Page 1825 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual POWER SUPPLY AND GROUND CIRCUIT EC-1421 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 14. CHECK ECM POWER SUPPLY CIRCUIT-V Check voltage between ECM terminal 121 and ground with CON- SULT-II or

Page 1826 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1422 [YD (WITHOUT EURO-OBD)] POWER SUPPLY AND GROUND CIRCUIT 16. CHECK GROUND CONNECTIONS 1. Turn ignition switch OFF. 2. Loosen and retighten ground screws on the body. Refer to EC-1055, " Groun

Page 1827 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual POWER SUPPLY AND GROUND CIRCUIT EC-1423 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC Component InspectionEBS011XU ECM RELAY 1. Apply 12V direct current between ECM relay terminals 1 and 2. 2. C

Page 1828 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1424 [YD (WITHOUT EURO-OBD)] POWER SUPPLY AND GROUND CIRCUIT Ground InspectionEBS011XV Ground connections are very important to the proper operation of electrical and electronic circuits. Ground

Page 1829 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC U1000 CAN COMMUNICATION LINE EC-1425 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC DTC U1000 CAN COMMUNICATION LINEPFP:23710 DescriptionEBS011XW CAN (Controller Area Network) is a serial com

Page 1830 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1426 [YD (WITHOUT EURO-OBD)] DTC U1000 CAN COMMUNICATION LINE Wiring DiagramEBS011XZ TBWA0564E

Page 1831 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC U1000 CAN COMMUNICATION LINE EC-1427 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC Diagnostic ProcedureEBS011Y0 Go to LAN-4, "CAN Communication Unit" .

Page 1832 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1428 [YD (WITHOUT EURO-OBD)] DTC P0016 CKP - CMP CORRELATION DTC P0016 CKP - CMP CORRELATIONPFP:10328 On Board Diagnosis LogicEBS011Y1 The MI will not light up for this self-diagnosis. NOTE: If
