Page 2313 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION AT-49 [EURO-OBD] D E F G H I J K L MA B AT 8. Touch “START”. 9. Perform driving test according to “DTC Confirmation Procedure” in “TROUBLE DIAGNOSIS

Page 2314 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-50 [EURO-OBD] ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION If “NG” appears on the screen, malfunction may exist. Go to “Diagnostic Procedure”. 11. Perform test drive to check gear shift feelin

Page 2315 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION AT-51 [EURO-OBD] D E F G H I J K L MA B AT DTC WORK SUPPORT MODE DTC work support item Description Check items (Possible cause) 1ST GR FNCTN P0731Following ite

Page 2316 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-52 [EURO-OBD] ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION Diagnostic Procedure Without CONSULT-IIECS004QN EURO-OBD SELF-DIAGNOSTIC PROCEDURE (WITH GST) Refer to EC-113, "Generic Scan Tool (GST) Functi

Page 2317 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION AT-53 [EURO-OBD] D E F G H I J K L MA B AT 3. JUDGEMENT PROCEDURE STEP 2 1. Move selector lever to 2 position. 2. Set overdrive control switch to ON position.

Page 2318 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-54 [EURO-OBD] ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION JUDGEMENT OF SELF-DIAGNOSIS CODE O/D OFF indicator lamp All judgement flickers are the same. All circuits that can be confirmed by self-diagno

Page 2319 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION AT-55 [EURO-OBD] D E F G H I J K L MA B AT 6th judgement flicker is longer than others. Overrun clutch solenoid valve circuit is short-circuited or discon- nec

Page 2320 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual AT-56 [EURO-OBD] ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION t1 = 2.5 seconds t2 = 2.0 seconds t3 = 1.0 second t4 = 1.0 second 10th judgement flicker is longer than others. Line pressure solenoid val
