Page 3849 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DOOR OUTSIDE MOLDING EI-23 C D E F G H J K L MA B EI 5. Reaching from inner side of door, use a clip clamp tool to disen- gage rear door outside molding from the pawl. NOTE: Insert clip clamp tool

Page 3850 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-24 SIDE GUARD MOLDING SIDE GUARD MOLDINGPFP:76840 Removal and InstallationEIS000N3 REMOVAL Side guard molding (front/rear) 1. Apply masking tape around outer circumference of side guard molding.

Page 3851 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DOOR OUTSIDE LOWER MOLDING EI-25 C D E F G H J K L MA B EI DOOR OUTSIDE LOWER MOLDINGPFP:82877 Removal and InstallationEIS000N4 REMOVAL Door outside molding (front/rear) 1. Remove clips of door outs

Page 3852 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-26 SIDE SILL PROTECTOR SIDE SILL PROTECTORPFP:86856 Removal and InstallationEIS000N5 REMOVAL 1. Remove screw and clip of side sill protector. 2. Remove side sill protector. INSTALLATION Installat

Page 3853 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual ROOF RAIL EI-27 C D E F G H J K L MA B EI ROOF RAILPFP:73820 Removal and Installation (for Hyper Roof Rail)EIS000N6 CAUTION: Be careful not to damage the body. REMOVAL 1. Remove driving lamp cap (fr

Page 3854 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-28 ROOF RAIL Removal and Installation (for Roof Rail)EIS008OQ CAUTION: Be careful not to damage the body. REMOVAL 1. Remove headlining. Refer to EI-35, "BODY SIDE TRIM" . 2. Remove roof rail moun

Page 3855 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual ROOF RAIL EI-29 C D E F G H J K L MA B EI 3. Remove roof rail bracket mounting nuts (front and rear). 4. Remove roof rail covers (or roof spoiler). For removal of roof spoiler, refer to EI-30, " ROO

Page 3856 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual EI-30 ROOF SPOILER ROOF SPOILERPFP:96030 Removal and InstallationEIS000N7 CAUTION: Be careful not to damage the body. REMOVAL 1. Remove headlining. Refer to EI-39, "Removal and Installation" . 2. Re
