GI-50
TERMINOLOGY

Nonvolatile random access memory NVRAM ***
On board diagnostic system OBD system Self-diagnosis
Open loop OL Open loop
Oxidation catalyst OC Catalyst
Oxidation catalytic converter system OC system ***
Oxygen sensor O2S Exhaust gas sensor
Park position switch *** Park switch
Park/neutral position switch PNP switchPark/neutral switch
Inhibitor switch
Neutral position switch
Periodic trap oxidizer system PTOX system ***
Positive crankcase ventilation PCV Positive crankcase ventilation
Positive crankcase ventilation valve PCV valve PCV valve
Powertrain control module PCM ***
Programmable read only memory PROM ***
Pulsed secondary air injection control sole-
noid valvePAIRC solenoid valve AIV control solenoid valve
Pulsed secondary air injection system PAIR system Air induction valve (AIV) control
Pulsed secondary air injection valve PAIR valve Air induction valve
Random access memory RAM ***
Read only memory ROM ***
Scan tool ST ***
Secondary air injection pump AIR pump ***
Secondary air injection system AIR system ***
Sequential multiport fuel injection system SFI system Sequential fuel injection
Service reminder indicator SRI ***
Simultaneous multiport fuel injection sys-
tem*** Simultaneous fuel injection
Smoke puff limiter system SPL system ***
Supercharger SC ***
Supercharger bypass SCB ***
System readiness test SRT ***
Thermal vacuum valve TVV Thermal vacuum valve
Three way catalyst TWC Catalyst
Three way catalytic converter system TWC system ***
Three way + oxidation catalyst TWC + OC Catalyst
Three way + oxidation catalytic converter
systemTWC + OC system ***
Throttle body TBThrottle chamber
SPI body
Throttle body fuel injection system TBI system Fuel injection control
Throttle position TP Throttle position
Throttle position sensor TPS Throttle sensor
Throttle position switch TP switch Throttle switch
Torque converter clutch solenoid valve TCC solenoid valveLock-up cancel solenoid
Lock-up solenoid NEW TERMNEW ACRONYM /
ABBREVIATIONOLD TERM

EM-18
[QR]
INTAKE MANIFOLD

INTAKE MANIFOLDPFP:14003
Removal and Installation (QR20DE)EBS00KNC
REMOVAL
1. Release fuel pressure. Refer to EC-49, "FUEL PRESSURE RELEASE" (WITH EURO-OBD) or EC-562,
"FUEL PRESSURE RELEASE" (WITHOUT EURO-OBD).
2. Remove air cleaner case upper, mass air flow sensor and air duct assembly. Refer to EM-16, "
AIR
CLEANER AND AIR DUCT" .
3. Remove quick connector caps, and disconnect quick connectors
at engine side and vehicle side. Refer to EM-34, "
Removal and
Installation (QR20DE)" .
4. Remove electric throttle control actuator with the following procedure:
a. Disconnect harness connector.
1. Vacuum hose 2. Intake manifold 3. PCV hose
4. Bracket 5. Gasket 6. Electric throttle control actuator
7. Gasket 8. Intake manifold support 9. Gasket
10. Vacuum hose 11.EVAP canister purge volume con-
trol solenoid valve12. Vacuum hose
13. Bracket 14. Bracket
PBIC2172E
PBIC2175E

EM-20
[QR]
INTAKE MANIFOLD

Intake Manifold Support
Tighten mounting bolt from “A” to “B” in order as shown in the figure.
NOTE:
Tighten “A” in the figure together with electric throttle control actua-
tor. Refer to EM-20, "
Electric Throttle Control Actuator" for the tight-
ening procedure.
Electric Throttle Control Actuator

Tighten mounting bolts equally and diagonally in several steps
and in numerical order as shown in the figure.

Perform the “Throttle Valve Closed Position Learning” when har-
ness connector of electric throttle control actuator is discon-
nected. Refer to EC-47, "
Throttle Valve Closed Position
Learning" (WITH EURO-OBD) or EC-560, "Throttle Valve
Closed Position Learning" (WITHOUT EURO-OBD).

