Page 3953 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual HEATER UNIT MTC-29 C D E F G H I K L MA B MTC Disassembly and AssemblyEJS001FA NOTE: This illustration is for RHD models. The layout for LHD models is symmetrically opposite. 1. Screw 2. Air mix doo

Page 3954 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual MTC-30 HEATER CORE HEATER COREPFP:27140 Removal and InstallationEJS004HF REMOVAL 1. Remove heater (& cooling) unit. Refer to MTC-27, "HEATER UNIT" . 2. Remove heater pipe support. 3. Remove mounting

Page 3955 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual MODE DOOR MTC-31 C D E F G H I K L MA B MTC MODE DOORPFP:27181 Control Linkage AdjustmentEJS001DA MODE DOOR CONTROL CABLE 1. Turn the mode control dial to VENT position. 2. Move side link by hand an

Page 3956 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual MTC-32 AIR MIX DOOR AIR MIX DOORPFP:27180 Control Linkage AdjustmentEJS001DB AIR MIX DOOR CONTROL CABLE 1. Turn the temperature control dial to full cold position. 2. Move air mix door lever by hand

Page 3957 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DUCTS AND GRILLES MTC-33 C D E F G H I K L MA B MTC DUCTS AND GRILLESPFP:27860 Removal and InstallationEJS004HH REMOVAL NOTE: This illustration is for RHD models. The layout for LHD models is symmet

Page 3958 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual MTC-34 DUCTS AND GRILLES Removal of Side Ventilator Grille 1. Remove instrument panel. Refer to IP-11, "Removal and Installation" . 2. Remove side ventilator ducts. Refer to MTC-34, " Removal of Def

Page 3959 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual DUCTS AND GRILLES MTC-35 C D E F G H I K L MA B MTC Removal of Adaptor 1. Remove heater (& cooling) unit. Refer to MTC-27, "HEATER UNIT" . 2. Remove mounting screw and clip. 3. Slide adaptor toward

Page 3960 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual MTC-36 DUCTS AND GRILLES Removal of Floor Duct 1. Remove the front seats. Refer to SE-24, "FRONT SEAT" . 2. Remove multi-box (Instrument center lower panel). Refer to IP-11, " Removal and Installati
