Page 2737 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-473 [ALL] D E F G H I J K L MA B AT 5. Install drive plates, driven plates and retaining plate. Refer to AT- 5 3 3 , " HIGH CLUTCH" . CAUTION: Be careful with the ord

Page 2738 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-474 [ALL] REPAIR FOR COMPONENT PARTS 9. Install seal rings to input shaft assembly (high clutch drum). CAUTION: Do not reuse seal rings. Apply petroleum jelly to seal rings. CAUTION: Roll paper

Page 2739 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-475 [ALL] D E F G H I J K L MA B AT Forward and Overrun ClutchesECS00EC6 COMPONENTS DISASSEMBLY 1. Check operation of forward clutch and overrun clutch. a. Install bear

Page 2740 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-476 [ALL] REPAIR FOR COMPONENT PARTS 2. Remove snap ring for forward clutch. 3. Remove drive plates, driven plates, retaining plate and dish plate for forward clutch. 4. Remove snap ring for over

Page 2741 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-477 [ALL] D E F G H I J K L MA B AT 10. Remove D-rings and seal rings from forward clutch piston and overrun clutch piston. INSPECTION Snap Rings, Spring Retainer and R

Page 2742 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-478 [ALL] REPAIR FOR COMPONENT PARTS Overrun Clutch Piston Make sure that check balls are not fixed. Apply compressed air to check ball oil hole opposite the return spring. Make sure there is n

Page 2743 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual REPAIR FOR COMPONENT PARTS AT-479 [ALL] D E F G H I J K L MA B AT 4. Install spring retainer and return spring on overrun clutch piston. Align the mark on spring retainer with check ball in overrun

Page 2744 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-480 [ALL] REPAIR FOR COMPONENT PARTS 6. Install drive plates, driven plates, retaining plate and dish plate for overrun clutch. Refer to AT- 5 3 4 , " OVERRUN CLUTCH" . CAUTION: Take care with t