Perform the “Idle Air Volume Learning” and “Throttle Valve
Closed Position Learning” when electric throttle control actuator
is replaced. Refer to EC-47, "
Idle Air Volume Learning" (WITH
EURO-OBD) or EC-560, "
Idle Air Volume Learning" (WITHOUT
EURO-OBD).
INSPECTION AFTER INSTALLATION
Make sure there are no fuel leaks at connections with the following procedure:
1. Apply fuel pressure to fuel lines with turning ignition switch “ON” (with engine stopped). Then make sure
there are no fuel leaks at connections.
NOTE:
Use mirrors for checking on invisible points.
2. Start engine. With engine speed increased, make sure again there are no fuel leaks at connections.
CAUTION:
Do not touch engine immediately after stopped as engine becomes extremely hot.
PBIC2628E
EMJ1612D

INTAKE MANIFOLD
EM-21
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EM

Removal and Installation (QR25DE)EBS011TH
REMOVAL
1. Release fuel pressure. Refer to EC-49, "FUEL PRESSURE RELEASE" (WITH EURO-OBD) or EC-562,
"FUEL PRESSURE RELEASE" (WITHOUT EURO-OBD).
2. Remove air cleaner case upper, mass air flow sensor and air duct assembly. Refer to EM-16, "
AIR
CLEANER AND AIR DUCT" .
3. Remove quick connector caps, and disconnect quick connectors
at engine side and vehicle side. Refer to EM-39, "
Removal and
Installation (QR25DE)" .
4. Remove electric throttle control actuator with the following procedure:
1. Bracket 2. PCV hose 3. Intake manifold collector
4. Gasket 5. Electric throttle control actuator 6. Intake manifold rear support
7.EVAP canister purge volume control
solenoid valve8. Vacuum hose 9. Intake manifold
10. Vacuum reservoir tank 11. VIAS control solenoid valve 12. Vacuum hose
13. Bracket 14. Intake manifold support 15. Vacuum reservoir tank bracket
PBIC2174E
PBIC2175E

EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EC
A
EC

ENGINE CONTROL SYSTEM
QR (WITH EURO-OBD)
INDEX FOR DTC ...................................................... 19
Alphabetical Index .................................................. 19
DTC No. Index ....................................................... 21
PRECAUTIONS ........................................................ 24
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................ 24
On Board Diagnostic (OBD) System of Engine and
A/T .......................................................................... 24
Precaution .............................................................. 24
Wiring Diagrams and Trouble Diagnosis ................ 27
PREPARATION ......................................................... 28
Special Service Tools ............................................. 28
Commercial Service Tools ...................................... 29
ENGINE CONTROL SYSTEM .................................. 30
System Diagram ..................................................... 30
Vacuum Hose Drawing ........................................... 32
System Chart ......................................................... 34
Multiport Fuel Injection (MFI) System .................... 35
Electronic Ignition (EI) System ............................... 37
Air Conditioning Cut Control ................................... 38
Fuel Cut Control (at No Load and High Engine
Speed) .................................................................... 38
CAN Communication Unit ...................................... 39
BASIC SERVICE PROCEDURE .............................. 45
Idle Speed and Ignition Timing Check .................... 45
Accelerator Pedal Released Position Learning ...... 46
Throttle Valve Closed Position Learning ................ 47
Idle Air Volume Learning ........................................ 47
Fuel Pressure Check .............................................. 49
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 52
Introduction ............................................................ 52
Two Trip Detection Logic ........................................ 52
Emission-related Diagnostic Information ................ 53
NATS (Nissan Anti-theft System) ........................... 64
Malfunction Indicator (MI) ....................................... 64
OBD System Operation Chart ................................ 67
TROUBLE DIAGNOSIS ............................................ 73
Trouble Diagnosis Introduction ............................... 73DTC Inspection Priority Chart ................................. 77
Fail-Safe Chart ....................................................... 78
Basic Inspection ..................................................... 79
Symptom Matrix Chart ............................................ 84
Engine Control Component Parts Location ............ 88
Circuit Diagram ....................................................... 93
ECM Harness Connector Terminal Layout ............. 95
ECM Terminals and Reference Value ..................... 95
CONSULT-II Function (ENGINE) ..........................103
Generic Scan Tool (GST) Function .......................113
CONSULT-II Reference Value in Data Monitor Mode
.115
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................118
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .120
Description ............................................................120
Testing Condition ..................................................120
Inspection Procedure ............................................120
Diagnostic Procedure ...........................................121
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT .......................................................................124
Description ............................................................124
Diagnostic Procedure ...........................................124
POWER SUPPLY AND GROUND CIRCUIT ...........125
Wiring Diagram .....................................................125
Diagnostic Procedure ...........................................126
Component Inspection ..........................................132
Ground Inspection ................................................132
DTC U1000, U1001 CAN COMMUNICATION LINE .133
Description ............................................................133
On Board Diagnosis Logic ....................................133
DTC Confirmation Procedure ...............................133
Wiring Diagram .....................................................134
Diagnostic Procedure ...........................................135
DTC P0011 IVT CONTROL .....................................136
Description ............................................................136
CONSULT-II Reference Value in Data Monitor Mode
.136
On Board Diagnosis Logic ....................................137

