ATC-164
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
CompressorEJS00281
LubricantEJS00282
RefrigerantEJS00283
Engine Idling SpeedEJS00284
Refer to EC-45, "Idle Speed and Ignition Timing Check" for QR engine (WITH EURO-OBD), EC-558, "Idle
Speed and Ignition Timing Check" for QR engine (WITHOUT EURO-OBD), EC-1012, "Basic Inspection" for
YD engine (WITH EURO-OBD) or EC-1382, "
Basic Inspection" for YD engine (WITHOUT EURO-OBD).
Belt TensionEJS00285
Refer to EM-13, "DRIVE BELTS" for QR engine or EM-140, "DRIVE BELTS" for YD engine.
ModelWith QR engine With YD engine
Calsonic Kansei make CWV-615MZEXEL VALEO CLIMATE CONTROL make
DKV-11G
Type V-6 variable displacement Vane rotary
Displacement
cm
3 (cu in)/revMax. 146 (8.91)
110 (6.71)
Min. 13.5 (0.824)
Cylinder bore × stroke
mm (in)35.2 (1.386) × [2.3 - 25.0 (0.091 - 0.984)] -
Direction of rotation Clockwise (viewed from drive end)
Drive beltPoly V
ModelWith QR engine With YD engine
Calsonic Kansei make CWV-615MZEXEL VALEO CLIMATE CONTROL
make DKV-11G
Name Nissan A/C System Oil Type S (DH-PS) Nissan A/C System Oil Type R (DH-PR)
Part number KLH00-PAGS0 KLH00-PAGR0
Capacity
m (lmp fl oz)Total in system 180 (6.3)
Compressor (Service part)
charging amount180 (6.3)
Ty p eHFC-134a (R-134a)
Capacity
kg (lb)0.55 (1.21)
