Page 3857 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual LICENSE LAMP FINISHER EI-31 C D E F G H J K L MA B EI LICENSE LAMP FINISHERPFP:84810 Removal and InstallationEIS001NV REMOVAL 1. Remove back door finisher. Refer to EI-34, "Removal and Installation"

Page 3858 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-32 DOOR FINISHER DOOR FINISHERPFP:80900 Removal and InstallationEIS000N9 FRONT AND REAR Removal 1. Insert a screwdriver, wrapped with a cloth, into door trim cutout on the inside handle escutcheo

Page 3859 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DOOR FINISHER EI-33 C D E F G H J K L MA B EI 2. Insert a screwdriver, wrapped with a cloth, into the cutout on the front edge of power window switch finisher. Unfasten the metal clip on the front s

Page 3860 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-34 BACK DOOR TRIM BACK DOOR TRIMPFP:90900 Removal and InstallationEIS000NA REMOVAL 1. Remove clips of back door trim. 2. Remove back door trim. CAUTION: Insert a clip driver or clip clamp remove

Page 3861 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual BODY SIDE TRIM EI-35 C D E F G H J K L MA B EI BODY SIDE TRIMPFP:76913 Removal and InstallationEIS000NB CAUTION: Wrap the tip of flat-bladed screwdriver with a cloth when removing metal clips from g

Page 3862 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-36 BODY SIDE TRIM CENTER PILLAR LOWER GARNISH Removal Remove front and rear kick panels. Installation Installation is in the reverse order of removal. CENTER PILLAR UPPER GARNISH Removal 1. Remov

Page 3863 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual BODY SIDE TRIM EI-37 C D E F G H J K L MA B EI CAUTION: Insert a screwdriver, wrapped with a cloth, into the part shown by an arrow (between the body side panel and clips). Remove clips. When inst

Page 3864 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-38 FLOOR TRIM FLOOR TRIMPFP:74902 Removal and InstallationEIS000NC REMOVAL 1. Remove front seat and rear seat cushions. Refer to SE-26, "Removal and Installation" and SE-34, "Removal and Install