EC-6 Wiring Diagram .....................................................515
Diagnostic Procedure ...........................................517
MI & DATA LINK CONNECTORS ...........................518
Wiring Diagram .....................................................518
EVAPORATIVE EMISSION SYSTEM .....................522
Description ............................................................522
Component Inspection ..........................................525
POSITIVE CRANKCASE VENTILATION ...............527
Description ............................................................527
Component Inspection ..........................................527
AUTOMATIC SPEED CONTROL DEVICE (ASCD) .529
System Description ...............................................529
Component Description ........................................530
SERVICE DATA AND SPECIFICATIONS (SDS) ....531
Fuel Pressure .......................................................531
Idle Speed and Ignition Timing .............................531
Calculated Load Value ..........................................531
Mass Air Flow Sensor ...........................................531
Intake Air Temperature Sensor .............................531
Engine Coolant Temperature Sensor ...................531
Heated Oxygen Sensor 1 Heater .........................531
Heated Oxygen sensor 2 Heater ..........................532
Crankshaft Position Sensor (POS) .......................532
Camshaft Position Sensor (PHASE) ....................532
Throttle Control Motor ...........................................532
Injector ..................................................................532
Fuel Pump ............................................................532
QR (WITHOUT EURO-OBD)
INDEX FOR DTC .....................................................533
Alphabetical Index ................................................533
DTC No. Index ......................................................535
PRECAUTIONS .......................................................537
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ...............................................................537
On Board Diagnostic (OBD) System of Engine ....537
Precaution ............................................................537
Wiring Diagrams and Trouble Diagnosis ..............540
PREPARATION .......................................................541
Special Service Tools ...........................................541
Commercial Service Tools ....................................542
ENGINE CONTROL SYSTEM ................................543
System Diagram ...................................................543
Vacuum Hose Drawing .........................................545
System Chart ........................................................547
Multiport Fuel Injection (MFI) System ...................548
Electronic Ignition (EI) System .............................550
Air Conditioning Cut Control .................................551
Fuel Cut Control (at No Load and High Engine
Speed) ..................................................................551
CAN Communication Unit .....................................552
BASIC SERVICE PROCEDURE .............................558
Idle Speed and Ignition Timing Check ..................558
Accelerator Pedal Released Position Learning ....559
Throttle Valve Closed Position Learning ...............560
Idle Air Volume Learning ......................................560
Fuel Pressure Check ............................................562ON BOARD DIAGNOSTIC (OBD) SYSTEM ...........565
Introduction ...........................................................565
Two Trip Detection Logic .......................................565
Emission-related Diagnostic Information ..............565
NATS (Nissan Anti-theft System) ..........................567
Malfunction Indicator (MI) .....................................568
TROUBLE DIAGNOSIS ..........................................572
Trouble Diagnosis Introduction .............................572
DTC Inspection Priority Chart ...............................576
Fail-Safe Chart ......................................................577
Basic Inspection ....................................................578
Symptom Matrix Chart ..........................................584
Engine Control Component Parts Location ...........588
Circuit Diagram .....................................................593
ECM Harness Connector Terminal Layout ............595
ECM Terminals and Reference Value ...................595
CONSULT-II Function (ENGINE) ..........................604
CONSULT-II Reference Value in Data Monitor Mode
.615
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................618
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .620
Description ............................................................620
Testing Condition ..................................................620
Inspection Procedure ............................................620
Diagnostic Procedure ............................................621
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT .......................................................................624
Description ............................................................624
Diagnostic Procedure ............................................624
POWER SUPPLY AND GROUND CIRCUIT ...........625
Wiring Diagram .....................................................625
Diagnostic Procedure ............................................626
Component Inspection ..........................................632
Ground Inspection .................................................632
DTC U1000, U1001 CAN COMMUNICATION LINE .633
Description ............................................................633
On Board Diagnosis Logic ....................................633
DTC Confirmation Procedure ................................633
Wiring Diagram .....................................................634
Diagnostic Procedure ............................................635
DTC P0011 IVT CONTROL .....................................636
Description ............................................................636
CONSULT-II Reference Value in Data Monitor Mode
.637
On Board Diagnosis Logic ....................................637
DTC Confirmation Procedure ................................637
Overall Function Check .........................................639
Wiring Diagram .....................................................640
Diagnostic Procedure ............................................641
Component Inspection ..........................................643
Removal and Installation .......................................643
DTC P0102, P0103 MAF SENSOR .........................644
Component Description ........................................644
CONSULT-II Reference Value in Data Monitor Mode
.644
On Board Diagnosis Logic ....................................644
DTC Confirmation Procedure ................................644
Wiring Diagram .....................................................646

