DTC P0172 FUEL INJECTION SYSTEM FUNCTION . 225
On Board Diagnosis Logic ................................... 225
DTC Confirmation Procedure ............................... 225
Wiring Diagram .................................................... 227
Diagnostic Procedure ........................................... 228
DTC P0222, P0223 TP SENSOR ........................... 231
Component Description ........................................ 231
CONSULT-II Reference Value in Data Monitor Mode
. 231
On Board Diagnosis Logic ................................... 231
DTC Confirmation Procedure ............................... 231
Wiring Diagram .................................................... 233
Diagnostic Procedure ........................................... 235
Component Inspection ......................................... 238
Removal and Installation ...................................... 238
DTC P0300 - P0304 MULTIPLE CYLINDER MIS-
FIRE, NO. 1 - 4 CYLINDER MISFIRE ..................... 239
On Board Diagnosis Logic ................................... 239
DTC Confirmation Procedure ............................... 239
Diagnostic Procedure ........................................... 240
DTC P0327, P0328 KS ........................................... 245
Component Description ........................................ 245
On Board Diagnosis Logic ................................... 245
DTC Confirmation Procedure ............................... 245
Wiring Diagram .................................................... 246
Diagnostic Procedure ........................................... 247
Component Inspection ......................................... 249
Removal and Installation ...................................... 249
DTC P0335 CKP SENSOR (POS) .......................... 250
Component Description ........................................ 250
CONSULT-II Reference Value in Data Monitor Mode
. 250
On Board Diagnosis Logic ................................... 250
DTC Confirmation Procedure ............................... 250
Wiring Diagram .................................................... 251
Diagnostic Procedure ........................................... 253
Component Inspection ......................................... 255
Removal and Installation ...................................... 256
DTC P0340 CMP SENSOR (PHASE) ..................... 257
Component Description ........................................ 257
On Board Diagnosis Logic ................................... 257
DTC Confirmation Procedure ............................... 257
Wiring Diagram .................................................... 258
Diagnostic Procedure ........................................... 259
Component Inspection ......................................... 262
Removal and Installation ...................................... 263
DTC P0420 THREE WAY CATALYST FUNCTION . 264
On Board Diagnosis Logic ................................... 264
DTC Confirmation Procedure ............................... 264
Overall Function Check ........................................ 265
Diagnostic Procedure ........................................... 266
DTC P0444 EVAP CANISTER PURGE VOLUME
CONTROL SOLENOID VALVE .............................. 269
Description ........................................................... 269
CONSULT-II Reference Value in Data Monitor Mode
. 269
On Board Diagnosis Logic ................................... 269
DTC Confirmation Procedure ............................... 270
Wiring Diagram .................................................... 271Diagnostic Procedure ...........................................273
Component Inspection ..........................................275
Removal and Installation ......................................275
DTC P0500 VSS ......................................................276
Description ............................................................276
On Board Diagnosis Logic ....................................276
DTC Confirmation Procedure ...............................276
Overall Function Check ........................................276
Diagnostic Procedure ...........................................277
DTC P0550 PSP SENSOR .....................................278
Component Description ........................................278
CONSULT-II Reference Value in Data Monitor Mode
.278
On Board Diagnosis Logic ....................................278
DTC Confirmation Procedure ...............................278
Wiring Diagram .....................................................279
Diagnostic Procedure ...........................................280
Component Inspection ..........................................282
Removal and Installation ......................................282
DTC P0605 ECM .....................................................283
Component Description ........................................283
On Board Diagnosis Logic ....................................283
DTC Confirmation Procedure ...............................283
Diagnostic Procedure ...........................................284
DTC P1065 ECM POWER SUPPLY .......................286
Component Description ........................................286
On Board Diagnosis Logic ....................................286
DTC Confirmation Procedure ...............................286
Wiring Diagram .....................................................287
Diagnostic Procedure ...........................................288
DTC P1111 IVT CONTROL SOLENOID VALVE .....290
Component Description ........................................290
CONSULT-II Reference Value in Data Monitor Mode
.290
On Board Diagnosis Logic ....................................290
DTC Confirmation Procedure ...............................290
Wiring Diagram .....................................................291
Diagnostic Procedure ...........................................292
Component Inspection ..........................................293
Removal and Installation ......................................293
DTC P1121 ELECTRIC THROTTLE CONTROL
ACTUATOR .............................................................294
Component Description ........................................294
On Board Diagnosis Logic ....................................294
DTC Confirmation Procedure ...............................294
Diagnostic Procedure ...........................................295
Removal and Installation ......................................295
DTC P1122 ELECTRIC THROTTLE CONTROL
FUNCTION ..............................................................296
Description ............................................................296
On Board Diagnosis Logic ....................................296
DTC Confirmation Procedure ...............................296
Wiring Diagram .....................................................297
Diagnostic Procedure ...........................................301
Component Inspection ..........................................304
Removal and Installation ......................................305
DTC P1124, P1126 THROTTLE CONTROL MOTOR
RELAY .....................................................................306
Component Description ........................................306

DTC P0011 IVT CONTROL
EC-137
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

On Board Diagnosis LogicEBS010MI
The MI will not light up for this diagnosis.
FAIL-SAFE MODE
ECM enters in fail-safe mode when the malfunction is detected.
DTC Confirmation ProcedureEBS010MJ
CAUTION:
Always drive at a safe speed.
NOTE:

If DTC P0011 is displayed with DTC P1111, first perform trouble diagnosis for DTC P1111. See EC-
290, "DTC P1111 IVT CONTROL SOLENOID VALVE" .

