Page 2377 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR) AT-113 [EURO-OBD] D E F G H I J K L MA B AT 2. Drive vehicle and check for an increase of “VHCL/S SE·MTR” value increase. If the check re

Page 2378 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-114 [EURO-OBD] DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR) Wiring Diagram — AT — VSSA/TECS004R5 TCWA0231E

Page 2379 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR) AT-115 [EURO-OBD] D E F G H I J K L MA B AT TERMINALS AND REFERENCE VALUE MEASURED BETWEEN EACH TERMINAL Diagnostic ProcedureECS004R6 1. CHEC

Page 2380 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-116 [EURO-OBD] DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR) 2. CHECK REVOLUTION SENSOR With CONSULT-II 1. Start engine. 2. Check power supply to revolution sensor by voltage between

Page 2381 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR) AT-117 [EURO-OBD] D E F G H I J K L MA B AT 3. CHECK POWER AND SENSOR GROUND 1. Turn ignition switch OFF. 2. Disconnect the revolution sensor

Page 2382 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-118 [EURO-OBD] DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR) 6. CHECK HARNESS BETWEEN TCM AND REVOLUTION SENSOR (POWER) 1. Turn ignition switch OFF. 2. Disconnect the TCM connector and

Page 2383 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P0725 ENGINE SPEED SIGNAL AT-119 [EURO-OBD] D E F G H I J K L MA B AT DTC P0725 ENGINE SPEED SIGNALPFP:24825 DescriptionECS004R7 The engine speed signal is sent from the ECM to the TCM. On Board

Page 2384 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-120 [EURO-OBD] DTC P0725 ENGINE SPEED SIGNAL WITHOUT CONSULT-II 1. Start engine. 2. Drive vehicle under the following conditions for more than 5 sec- onds. Selector lever: D position (O/D ON) Ve