EC-14 Wiring Diagram ....................................................1294
Diagnostic Procedure ..........................................1296
DTC P2147, P2148 FUEL INJECTOR CIRCUIT ...1297
Component Description .......................................1297
CONSULT-II Reference Value in Data Monitor Mode
1297
On Board Diagnosis Logic ...................................1297
DTC Confirmation Procedure ..............................1297
Wiring Diagram ....................................................1298
Diagnostic Procedure ..........................................1300
Component Inspection .........................................1301
Removal and Installation .....................................1302
DTC P2228, P2229 BARO SENSOR .....................1303
Description ...........................................................1303
On Board Diagnosis Logic ...................................1303
DTC Confirmation Procedure ..............................1303
Diagnostic Procedure ..........................................1304
GLOW CONTROL SYSTEM ..................................1305
Description ...........................................................1305
Wiring Diagram ....................................................1306
Diagnostic Procedure ..........................................1308
Component Inspection .........................................1312
Removal and Installation .....................................1312
BRAKE SWITCH ....................................................1313
Description ...........................................................1313
CONSULT-II Reference Value in Data Monitor Mode
1313
Wiring Diagram ....................................................1314
Diagnostic Procedure ..........................................1316
Component Inspection .........................................1320
PNP SWITCH .........................................................1322
Description ...........................................................1322
CONSULT-II Reference Value in Data Monitor Mode
1322
Wiring Diagram ....................................................1323
Diagnostic Procedure ..........................................1324
PSP SWITCH .........................................................1326
Component Description .......................................1326
CONSULT-II Reference Value in Data Monitor Mode
1326
Wiring Diagram ....................................................1327
Diagnostic Procedure ..........................................1328
Component Inspection .........................................1329
Removal and Installation .....................................1330
FUEL TRANSPORT PUMP ....................................1331
Description ...........................................................1331
Wiring Diagram ....................................................1332
Diagnostic Procedure ..........................................1334
Component Inspection .........................................1338
Removal and Installation .....................................1338
AUTOMATIC SPEED CONTROL DEVICE (ASCD) 1339
System Description ..............................................1339
Component Description .......................................1340
ASCD INDICATOR .................................................1341
Component Description .......................................1341
Wiring Diagram—LHD Models .............................1342
Wiring Diagram—RHD Models ............................1343
Diagnostic Procedure ..........................................1344START SIGNAL ......................................................1345
Wiring Diagram ....................................................1345
Diagnostic Procedure ...........................................1346
MI & DATA LINK CONNECTORS ..........................1348
Wiring Diagram ....................................................1348
SERVICE DATA AND SPECIFICATIONS (SDS) ...1350
General Specifications .........................................1350
Mass Air Flow Sensor ..........................................1350
Engine Coolant Temperature Sensor ...................1350
Fuel Rail Pressure Sensor ...................................1350
Glow Plug .............................................................1350
EGR Volume Control Valve ..................................1350
Crankshaft Position Sensor .................................1350
Camshaft Position Sensor ...................................1350
YD (WITHOUT EURO-OBD)
INDEX FOR DTC ....................................................1351
Alphabetical Index ................................................1351
DTC No. Index .....................................................1353
PRECAUTIONS ......................................................1355
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ..............................................................1355
On Board Diagnostic (OBD) System of Engine ...1355
Precautions ..........................................................1355
Wiring Diagrams and Trouble Diagnosis ..............1358
PREPARATION ......................................................1359
Special Service Tools ...........................................1359
Commercial Service Tools ...................................1359
ENGINE CONTROL SYSTEM ................................1360
System Diagram ..................................................1360
Vacuum Hose Drawing ........................................1361
System Chart .......................................................1362
Fuel Injection Control System ..............................1362
Fuel Injection Timing Control System ..................1364
Air Conditioning Cut Control ................................1364
Fuel Cut Control (At No Load & High Engine Speed) 1364
Crankcase Ventilation System .............................1365
CAN Communication ...........................................1365
BASIC SERVICE PROCEDURE ............................1370
Fuel Filter .............................................................1370
Fuel Pump Learning Value Clearing ....................1370
ON BOARD DIAGNOSTIC (OBD) SYSTEM ..........1372
DTC and MI Detection Logic ................................1372
Diagnostic Trouble Code (DTC) ...........................1372
Freeze Frame Data ..............................................1373
NATS (Nissan Anti-theft System) .........................1373
Malfunction Indicator (MI) ....................................1373
Relationship Between MI, DTC, CONSULT-II and
Driving Patterns ...................................................1376
TROUBLE DIAGNOSIS .........................................1378
Trouble Diagnosis Introduction ............................1378
DTC Inspection Priority Chart ..............................1381
Basic Inspection ...................................................1382
Symptom Matrix Chart .........................................1387
Engine Control Component Parts Location ..........1391
Circuit Diagram ....................................................1396
ECM Harness Connector Terminal Layout ...........1398

