NISSAN X-TRAIL 2005 Service Repair Manual DTC P1260 - P1267 FUEL INJECTOR ADJUSTMENT RESISTOR EC-1253 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC Wiring DiagramEBS011DC TBWA0575E

Page 1658 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1254 [YD (WITH EURO-OBD)] DTC P1260 - P1267 FUEL INJECTOR ADJUSTMENT RESISTOR Specification data are reference values and are measured between each terminal and ground. CAUTION: Do not use ECM gr

Page 1659 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P1260 - P1267 FUEL INJECTOR ADJUSTMENT RESISTOR EC-1255 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC 2. CHECK FUEL INJECTOR ADJUSTMENT RESISTOR POWER SUPPLY CIRCUIT 1. Disconnect fuel injector

Page 1660 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1256 [YD (WITH EURO-OBD)] DTC P1260 - P1267 FUEL INJECTOR ADJUSTMENT RESISTOR 2. Check continuity between terminals as shown in the figure. If NG, replace fuel injector. Removal and InstallationE

Page 1661 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P1268 - P1271 FUEL INJECTOR EC-1257 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC DTC P1268 - P1271 FUEL INJECTORPFP:16600 Component DescriptionEBS011DG The fuel injector is a small, precise so

Page 1662 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1258 [YD (WITH EURO-OBD)] DTC P1268 - P1271 FUEL INJECTOR DTC Confirmation ProcedureEBS011DK CAUTION: Always drive vehicle in safe manner according to traffic conditions and obey all traffic laws

Page 1663 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DTC P1268 - P1271 FUEL INJECTOR EC-1259 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC Wiring DiagramEBS011DL TBWA0569E

Page 1664 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EC-1260 [YD (WITH EURO-OBD)] DTC P1268 - P1271 FUEL INJECTOR Specification data are reference values and are measured between each terminal and ground. Pulse signal is measured by CONSULT-II. CAUTIO
