FRONT FOG LAMP
LT-109
C
D
E
F
G
H
I
J
L
MA
B
LT
Wiring Diagram — F/FOG — EKS003DG
TKWA1535E
Page 4106 of 4555
LT-110
FRONT FOG LAMP
Aiming Adjustment EKS003DH
1. Set the distance between the screen and the center of the fog
lamp lens as shown at left.
2. Turn fog lamp switch ON.
3. Insert a phillips screwdriver into the access hole and engage the
tip of the screwdriver with the gear of the adjuster as shown at
left. The aiming adjuster can now be turned by turning the
screwdriver.
4. Adjust front fog lamps so that the top edge of the high intensity
zone is 100 mm (3.94 in) below the height of the fog lamp cen-
ters as shown at left.
When performing adjustment, if necessary, cover the head-
lamps and opposite fog lamp.
PKIB1672E
PKIA5558E
PKIB1673E
Page 4107 of 4555

FRONT FOG LAMP
LT-111
C
D
E
F
G
H
I
J
L
MA
B
LT
Bulb Replacement EKS003DI
1. Remove fog lamp. Refer to LT- 111 , "Removal and Installation" .
2. Turn the bulb socket counterclockwise and unlock it.
3. Remove the bulb from its socket.
4. Installation is the reverse order of removal.
CAUTION:
Never touch the glass of bulb directly by hand. Keep grease
and other oily matters away from it. Never touch bulb by
hand while it is lit or right after being turned off. Burning
may result.
Never leave bulb out of fog lamp housing for a long time because dust, moisture smoke, etc. May
affect the performance of fog lamp. When replacing bulb, be sure to replace it with new one.
Removal and Installation EKS003DJ
REMOVAL
1. Remove fender protector. Refer to EI-21, "FENDER PROTECTOR" .
2. Disconnect fog lamp connector.
3. Remove fog lamp mounting nuts from fog lamp bracket.
4. Pull out fog lamp from vehicle and disconnect connector.
INSTALLATION
Installation is the reverse order of removal.Front fog lamp : 12V - 55W (H11)
PKIA5559E
PKIA5560E
Fog lamp mounting bolt
: 5.5 N·m (0.56 kg-m, 49 in-lb)
Page 4108 of 4555

LT-112
REAR FOG LAMP
REAR FOG LAMPPFP:26550
System Description EKS00ESB
DESCRIPTION
Power is supplied at all times (without front fog lamp)
through 15A fuse (No. 41, located in fuse and fusible link box)
to lighting switch terminal 5,
through 10A fuse (No. 36, located in fuse and fusible link box)
to rear fog lamp relay terminal 3.
Power is supplied at all times (with front fog lamp)
through 10A fuse (No. 31, located in the fuse and fusible link box)
to lighting switch terminal 11,
through 10A fuse (No. 36, located in fuse and fusible link box)
to rear fog lamp relay terminal 3.
With the lighting switch in the 2ND position, power is supplied (without front fog lamp)
through lighting switch terminal 25
to fog lamp switch terminal 34.
With the lighting switch in the 2ND position, power is supplied (with front fog lamp)
through lighting switch terminal 12
to fog lamp switch terminal 32.
FOG LAMP OPERATION
The front and rear fog lamp switch is built into the combination switch. The lighting switch must be in the 1ST
or 2ND position for rear fog lamp operation.
With the fog lamp switch in the REAR FOG ON position, ground is supplied
through fog lamp switch terminal 33
to rear fog lamp relay terminal 2.
Ground is supplied
to rear fog lamp relay terminal 1
through grounds E24 and E50.
The rear fog lamp relay is energized and power is supplied
through rear fog lamp relay terminal 5
to rear fog lamp terminal 1, and
to combination meter terminal 13.
Ground is supplied
to rear fog lamp terminal 2
through grounds B8 and B18,
to combination meter terminal 64
through grounds M27 and M70.
With power and ground supplied, the rear fog lamps and REAR FOG indicator illuminate.
Page 4109 of 4555
REAR FOG LAMP
LT-113
C
D
E
F
G
H
I
J
L
MA
B
LT
Wiring Diagram — R/FOG —/Without Front Fog LampEKS003BV
TKWA1536E
Page 4110 of 4555
LT-114
REAR FOG LAMP
Wiring Diagram — R/FOG —/With Front Fog LampEKS003BW
TKWA1537E
Page 4111 of 4555
REAR FOG LAMP
LT-115
C
D
E
F
G
H
I
J
L
MA
B
LT
Bulb ReplacementEKS0015L
1. Remove rear fog lamp. Refer to LT- 11 5 , "Removal and Installa-
tion" .
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb.
4. Installation is the reverse order of removal.
Removal and InstallationEKS0015M
REMOVAL
1. Remove rear fog lamp mounting screws.
2. Take out rear fog lamp from bumper, then disconnect connector.
INSTALLATION
Installation is the reverse order of removal.Rear fog lamp : 12V - 21W
SKIA0052E
SKIA0090E
Rear fog lamp mounting screws
: 1.4 N·m (0.14 kg-m, 12 in-lb)
Page 4112 of 4555
LT-116
CLEARANCE LAMP/TAIL LAMP
CLEARANCE LAMP/TAIL LAMPPFP:26010
Bulb Replacement (Clearance Lamp)EKS001UR
Refer to LT- 2 0 , "Bulb Replacement of Headlamp and Clearance Lamp" in “HEADLAMP-XENON TYPE-” or
LT- 3 7 , "
Bulb Replacement of Headlamp and Clearance lamp" in “HEADLAMP-CONVENTIONAL TYPE-”.
Bulb Replacement (Tail lamp)EKS001US
Refer to LT- 11 9 , "Bulb Replacement" in “REAR COMBINATION LAMP”.
Removal and Installation of Clearance LampEKS001UT
Refer to LT- 2 1 , "Removal and Installation of Headlamp" in “HEADLAMP-XENON TYPE-” or LT- 3 8 , "Removal
and Installation of Headlamp" in “HEADLAMP-CONVENTIONAL TYPE-”.
Removal and Installation of Tail lampEKS001UU
Refer to LT- 11 9 , "Removal and Installation" in “REAR COMBINATION LAMP”.
