2005 NISSAN X-TRAIL Fuel injector and fuel tube

GI-6
PRECAUTIONS

CAUTION:

Do not use home heating oil, gasoline or other alternate fuels in your diesel engine. The use of
those can cause engine damage.

Do not use summer fuel at temperatures below –7°C (20°F). The cold temperatures will cause wax
to form in the fuel. As a result, it may prevent the engine from running smoothly.

Do not add gasoline or other alternate fuels to diesel fuel.
Precautions for Multiport Fuel Injection System or Engine Control SystemEAS000FT

Before connecting or disconnecting any harness connector for
the multiport fuel injection system or ECM:
Turn ignition switch to “OFF” position.
Disconnect negative battery terminal.
Otherwise, there may be damage to ECM.

Before disconnecting pressurized fuel line from fuel pump to
injectors, be sure to release fuel pressure.

Be careful not to jar components such as ECM and mass air
flow sensor.
Precautions for Turbocharger (If Equipped)EAS000FU
The turbocharger turbine revolves at extremely high speeds and
becomes very hot. Therefore, it is essential to maintain a clean sup-
ply of oil flowing through the turbocharger and to follow all required
maintenance instructions and operating procedures.

Always use the recommended oil. Follow the instructions for
proper time to change the oil and proper oil level.

Avoid accelerating engine to a high rpm immediately after start-
ing.

If engine had been operating at high rpm for an extended period
of time, let it idle for a few minutes prior to shutting if off.
Precautions for HosesEAS000FV
HOSE REMOVAL AND INSTALLATION

To prevent damage to rubber hose, do not pry off rubber hose
with tapered tool or screwdriver.

To reinstall the rubber hose securely, make sure that hose inser-
tion length and orientation is correct. (If tube is equipped with
hose stopper, insert rubber hose into tube until it butts up
against hose stopper.)
SGI787
SGI292
SMA019D
SMA020D

EM-1
ENGINE MECHANICAL
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EM
A
EM

ENGINE MECHANICAL
QR
PRECAUTIONS .......................................................... 5
Precautions for Drain Engine Coolant ...................... 5
Precautions for Disconnecting Fuel Piping .............. 5
Precautions for Removal and Disassembly ............. 5
Precautions for Inspection, Repair and Replace-
ment ......................................................................... 5
Precautions for Assembly and Installation ............... 5
Parts Requiring Angle Tightening ............................. 5
Precautions for Liquid Gasket .................................. 6
REMOVAL OF LIQUID GASKET .......................... 6
LIQUID GASKET APPLICATION PROCEDURE ..... 6
PREPARATION ........................................................... 7
Special Service Tools ............................................... 7
Commercial Service Tools ........................................ 9
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ...............................................11
NVH Troubleshooting — Engine Noise ................... 11
Use the Chart Below to Help You Find the Cause
of the Symptom. ..................................................... 12
DRIVE BELTS ........................................................... 13
Checking Drive Belts .............................................. 13
Tension Adjustment ................................................ 13
Removal and Installation ........................................ 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 14
Removal and Installation of Drive Belt Auto-Ten-
sioner ..................................................................... 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 15
AIR CLEANER AND AIR DUCT ............................... 16
Removal and Installation ........................................ 16
REMOVAL ........................................................... 16
INSTALLATION ................................................... 17
Changing Air Cleaner Filter .................................... 17
REMOVAL ........................................................... 17
INSTALLATION ................................................... 17
INTAKE MANIFOLD ................................................. 18
Removal and Installation (QR20DE) ...................... 18
REMOVAL ........................................................... 18INSTALLATION ................................................... 19
INSPECTION AFTER INSTALLATION ................ 20
Removal and Installation (QR25DE) ...................... 21
REMOVAL ........................................................... 21
INSPECTION AFTER REMOVAL ....................... 23
INSTALLATION ................................................... 23
INSPECTION AFTER INSTALLATION ................ 24
EXHAUST MANIFOLD AND THREE WAY CATA-
LYST .......................................................................... 25
Removal and Installation ........................................ 25
REMOVAL ........................................................... 25
INSPECTION AFTER REMOVAL ....................... 26
INSTALLATION ................................................... 26
OIL PAN AND OIL STRAINER ................................. 27
Removal and Installation ........................................ 27
REMOVAL ........................................................... 27
INSPECTION AFTER REMOVAL ....................... 29
INSTALLATION ................................................... 29
INSPECTION AFTER INSTALLATION ................ 30
IGNITION COIL ......................................................... 31
Removal and Installation ........................................ 31
REMOVAL ........................................................... 31
INSTALLATION ................................................... 31
SPARK PLUG ........................................................... 32
Removal and Installation ........................................ 32
REMOVAL ........................................................... 32
INSPECTION AFTER REMOVAL (EXCEPT
RUSSIA) .............................................................. 32
INSPECTION AFTER REMOVAL (FOR RUS-
SIA) ..................................................................... 33
INSTALLATION ................................................... 33
FUEL INJECTOR AND FUEL TUBE ........................ 34
Removal and Installation (QR20DE) ...................... 34
REMOVAL ........................................................... 34
INSTALLATION ................................................... 36
INSPECTION AFTER INSTALLATION ................ 38
Removal and Installation (QR25DE) ...................... 39
REMOVAL ........................................................... 39
INSTALLATION ................................................... 41
INSPECTION AFTER INSTALLATION ................ 43