ENGINE CONTROL SYSTEM
EC-35
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Multiport Fuel Injection (MFI) SystemEBS010L9
INPUT/OUTPUT SIGNAL CHART
*1: This sensor is not used to control the engine system under normal conditions.
*2: This signal is sent to the ECM through CAN communication line.
*3: ECM determines the start signal status by the signals of engine speed and battery voltage.
SYSTEM DESCRIPTION
The amount of fuel injected from the fuel injector is determined by the ECM. The ECM controls the length of
time the valve remains open (injection pulse duration). The amount of fuel injected is a program value in the
ECM memory. The program value is preset by engine operating conditions. These conditions are determined
by input signals (for engine speed and intake air) from both the crankshaft position sensor and the mass air
flow sensor.
VARIOUS FUEL INJECTION INCREASE/DECREASE COMPENSATION
In addition, the amount of fuel injected is compensated to improve engine performance under various operat-
ing conditions as listed below.


During warm-up

When starting the engine

During acceleration

Hot-engine operation

When selector lever is changed from N to D (A/T models)

High-load, high-speed operation


During deceleration

During high engine speed operation
Sensor Input Signal to ECMECM
functionActuator
Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)Engine speed*
3 and piston position
Fuel injec-
tion & mix-
ture ratio
controlFuel injector Mass air flow sensor Amount of intake air
Engine coolant temperature sensor Engine coolant temperature
Heated oxygen sensor 1 Density of oxygen in exhaust gas
Throttle position sensor Throttle position
Accelerator pedal position sensor Accelerator pedal position
Park/neutral position (PNP) switch Gear position
Knock sensor Engine knocking condition
Battery
Battery voltage*
3
Power steering pressure sensor Power steering operation
Heated oxygen sensor 2*
1Density of oxygen in exhaust gas
Wheel sensor*
2Vehicle speed
Air conditioner switch Air conditioner operation
