SERVICE DATA AND SPECIFICATIONS (SDS)
PR-7
C
E
F
G
H
I
J
K
L
MA
B
PR
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsEDS0027D
Journal Axial PlayEDS0027E
Propeller Shaft RunoutEDS0027F
Applied model QR20DE, QR25DE, YD22DDTi
Propeller shaft model 3F63A-DOJ75
Number of joints3
Coupling method with transfer Flange
Type of journal bearings Shell type (Non-disassembly type)
Shaft length 1st (spider to cardan joint center) 1,041 mm (40.98 in)
2nd (cardan joint center to spider) 934mm (36.77 in)
Shaft outer diameter1st 63.5 mm (2.500 in)
2nd 70.0 mm (2.76 in)
Model3F63A-DOJ75
Journal axial play0 mm (0 in)
Model3F63A-DOJ75
Propeller shaft runout limit 0.6 mm (0.024 in) or less
Page 2890 of 4555
PR-8
SERVICE DATA AND SPECIFICATIONS (SDS)
Page 2891 of 4555

RFD-1
REAR FINAL DRIVE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION RFD
A
B
RFD
REAR FINAL DRIVE
PRECAUTIONS .......................................................... 2
Service Notice or Precautions .................................. 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
Commercial Service Tools ........................................ 4
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 6
NVH Troubleshooting Chart ..................................... 6
REAR FINAL DRIVE SYSTEM ................................... 7
Sectional View .......................................................... 7
DIFFERENTIAL GEAR OIL ........................................ 8
Changing Differential Gear Oil ................................. 8
DRAINING ............................................................. 8
FILLING ................................................................. 8
Checking Differential Gear Oil .................................. 8
OIL LEAKAGE AND OIL LEVEL ........................... 8
FRONT OIL SEAL ...................................................... 9
Removal and Installation .......................................... 9
REMOVAL ............................................................. 9
INSTALLATION ..................................................... 9
SIDE OIL SEAL .........................................................11
Removal and Installation ......................................... 11
REMOVAL ............................................................ 11
INSTALLATION .................................................... 11
ELECTRIC CONTROLLED COUPLING .................. 12
Removal and Installation ........................................ 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 13REAR FINAL DRIVE ASSEMBLY ............................ 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 15
Components ........................................................... 16
Pre-Inspection ........................................................ 17
TOTAL PRELOAD ............................................... 17
DRIVE GEAR TO DRIVE PINION BACKLASH ... 18
DRIVE GEAR RUNOUT ...................................... 19
COMPANION FLANGE RUNOUT ....................... 19
TOOTH CONTACT .............................................. 19
Disassembly and Assembly .................................... 22
DISASSEMBLY ................................................... 22
ASSEMBLY ......................................................... 25
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 32
General Specification ............................................. 32
Drive Gear Vibration ............................................... 32
Total Preload ........................................................... 32
Side Gear Clearance Adjustment ........................... 32
Drive Pinion Gear Preload Adjustment ................... 32
Side Bearing Preload Adjustment ........................... 32
THRUST WASHER FOR ADJUSTMENT OF SIDE
GEAR BACK CLEARANCE .................................... 32
DRIVE PINION GEAR PRELOAD ADJUSTING
SHIM ....................................................................... 32
ADJUSTING SHIM FOR SIDE BEARING PRE-
LOAD ...................................................................... 33
Page 2892 of 4555

RFD-2
PRECAUTIONS
PRECAUTIONSPFP:00001
Service Notice or PrecautionsEDS001YY
Check for the correct installation status prior to removal or disassembly. If matching marks are required,
be certain they do not interfere with the function of the parts when applied.
Overhaul should be done in a clean work area, it is preferable to work in dustproof area.
Before disassembly, using steam or white gasoline, completely remove sand and mud from the exterior of
the unit, preventing them from entering into the unit during disassembly or assembly.
Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them
with a new ones if necessary.
Gaskets, seals and O-rings should be replaced any time when the unit is disassembled.
In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
tightening sequence is specified, observe it.
Clean and flush the parts sufficiently and blow-dry them.
Be careful not to damage sliding surfaces and mating surfaces.
When applying sealant, remove the old sealant from the mounting surface; then remove any moisture, oil,
and foreign materials from the application and mounting surfaces.
Always use shop paper for cleaning the inside of components.
Avoid using cotton gloves or shop rags to prevent entering of lint.
During assembly, observe the specified tightening torque, and apply new differential oil, petroleum jelly, or
multi-purpose grease as specified for each vehicle, if necessary.
Page 2893 of 4555
PREPARATION
RFD-3
C
E
F
G
H
I
J
K
L
MA
B
RFD
PREPARATIONPFP:00002
Special Service ToolsEDS002VE
Tool number
Tool nameDescription
ST27861000
Drift
a: 62 mm (2.44 in) dia.
b: 52 mm (2.05 in) dia.Installing final drive front oil seal
KV38100200
Drift
a: 65 mm (2.56 in) dia.
b: 49 mm (1.93 in) dia.
Installing final drive front oil seal
Installing final drive side oil seal
ST3127S000
Preload gaugeMeasuring preload torque
ST33052000
Drift
a: 22 mm (0.87 in) dia.
b: 28 mm (1.10 in) dia.Removing side bearing inner race
ST33230000
Drift
a: 51 mm (2.01 in) dia.
b: 41 mm (1.61 in) dia.
c: 28.5 mm (1.122 in) dia.Installing pinion front bearing outer race
ST23860000
Drift
a: 38 mm (1.50 in) dia.
b: 33 mm (1.30 in) dia.
Installing pinion rear bearing inner race
Installing pinion front bearing inner race
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Installing center oil seal
ZZA0832D
ZZA1143D
ZZA0503D
ZZA1023D
ZZA1046D
ZZA0534D
ZZA0814D
Page 2894 of 4555
RFD-4
PREPARATION
Commercial Service ToolsEDS002VF
ST22360002
Drift
a: 29 mm (1.14 in) dia.
b: 23 mm (0.91 in) dia.
c: 150 mm (5.91 in)Installing coupling front bearing
KV389L0010
Dummy cover set
Checking backlash
Checking drive gear runout
Checking tooth contact
KV38108500
Drive pinion socket
Measuring preload torque
Removing and installing drive pinion nut
KV38108400
Pinion nut wrench
Measuring preload torque
Removing drive pinion nut Tool number
Tool nameDescription
ZZA0546D
PDIA0894E
ZZA1205D
ZZA1206D
Tool nameDescription
Flange wrench Removing and installing companion flange
lock nut
Drift
a: 54.5 mm (2.146 in) dia.Removing and installing carrier case and rear
cover (2 pieces are used)
Pin punch
a: 4.5 mm (0.177 in) dia.Removing and installing lock pin
NT771
PDIA0893E
NT410
Page 2895 of 4555
PREPARATION
RFD-5
C
E
F
G
H
I
J
K
L
MA
B
RFD
Drift