If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait
at least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is between 10V and 16V at
idle.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode with
CONSULT-II.
2. Start engine and warm it up to the normal operating tempera-
ture.
3. Maintain the following conditions for at least 6 consecutive sec-
onds.
Hold the accelerator pedal as steady as possible.
4. Let engine idle for 10 seconds.
5. If the 1st trip DTC is detected, go to EC-138, "
Diagnostic Procedure" .
If the 1st trip DTC is not detected, go to next step.
6. Maintain the following conditions for at least 20 consecutive seconds.
7. If 1st trip DTC is detected, go to EC-138, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II” above.
DTC No.Trouble diagnosis
nameDetecting condition Possible cause
P0011
0011Intake valve timing
control performanceThere is a gap between angle of target and
phase-control angle degree.

Crankshaft position sensor (POS)

Camshaft position sensor (PHASE)

Accumulation of debris to the signal pick-up
portion of the camshaft
Detected items Engine operating condition in fail-safe mode
Intake valve timing control The signal is not energized to the solenoid valve and the valve control does not function
ENG SPEED 1,200 - 2,000 rpm (A constant rotation is maintained.)
COOLANT TEMPS 60 - 120°C (176 - 194°F)
Shift leverA/T: P or N position
M/T: Neutral position
ENG SPEED 1,700 - 3,175 rpm (A constant rotation is maintained.)
COOLANT TEMPS 70 - 105°C (176 - 194°F)
Shift lever 1st or 2nd position
Driving location uphillDriving vehicle uphill
(Increased engine load will help maintain the driving
conditions required for this test.)
SEF174Y

EC-290
[QR (WITH EURO-OBD)]
DTC P1111 IVT CONTROL SOLENOID VALVE

D T C P 1111 I V T C O N T R O L S O L E N O I D VA LV EPFP:23796
Component DescriptionEBS010R5
Intake valve timing control solenoid valve is activated by ON/OFF
pulse duty (ratio) signals from the ECM.
The intake valve timing control solenoid valve changes the oil
amount and direction of flow through intake valve timing control unit
or stops oil flow.
The longer pulse width advances valve angle.
The shorter pulse width retards valve angle.
When ON and OFF pulse widths become equal, the solenoid valve
stops oil pressure flow to fix the intake valve angle at the control
position.
CONSULT-II Reference Value in Data Monitor ModeEBS010R6
Specification data are reference values.
On Board Diagnosis LogicEBS010R7
DTC Confirmation ProcedureEBS010R8
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
WITH CONSULT-II
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and let it idle for 5 seconds.
4. If 1st trip DTC is detected, go to EC-292, "
Diagnostic Procedure"
.
WITH GST
Following the procedure “WITH CONSULT-II” above.
PBIB1842E
MONITOR ITEM CONDITION SPECIFICATION
INT/V SOL (B1)

Engine: After warming up

Air conditioner switch: OFF

Shift lever: P or N (A/T), Neutral
(M/T)

No loadIdle 0% - 2%
2,000 rpm Approx. 0% - 50%
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P 1111
1111Intake valve timing control
solenoid valve circuitAn improper voltage is sent to the ECM
through intake valve timing control solenoid
valve.

Harness or connectors
(Solenoid valve circuit is open or shorted.)

Intake valve timing control solenoid valve
SEF058Y

DTC P1111 IVT CONTROL SOLENOID VALVE
EC-291
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Wiring DiagramEBS010R9
TBWA0612E

EC-292
[QR (WITH EURO-OBD)]
DTC P1111 IVT CONTROL SOLENOID VALVE

Specification data are reference values and are measured between each terminal and ground.
Pulse signal is measured by CONSULT-II.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
Diagnostic ProcedureEBS010RA
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect intake valve timing control solenoid valve harness connector.
3. Turn ignition switch ON.
4. Check voltage between intake valve timing control solenoid
valve terminal 1 and ground with CONSULT-II or tester.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. DETECT MALFUNCTION PART
Check harness for open or short between intake valve timing control solenoid valve and ECM relay.
>> Repair or replace harness or connectors.
TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
62 YIntake valve timing
control solenoid valve[Engine is running]

Warm-up condition

Idle speedBATTERY VOLTAGE
(11 - 14V)
[Engine is running]

Warm-up condition

Engine speed is 2,000 rpmApproximately 4V - BATTERY
VOLTAGE (11 - 14V)
PBIB1790E
PBIB0511E
Voltage: Battery voltage
PBIB0285E

DTC P1111 IVT CONTROL SOLENOID VALVE
EC-293
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

3. CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE OUTPUT SIGNAL CIRCUIT FOR
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness continuity between intake valve timing control solenoid valve terminal 2 and ECM terminal
62. Refer to Wiring Diagram.
4. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Refer to EC-293, "
Component Inspection" .
OK or NG
OK >> GO TO 5.
NG >> Replace intake valve timing control solenoid valve.
5. CHECK INTERMITTENT INCIDENT
Refer to EC-124, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>>INSPECTION END
Component InspectionEBS010RB
INTAKE VALVE TIMING CONTROL SOLENOID VALVE
1. Disconnect intake valve timing control solenoid valve harness connector.
2. Check resistance between intake valve timing control solenoid
valve terminals 1 and 2 under the following conditions.
Removal and InstallationEBS010RC
INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Refer to EM-46, "TIMING CHAIN" . Continuity should exist.
Terminals Resistance
1 and 2 Approximately 8Ω [at 20°C (68°F)]
1 or 2 and ground∞Ω
(Continuity should not exist)
MBIB0027E
