Page 1945 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0502 ASCD VEHICLE SPEED SENSOR EC-1541 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC WITHOUT CONSULT-II TESTING CONDITION: Step 2 may be conducted with the drive wheels lifted in the shop

Page 1946 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1542 [YD (WITHOUT EURO-OBD)] DTC P0503 ASCD VEHICLE SPEED SENSOR DTC P0503 ASCD VEHICLE SPEED SENSORPFP:24810 Component DescriptionEBS01FDI The ECM receives vehicle speed sensor signal via CAN co

Page 1947 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0503 ASCD VEHICLE SPEED SENSOR EC-1543 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC WITHOUT CONSULT-II TESTING CONDITION: Step 2 may be conducted with the drive wheels lifted in the shop

Page 1948 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1544 [YD (WITHOUT EURO-OBD)] DTC P0504 ASCD BRAKE SWITCH DTC P0504 ASCD BRAKE SWITCHPFP:25320 Component DescriptionEBS01FDM When the brake pedal is depressed, ASCD brake switch (1) and stop lamp

Page 1949 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0504 ASCD BRAKE SWITCH EC-1545 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC DTC confirmation ProcedureEBS01FDP CAUTION: Always drive vehicle at a safe speed. NOTE: If DTC Confirmation Proc

Page 1950 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1546 [YD (WITHOUT EURO-OBD)] DTC P0504 ASCD BRAKE SWITCH 4. Check voltage between ECM terminal 100 (Stop lamp switch signal) and ground under the following conditions. 5. If NG, go to EC-1548, "

Page 1951 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0504 ASCD BRAKE SWITCH EC-1547 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC Wiring Diagram EBS01FDQ TBWB0477E

Page 1952 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1548 [YD (WITHOUT EURO-OBD)] DTC P0504 ASCD BRAKE SWITCH Specification data are reference values and are measured between each terminal and ground. CAUTION: Do not use ECM ground terminals when m
