NISSAN X-TRAIL 2005 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-259 [YD22DDTi] C D E F G H I J K L MA EM CYLINDER HEAD Unit: mm (in) VA LV E Valve Dimensions Unit: mm (in) Item Standard Limit Cylinder head distortion Less

Page 314 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EM-260 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) Valve Guide Unit: mm (in) Item Standard Service Valve guide Outer diameter 10.023 - 10.034 (0.3946 - 0.3950) 10.223 - 10.234 (0.4025 - 0.4029)

Page 315 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-261 [YD22DDTi] C D E F G H I J K L MA EM Valve Seat Unit: mm (in) Item Standard Service Cylinder head seat recess diameter (D)Intake 30.000 - 30.016 (1.1811

Page 316 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EM-262 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) Valve Spring CYLINDER BLOCK Unit: mm (in) Depth (H)Intake 8.83 - 9.13 (0.3476 - 0.3594) Exhaust 9.06 - 9.36 (0.3567 - 0.3685) Projection (L)In

Page 317 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-263 [YD22DDTi] C D E F G H I J K L MA EM PISTON, PISTON RING AND PISTON PIN Available Piston Unit: mm (in) Piston Ring Unit: mm (in) Piston Pin Unit: mm (in)

Page 318 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EM-264 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) CONNECTING ROD Unit: mm (in) *: After installing in connecting rod CRANKSHAFT Unit: mm (in) *: Total indicator readingCenter distance157.5 (6.

Page 319 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-265 [YD22DDTi] C D E F G H I J K L MA EM AVAILABLE MAIN BEARING Main bearing Unit: mm (in) Under size Unit: mm (in) Bearing oil clearance Unit: mm (in) AVAIL

Page 320 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EM-266 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) Bearing Oil Clearance Unit: mm (in) Tightening TorqueEBS01FCN *1: Parts to be tightened in particular orders. 1)-: Order of tightening when ti
