywheel (M/T models) or drive plate (A/T models).
CAUTION:
Make sure that dowel pin is installed at the rear end of crankshaft.
When installing flywheel (M/T models) or drive plate (A/T models) to crankshaft, make sure that align
crankshaft side dowel pin with flywheel/drive-plate side dowel pin hole correctly.
CAUTION:
If these are not aligned correctly, engine runs roughly and “MI” turns on.
Secure crankshaft with a stopper plate, and tighten mounting bolts crosswise over several times.
PBIC1619E
PBIC2196E
: 19.6 N·m (2.0 kg-m, 14 ft-lb)
KBIA0068E
