Page 4113 of 4555
HIGH-MOUNTED STOP LAMP
LT-117
C
D
E
F
G
H
I
J
L
MA
B
LT
HIGH-MOUNTED STOP LAMPPFP:26590
Bulb ReplacementEKS0034W
Refer to LT- 9 9 , "Bulb Replacement" in “STOP LAMP”.
Removal and InstallationEKS0034X
Refer to LT- 9 9 , "Removal and Installation" in “STOP LAMP”.
Page 4114 of 4555
LT-118
REAR COMBINATION LAMP
REAR COMBINATION LAMP PFP:26554
Wiring Diagram —STOP/L— EKS003C6
TKWA1529E
Page 4115 of 4555
REAR COMBINATION LAMP
LT-119
C
D
E
F
G
H
I
J
L
MA
B
LT
Bulb ReplacementEKS00164
1. Remove rear combination lamp mounting bolts.
2. Pull rear combination lamp toward rear of vehicle. Disengage
locating pins.
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb.
5. Installation is the reverse order of removal.
Removal and InstallationEKS00165
REMOVAL
1. Remove luggage-side lower finisher. Refer to EI-35, "BODY
SIDE TRIM" in “EI EXTERIOR & INTERIOR” section.
2. Disconnect rear combination lamp connector.
3. Remove rear combination lamp mounting bolts.
4. Pull rear combination lamp rearward the vehicle. Disengage
locating pins.
5. Pull harness grommet and remove harness.
INSTALLATION
Installation is the reverse order of removal.Stop/tail lamp : 12V - 21/5W
Rear turn signal lamp : 12V - 21W
Back-up lamp : 12V - 21W
PKIC0923E
PKIA8620E
Rear combination lamp mounting bolts
: 5.4 N·m (0.55 kg-m, 48 in-lb)
Page 4116 of 4555
LT-120
COMBINATION SWITCH
COMBINATION SWITCHPFP:25567
Removal and InstallationEKS001V6
Refer to SRS-33, "SPIRAL CABLE" in “SUPPLEMENTAL RESTRAINT SYSTEM (SRS)” section.
Switch Circuit InspectionEKS001V7
Refer to LT- 9 6 , "Switch Circuit Inspection" in “LIGHTING AND TURN SIGNAL SWITCH”, and WW-8, "Te r m i -
nal and Reference Values for Combination Switch" , WW-16, "Terminal and Reference Values for Combination
Switch" in “Wiper, Washer&Horn (WW)” section.
Page 4117 of 4555
ASHTRAY ILLUMINATION
LT-121
C
D
E
F
G
H
I
J
L
MA
B
LT
ASHTRAY ILLUMINATIONPFP:25860
Bulb Replacement, Removal and InstallationEKS00F86
1. Remove the instrument center lower panel. Refer to IP-10,
"INSTRUMENT PANEL ASSEMBLY" in “IP” section.
2. Turn bulb socket counterclockwise and unlock it.
3. Pull the bulb from socket.
4. Installation is the reverse order of removal.Ashtray illumination lamp : 12V - 1.4W
PKIA6440E
Page 4118 of 4555

LT-122
ILLUMINATION
ILLUMINATIONPFP:27545
System Description EKS003C7
Power is supplied at all times
through 10A fuse (No. 31, located in fuse and fusible link box)
to lighting switch terminal 11.
The lighting switch must be in the 1ST or 2ND position for illumination.
The following chart shows the power and ground connector terminals for the components included in the illu-
mination system.
Component Connector No. Power terminal Ground terminal
Headlamp washier switch M23 4 3
Headlamp aiming switch M24 3 4
ESP off switch M25 3 4
Driving lamp switch M101 1 5
Door mirror remote control switch M26 10 3
Driver pocket lamp M119 1 2
4WD mode switch M39 5 6
Hazard switch M51 7 8
Rear window defogger switch M50 5 6
A/C auto amp. M52 12 11
Combination meter M45 60 63
Heater control panel M55 2 6
Audio unit (with cassette deck) M108 8 case ground
Audio unit (without cassette deck and
with NAVI)M47 1 case ground
Audio unit (without cassette deck and
without NAVI)M207 1 case ground
Cigarette lighter socket M301, M302 3 2
Ashtray illumination M303 5 6
A/T device M58 3 4
NAVI control unit M116, M117 25 1, 4
NAVI switch M113 2 3
Heated seat switch LH (LHD models) B212 5 6
Heated seat switch RH (LHD models) B213 5 6
Page 4119 of 4555
ILLUMINATION
LT-123
C
D
E
F
G
H
I
J
L
MA
B
LT
SchematicEKS003BL
TKWA1538E
Page 4120 of 4555
LT-124
ILLUMINATION
Wiring Diagram —ILL—EKS003BM
LHD MODELS
TKWB1133E