EM-3
C
D
E
F
G
H
I
J
K
L
M
EMA

YD22DDTi
PRECAUTIONS ...................................................... 130
Precautions for Draining Engine Coolant ............. 130
Precautions for Disconnecting Fuel Piping .......... 130
Precautions for Removal and Disassembly ......... 130
Precautions for Inspection, Repair and Replace-
ment ..................................................................... 130
Precautions for Assembly and Installation ........... 130
Parts Requiring Angle Tightening ......................... 130
Precautions For Liquid Gasket ............................. 131
REMOVAL OF LIQUID GASKET ...................... 131
LIQUID GASKET APPLICATION PROCEDURE . 131
PREPARATION ....................................................... 132
Special Service Tools ........................................... 132
Commercial Service Tools .................................... 136
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ............................................ 138
NVH Troubleshooting — Engine Noise ................ 138
Use the Chart Below to Help You Find the Cause
of the Symptom. ................................................... 139
DRIVE BELTS ......................................................... 140
Checking Drive Belts ............................................ 140
Tension Adjustment .............................................. 140
A/C COMPRESSOR BELT ............................... 141
ALTERNATOR AND WATER PUMP BELT ....... 141
Removal and Installation ...................................... 141
REMOVAL ......................................................... 141
INSTALLATION ................................................. 141
AIR CLEANER AND AIR DUCT ............................. 142
Removal and Installation ...................................... 142
REMOVAL ......................................................... 142
INSTALLATION ................................................. 142
CHANGING AIR CLEANER FILTER ................. 143
CHARGE AIR COOLER ......................................... 144
Removal and Installation ...................................... 144
REMOVAL ......................................................... 144
INSPECTION AFTER REMOVAL ..................... 144
INSTALLATION ................................................. 144
INTAKE MANIFOLD ............................................... 146
Removal and Installation ...................................... 146
REMOVAL ......................................................... 146
INSPECTION AFTER REMOVAL ..................... 147
INSTALLATION ................................................. 147
INSPECTION AFTER INSTALLATION ............. 148
CATALYST .............................................................. 149
Removal and Installation ...................................... 149
REMOVAL ......................................................... 149
INSTALLATION ................................................. 150
EXHAUST MANIFOLD AND TURBOCHARGER .. 151
Removal and Installation ...................................... 151
REMOVAL ......................................................... 151
INSTALLATION ................................................. 152
INSPECTION AFTER INSTALLATION ............. 152
Disassembly and Assembly ................................. 153
DISASSEMBLY ................................................. 153
ASSEMBLY ....................................................... 153INSPECTION AFTER DISASSEMBLY ..............154
Turbocharger ........................................................154
ROTOR SHAFT CLEARANCE ..........................154
ROTOR SHAFT END PLAY ..............................155
TURBINE WHEEL .............................................155
COMPRESSOR WHEEL ...................................155
TURBOCHARGER BOOST CONTROL ACTU-
ATOR .................................................................155
TROUBLE DIAGNOSIS OF TURBOCHARGER .156
OIL PAN AND OIL STRAINER ...............................157
Removal and Installation ......................................157
REMOVAL .........................................................157
INSPECTION AFTER REMOVAL .....................159
INSTALLATION .................................................159
INSPECTION AFTER INSTALLATION ..............161
GLOW PLUG ..........................................................162
Removal and Installation ......................................162
REMOVAL .........................................................162
INSTALLATION .................................................162
VACUUM PUMP ......................................................163
Removal and Installation ......................................163
INSPECTION BEFORE REMOVAL ..................163
REMOVAL .........................................................163
INSTALLATION .................................................164
INSPECTION AFTER INSTALLATION ..............165
Disassembly and Assembly ..................................165
DISASSEMBLY .................................................165
ASSEMBLY .......................................................166
INJECTION TUBE AND FUEL INJECTOR ............167
Removal and Installation ......................................167
REMOVAL .........................................................167
INSTALLATION .................................................169
INSPECTION AFTER INSTALLATION ..............170
FUEL PUMP ............................................................171
Removal and Installation ......................................171
REMOVAL .........................................................171
INSPECTION AFTER REMOVAL .....................175
INSTALLATION .................................................175
ROCKER COVER ...................................................178
Removal and Installation ......................................178
REMOVAL .........................................................178
INSTALLATION .................................................179
INSPECTION AFTER INSTALLATION ..............179
CAMSHAFT ............................................................180
Removal and Installation ......................................180
REMOVAL .........................................................180
INSPECTION AFTER REMOVAL .....................181
INSTALLATION .................................................184
Valve Clearance ...................................................185
INSPECTION ....................................................185
ADJUSTMENTS ................................................187
OIL SEAL ................................................................190
Removal and Installation of Valve Oil Seal ...........190
REMOVAL .........................................................190
INSTALLATION .................................................190
Removal and Installation of Front Oil Seal ...........191
REMOVAL .........................................................191

