NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-457 [ALL] D E F G H I J K L MA B AT Control Valve Upper BodyECS00EC2 COMPONENTS SCIA2960J

Page 2722 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-458 [ALL] REPAIR FOR COMPONENT PARTS DISASSEMBLY 1. Remove valves at retainer plates. CAUTION: Do not use a magnetic pick-up tool. a. Use a screwdriver to remove retainer plates. b. Remove retain

Page 2723 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-459 [ALL] D E F G H I J K L MA B AT c. Place mating surface of valve body face down, and remove internal parts. CAUTION: If a valve is hard to remove, place valve body

Page 2724 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-460 [ALL] REPAIR FOR COMPONENT PARTS –Wrap a small screwdriver with vinyl tape and use it to insert valves into their proper positions. 1-2 Accumulator Valve Install 1-2 accumulator valve. Ali

Page 2725 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-461 [ALL] D E F G H I J K L MA B AT Control Valve Lower BodyECS00EC3 COMPONENTS SCIA2959J

Page 2726 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-462 [ALL] REPAIR FOR COMPONENT PARTS DISASSEMBLY Remove valves at retainer plates. For removal procedures, refer to AT- 4 5 8 , " DISASSEMBLY" . INSPECTION Valve Springs Check each valve sprin

Page 2727 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-463 [ALL] D E F G H I J K L MA B AT Install control valves. For installation procedures, refer to AT- 4 5 9 , " ASSEMBLY" . Retainer Plate (Control Valve Lower Body)

Page 2728 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-464 [ALL] REPAIR FOR COMPONENT PARTS Reverse ClutchECS00EC4 COMPONENTS DISASSEMBLY 1. Check operation of reverse clutch a. Install seal ring onto drum support of oil pump cover and install revers
