Removal and Installation of NAVI Control UnitEKS00F3P
REMOVAL
1. Remove upper grove box. Refer to IP-11, "Removal and Installation" .
2. Remove screws (4) and remove NAVI control unit.
3. Remove screws (4) and remove bracket.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of GPS AntennaEKS00F3Q
REMOVAL
1. Remove cluster lid A. Refer to IP-11, "Removal and Installation" .
2. Remove screws (2) and remove GPS antenna.
INSTALLATION
Installation is the reverse order of removal.
SKIA9174E
SKIA9175E
PKIB9384E
Page 3450 of 4555
AV-108
NAVIGATION SYSTEM
Removal and Installation of GPS Antenna FeederEKS00F3R
REMOVAL
1. Remove combination meter. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove NAVI control unit. Refer to AV- 1 0 7 , "
Removal and Installation of NAVI Control Unit" .
3. Remove front passenger air bag module. Refer to SRS-35,
"Removal and Installation" .
4. Remove clips (2) and remove GPS antenna feeder.
INSTALLATION
Installation is the reverse order of removal.
PKIB9385E
PKIB9386E
Page 3451 of 4555