INTAKE MANIFOLD
EM-19
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM

b. Loosen mounting bolts in reverse order as shown in the figure,
and remove electric throttle control actuator and gasket.
CAUTION:

Handle carefully to avoid any shock to electric throttle
control actuator.

Do not disassemble.
5. Disconnect harness, power steering piping, vacuum hose and PCV hose from intake manifold, and move
them aside.
6. Remove intake manifold support and gasket.
7. Disconnect sub-harness from fuel injector. Refer to EM-34, "
Removal and Installation (QR20DE)" .
8. Loosen mounting bolts and nuts in reverse order as shown in
the figure, and remove intake manifold (with fuel tube and fuel
injector assembly) and gasket.
CAUTION:

Do not disassemble intake manifold.

Cover engine openings to avoid entry of foreign materi-
als.
NOTE:
Disregard No. 6 when loosening.
9. Remove fuel tube and fuel injector assembly from intake manifold. Refer to EM-34, "
Removal and Installa-
tion (QR20DE)" .
10. Remove EVAP canister purge volume control solenoid valve from intake manifold, if necessary.
INSTALLATION
Note the following, and install in the reverse order of removal.
Intake Manifold

If stud bolts were removed, install them and tighten to the specified torque below.

Check if gasket is not dropped from the installation groove of intake manifold.

Tighten in numerical order as shown in the figure.
NOTE:
No. 6 means double tightening of bolt No. 1.
EMJ1612D
PBIC2173E
: 10.8 N·m (1.1 kg-m, 8 ft-lb)
PBIC2173E

EM-22
[QR]
INTAKE MANIFOLD

a. Disconnect harness connector.
b. Loosen mounting bolts in reverse order as shown in the figure,
and remove electric throttle control actuator and gasket.
CAUTION:

Handle carefully to avoid any shock to electric throttle
control actuator.

Do not disassemble.
5. Disconnect harness, vacuum hose and PCV hose from intake manifold collector, and move them aside.
6. Remove intake manifold rear support and intake manifold support.
7. Loosen mounting bolts and nuts in reverse order as shown in
the figure, and remove intake manifold collector and gasket.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
NOTE:
Disregard No. 8 when loosening.
8. Disconnect power steering piping from intake manifold, and move them aside.
9. Disconnect sub-harness from fuel injector. Refer to EM-39, "
Removal and Installation (QR25DE)" .
10. Loosen mounting bolts and nuts in reverse order as shown in
the figure, and remove intake manifold (with fuel tube and fuel
injector assembly) and gasket.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
NOTE:
Disregard No. 6 when loosening.
11. Remove fuel tube and fuel injector assembly from intake manifold. Refer to EM-39, "
Removal and Installa-
tion (QR25DE)" .
12. Remove EVAP canister purge volume control solenoid valve from intake manifold collector, if necessary.
13. Remove vacuum reservoir tank and VIAS control solenoid valve from intake manifold, if necessary.
EMJ1612D
SBIA0230E
SBIA0231E

