Page 2417 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE AT-153 [EURO-OBD] D E F G H I J K L MA B AT 6. CHECK TCM 1. Check TCM input/output signal. Refer to AT- 9 4 , " TCM Terminals and Reference Value" .

Page 2418 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-154 [EURO-OBD] DTC P0745 LINE PRESSURE SOLENOID VALVE DTC P0745 LINE PRESSURE SOLENOID VALVEPFP:31940 DescriptionECS004RU The line pressure solenoid valve regulates the oil pump discharge pressur

Page 2419 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0745 LINE PRESSURE SOLENOID VALVE AT-155 [EURO-OBD] D E F G H I J K L MA B AT 2. Depress accelerator pedal completely and wait at least 5 sec- onds. 3. If check result is NG, go to AT- 1 5 7 ,

Page 2420 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-156 [EURO-OBD] DTC P0745 LINE PRESSURE SOLENOID VALVE Wiring Diagram — AT — LPSVECS004RV TCWA0046E

Page 2421 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0745 LINE PRESSURE SOLENOID VALVE AT-157 [EURO-OBD] D E F G H I J K L MA B AT TERMINALS AND REFERENCE VALUE MEASURED BETWEEN EACH TERMINAL Diagnostic ProcedureECS004RW 1. CHECK INPUT SIGNAL W

Page 2422 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-158 [EURO-OBD] DTC P0745 LINE PRESSURE SOLENOID VALVE 2. CHECK DROPPING RESISTOR 1. Turn ignition switch OFF. 2. Disconnect dropping resistor harness connector in engine room. 3. Check resistance

Page 2423 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0745 LINE PRESSURE SOLENOID VALVE AT-159 [EURO-OBD] D E F G H I J K L MA B AT 4. CHECK HARNESS BETWEEN TCM AND TERMINAL CORD ASSEMBLY HARNESS CONNECTOR 1. Turn ignition switch OFF. 2. Disconne

Page 2424 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-160 [EURO-OBD] DTC P0745 LINE PRESSURE SOLENOID VALVE Component InspectionECS004RX LINE PRESSURE SOLENOID VALVE For removal, refer to AT- 4 0 4 , "Control Valve Assembly and Accumulators" . Res
