NISSAN X-TRAIL 2005 Service Repair Manual OIL PUMP
LU-31
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU

Measure the clearance with the feeler gauge and the straight-
edge.
Side clearance between inner rotor and oil pump housing (posi-
tion 3)
Side c

Page 354 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual LU-32
[YD22DDTi]
OIL PUMP

ASSEMBLY
Assembly is the reverse order of disassembly.
Install inner rotor and outer rotor with the punched marks on the
oil pump cover side.
JLC286B

Page 355 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
LU-33
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00CTZ
OIL PRESSURE
OIL PUMP
Unit: mm (in)
REGULAT

Page 356 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual LU-34
[YD22DDTi]
SERVICE DATA AND SPECIFICATIONS (SDS)

Page 357 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION CO
A
CO

ENGINE COOLING SYSTEM
QR
PRECAUTIONS .......................................................... 3
Precautions for

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION CO
A
CO

ENGINE COOLING SYSTEM
QR
PRECAUTIONS .......................................................... 3
Precautions for Liquid Gasket .................................. 3
LIQUID GASKET APPLICATION PROCEDURE ..... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
OVERHEATING CAUSE ANALYSIS .......................... 5
Troubleshooting Chart .............................................. 5
COOLING SYSTEM .................................................... 7
Cooling Circuit .......................................................... 7
System Chart ........................................................... 8
ENGINE COOLANT .................................................... 9
Inspection ................................................................. 9
LEVEL CHECK ..................................................... 9
LEAK CHECK ....................................................... 9
Changing Engine Coolant ........................................ 9
DRAINING ENGINE COOLANT ........................... 9
REFILLING ENGINE COOLANT ........................ 10
FLUSHING COOLING SYSTEM ......................... 10
RADIATOR ................................................................ 12
Removal and Installation ........................................ 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 13
INSPECTION AFTER INSTALLATION ............... 13
Checking Radiator Cap .......................................... 13
Checking Radiator .................................................. 13
RADIATOR (ALUMINUM TYPE) .............................. 15
Disassembly and Assembly ................................... 15
PREPARATION ................................................... 15
DISASSEMBLY ................................................... 15
ASSEMBLY ......................................................... 16
INSPECTION ...................................................... 18
COOLING FAN ......................................................... 19
Removal and Installation ........................................ 19
REMOVAL ........................................................... 19INSTALLATION ................................................... 19
Disassembly and Assembly .................................... 20
DISASSEMBLY ................................................... 20
INSPECTION AFTER DISASSEMBLY ................ 20
ASSEMBLY ......................................................... 20
WATER PUMP .......................................................... 21
Removal and Installation ........................................ 21
REMOVAL ........................................................... 21
INSPECTION AFTER REMOVAL ....................... 22
INSTALLATION ................................................... 22
INSPECTION AFTER INSTALLATION ................ 22
THERMOSTAT AND WATER CONTROL VALVE .... 23
Removal and Installation ........................................ 23
REMOVAL ........................................................... 23
INSPECTION AFTER REMOVAL ....................... 24
INSTALLATION ................................................... 24
INSPECTION AFTER INSTALLATION ................ 24
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 25
Standard and Limit .................................................. 25
CAPACITY ........................................................... 25
RADIATOR .......................................................... 25
THERMOSTAT .................................................... 25
WATER CONTROL VALVE ................................. 25
Tightening Torque ................................................... 25
YD22DDTi
PRECAUTIONS ........................................................ 26
Precautions For Liquid Gasket ............................... 26
LIQUID GASKET APPLICATION PROCEDURE ... 26
PREPARATION ......................................................... 27
Special Service Tools ............................................. 27
Commercial Service Tools ...................................... 27
OVERHEATING CAUSE ANALYSIS ........................ 28
Troubleshooting Chart ............................................ 28
COOLING SYSTEM .................................................. 30
Cooling Circuit ........................................................ 30
System Chart .......................................................... 31
ENGINE COOLANT .................................................. 32
Inspection ............................................................... 32

Page 358 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual CO-2 LEVEL CHECK .................................................... 32
CHECKING RADIATOR SYSTEM FOR LEAKS ... 32
Changing Engine Coolant ....................................... 32
DRAINING ENGINE C

CO-2 LEVEL CHECK .................................................... 32
CHECKING RADIATOR SYSTEM FOR LEAKS ... 32
Changing Engine Coolant ....................................... 32
DRAINING ENGINE COOLANT .......................... 32
REFILLING ENGINE COOLANT ......................... 33
FLUSHING COOLING SYSTEM ......................... 34
RADIATOR ................................................................ 35
Removal and Installation ........................................ 35
REMOVAL ........................................................... 35
INSTALLATION .................................................... 35
INSPECTION AFTER INSTALLATION ................ 35
Checking Radiator Cap .......................................... 36
Checking Radiator .................................................. 36
COOLING FAN .......................................................... 37
Removal and Installation ........................................ 37
REMOVAL ........................................................... 37
INSTALLATION .................................................... 37
DISASSEMBLY AND ASSEMBLY ....................... 37
RADIATOR (ALUMINUM TYPE) ............................... 39
Disassembly and Assembly .................................... 39
PREPARATION ................................................... 39
DISASSEMBLY ................................................... 39
ASSEMBLY ......................................................... 40
INSPECTION ....................................................... 42WATER PUMP ........................................................... 43
Removal and Installation ......................................... 43
REMOVAL ............................................................ 43
INSPECTION AFTER REMOVAL ........................ 44
INSTALLATION .................................................... 44
INSPECTION AFTER INSTALLATION ................ 44
THERMOSTAT AND WATER PIPING ....................... 45
Removal and Installation ......................................... 45
REMOVAL ............................................................ 45
INSPECTION AFTER REMOVAL ........................ 46
INSTALLATION .................................................... 46
INSPECTION AFTER INSTALLATION ................ 46
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 47
Standard and Limit .................................................. 47
CAPACITY ........................................................... 47
THERMOSTAT ..................................................... 47
RADIATOR ........................................................... 47
Tightening Torque ................................................... 47

Page 359 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual PRECAUTIONS
CO-3
[QR]
C
D
E
F
G
H
I
J
K
L
MA
CO

[QR]PRECAUTIONSPFP:00001
Precautions for Liquid GasketEBS00MRX
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid

Page 360 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual CO-4
[QR]
PREPARATION

PREPARATIONPFP:00002
Special Service ToolsEBS00KOC
Commercial Service ToolsEBS011T8
Tool number
Tool nameDescription
EG17650301
Radiator cap tester adapterAdapting radiator cap