EM-34
[QR]
FUEL INJECTOR AND FUEL TUBE

FUEL INJECTOR AND FUEL TUBEPFP:16600
Removal and Installation (QR20DE)EBS00KNH
CAUTION:
Do not remove or disassemble parts unless instructed as shown in the figure.
REMOVAL
1. Release fuel pressure. Refer to EC-49, "FUEL PRESSURE RELEASE" (WITH EURO-OBD) or EC-562,
"FUEL PRESSURE RELEASE" (WITHOUT EURO-OBD).
2. Remove air cleaner case upper, mass air flow sensor and air duct assembly. Refer to EM-16, "
AIR
CLEANER AND AIR DUCT" .
3. Disconnect quick connectors at engine side and vehicle side as
follows, and remove fuel feed hose.
CAUTION:
Disconnect quick connector by using quick connector
release (special service tool), not by picking out retainer
tabs.
NOTE:
There is quick connector for the engine side and for the vehicle
side, and they have different shapes. But disconnection is same
procedure. The following procedure shows the engine side.
a. Remove quick connector cap (engine side).
1. Fuel feed hose 2. Quick connector cap (engine side) 3. Quick connector cap (vehicle side)
4. Centralized under-floor piping 5. Sub-harness 6. Fuel tube protector
7. Fuel tube 8. O-ring (black) 9. Clip
10. Fuel injector 11. O-ring (green)
PBIC2178E
PBIC2175E
KBIA0701E

FUEL INJECTOR AND FUEL TUBE
EM-35
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM

b. With the sleeve side of quick connector release facing quick connector, install quick connector release
onto fuel tube.
c. Insert quick connector release into quick connector until sleeve
contacts and goes no further. Hold quick connector release on
that position.
CAUTION:
Inserting quick connector release hard will not disconnect
quick connector. Hold quick connector release where it
contacts and goes no further.
d. Draw and pull out quick connector straight from fuel tube.
CAUTION:

Pull quick connector holding “A” position in the figure.

Do not pull with lateral force applied. O-ring inside quick
connector may be damaged.

Prepare container and cloth beforehand as fuel will leak out.

Avoid fire and sparks.

Keep parts away from heat source. Especially, be careful when welding is performed around
them.

Do not expose parts to battery electrolyte or other acids.

Do not bend or twist connection between quick connector and fuel feed hose during installa-
tion/removal.

To keep clean the connecting portion and to avoid dam-
age and foreign materials, cover them completely with
plastic bags or something similar.
4. Remove PCV hose. Refer to EM-18, "
Removal and Installation (QR20DE)" .
5. Disconnect harness connector from ignition coil.
6. Remove sub-harness for fuel injector.
7. Remove electric throttle control actuator and intake manifold support. Refer to EM-18, "
Removal and
Installation (QR20DE)" .
8. Loosen mounting bolts in reverse order as shown in the figure.
9. Remove fuel tube protector.
10. Pull out fuel tube and fuel injector assembly rearward of engine.
CAUTION:

When removing, be careful to avoid any interference with fuel injector.

Use a shop cloth to absorb any fuel leaks from fuel tube.
KBIA0702E
PBIC2205E
PBIC2180E

EM-36
[QR]
FUEL INJECTOR AND FUEL TUBE

11. Remove fuel injector from fuel tube with the following procedure:
a. Open and remove clip.
b. Remove fuel injector from fuel tube by pulling straight.
CAUTION:

Be careful with remaining fuel that may go out from fuel
tube.

Be careful not to damage fuel injector nozzle during
removal.

Do not bump or drop fuel injector.

Do not disassemble fuel injector.
INSTALLATION
1. Note the following, and install O-rings to fuel injector.
CAUTION:

Upper and lower O-rings are different. Be careful not to confuse them.

Handle O-ring with bare hands. Do not wear gloves.

Lubricate O-ring with new engine oil.

Do not clean O-ring with solvent.

Make sure that O-ring and its mating part are free of foreign material.

When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not to
twist or stretch O-ring. If O-ring was stretched while it was being attached, do not insert it
quickly into fuel tube.

Insert O-ring straight into fuel tube. Do not decenter or twist it.
SBIA0364E
Fuel tube side : Black
Nozzle side : Green
