LT-22
HEADLAMP - XENON TYPE -

3. Remove front turn signal lamps. Refer to LT- 9 4 , "Removal and
Installation of Front Turn Signal Lamp" .
4. Disconnect connector of headlamp and clearance lamp.
5. Remove front grille. Refer to EI-19, "
FRONT GRILLE" in
“EXTERIOR & INTERIOR (EI)” section.
6. Remove headlamp mounting bolts.
7. Pull headlamp forward the vehicle.
INSTALLATION
Installation is the reverse order of removal.
Disassembly and AssemblyEKS00N54
DISASSEMBLY
1. Turn plastic cap counterclockwise and unlock it.
2. Disconnect terminal connected to halogen bulb.
3. Turn xenon bulb socket counterclockwise and unlock it.
4. Unlock retaining spring, and then remove xenon bulb and halogen bulb.
5. Turn clearance bulb socket counterclockwise and unlock it.
6. Remove clearance bulb from clearance bulb socket.
7. Remove HID control unit mounting screws and remove HID control unit.
ASSEMBLY
Assembly is the reverse order of disassembly.
CAUTION:

When HID control unit is removed, reinstall it securely and avoid any looseness.

After installing bulb, be sure to install plastic cap and bulb socket securely to ensure watertight-
ness.
PKIA5555E
Headlamp mounting bolts
: 5.5 N·m (0.56 kg-m, 49 in-lb)
1. Xenon bulb socket 2. Xenon bulb 3. Halogen bulb
4. HID control unit 5. Screws 6. Plastic cap
7. Clearance lamp bulb socket 8. Clearance lamp bulb 9. Retaining springs
SKIA1466E
HID control unit mounting screws
: 3.2 N·m (0.33 kg-m, 28 in-lb)

LT-38
HEADLAMP - CONVENTIONAL TYPE -

3. Installation is the reverse of order removal.
CAUTION:

Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off. Burning may result.

When replacing bulb, prepare new bulb first of all. Never leave bulb out of headlamp housing for a
long period, because dust, moisture or smoke will cause performance lowering (fouling, cloud,
etc.) of headlamp reflector and lens.

When bulb is installed, be sure to lock rubber cap to ensure watertightness.
Bulb Replacement of Driving LampEKS00N5E
1. Remove the driving lamp. Refer to LT- 3 9 , "Removal and Installa-
tion of Driving Lamp" in “HEADLAMP”.
2. Disconnect driving lamp connector.
3. Turn bulb socket counterclockwise and unlock it.
4. Installation is the reverse order of removal.
CAUTION:

Never touch the glass of bulb directly by hand. Keep
grease and other oily matters away from it. Never touch
bulb by hand while it is lit or right after being turned off.
Burning may result.

When replacing bulb, prepare new bulb first of all. Never leave bulb out of driving lamp housing
for a long period, because dust, moisture or smoke will cause performance lowering (fouling,
cloud, etc.) of driving lamp reflector and lens.
Removal and Installation of HeadlampEKS00N5F
REMOVAL
1. Remove the front turn signal lamps. Refer toLT- 9 4 , "Removal
and Installation of Front Turn Signal Lamp" .
2. Disconnect headlamp and clearance lamp connector.
3. Remove the front grille. Refer to EI-19, "
FRONT GRILLE" in
“EXTERIOR & INTERIOR (EI)” section.
4. Remove the headlamp mounting bolts.
5. Pull the headlamp forward the vehicle.
INSTALLATION
Installation is the reverse order of removal.Clearance lamp : 12V - 5W
Driving lamp : 12 V - 65 W (H1R1)
PKIA3396E
PKIA5555E
Headlamp mounting bolts
: 5.5 N·m (0.56 kg-m, 49 in-lb)

TURN SIGNAL AND HAZARD WARNING LAMPS
LT-93
C
D
E
F
G
H
I
J
L
MA
B
LT

Trouble Diagnoses EKS003BG
Electrical Components InspectionEKS0034C
COMBINATION FLASHER UNIT CHECK

Before checking, ensure that bulbs meet specifications.

Connect a battery and test lamp to the combination flasher unit,
as shown. Combination flasher unit is properly functioning if it
blinks when power is supplied to the circuit.
Symptom Possible cause Repair order
Turn signal and hazard warning lamps do
not operate.1. Hazard switch
2. Combination flasher unit
3. Open in combination flasher unit circuit1. Check hazard switch.
2. Refer to combination flasher unit check.
3. Check wiring to combination flasher unit
for open circuit.
Turn signal lamps do not operate but haz-
ard warning lamps operate.1. 10A fuse
2. Hazard switch
3. Turn signal switch
4. Open in turn signal switch circuit1. Check 10A fuse [No. 2, located in fuse
block (J/B)]. Turn ignition switch ON and
verify battery positive voltage is present
at terminal 2 of hazard switch.
2. Check hazard switch.
3. Check turn signal switch.
4. Check the wire between combination
flasher unit terminal 3 and turn signal
switch terminal 1 for open circuit.
Hazard warning lamps do not operate but
turn signal lamps operate.1. 10A fuse
2. Hazard switch
3. Open in hazard switch circuit1. Check 10A fuse (No. 35, located in the
fuse and fusible link box). Verify battery
positive voltage is present at terminal 3
of hazard switch.
2. Check hazard switch.
3. Check the wire between combination
flasher unit terminal 3 and hazard switch
terminal 4 for open circuit.
Front turn signal lamp LH or RH does not
operate.1. Bulb
2. Grounds E24 and E501. Check bulb.
2. Check grounds E24 and E50.
Rear turn signal lamp LH or RH does not
operate.1. Bulb
2. Grounds B8 and B181. Check bulb.
2. Check grounds B8 and B18.
Side turn signal lamp LH or RH does not
operate.1. Bulb
2. Grounds E24 and E501. Check bulb.
2. Check grounds E24 and E50.
LH and RH turn indicators do not operate. 1. Ground 1. Check grounds M27 and M70.
LH or RH turn indicator does not operate. 1. Bulb 1. Check bulb in combination meter.
PKIC0929E

LT-94
TURN SIGNAL AND HAZARD WARNING LAMPS

Bulb ReplacementEKS0034D
FRONT TURN SIGNAL LAMP
1. Remove the front turn signal lamp. Refer to LT- 9 4 , "Removal
and Installation of Front Turn Signal Lamp"
2. Turn the bulb socket counterclockwise and unlock it.
3. Remove the bulb from its socket.
4. Installation is the reverse order of removal.
SIDE TURN SIGNAL LAMP
1. Remove side turn signal lamp. Refer to LT- 9 5 , "Removal and
Installation of Side Turn Signal Lamp"
2. Turn the bulb socket counterclockwise and unlock it.
3. Remove the bulb from its socket.
4. Installation is the reverse order of removal.
REAR TURN SIGNAL LAMP
Refer to LT- 11 9 , "Bulb Replacement" in “REAR COMBINATION LAMP”.
Removal and Installation of Front Turn Signal LampEKS003BH
REMOVAL
1. Press the upper pawl to remove front turn signal lamp forward
the front of the vehicle.
2. Disconnect front turn signal lamp connector.
INSTALLATION
1. Connect front turn signal lamp connector.
2. Insert the pawl into head lamp hole, and install front turn signal lamp.Front turn signal lamp : 12V - 21W (amber)
SKIA0053E
Side turn signal lamp : 12V - 5W
PKIA0468E
SKIA0054E

REAR COMBINATION LAMP
LT-119
C
D
E
F
G
H
I
J
L
MA
B
LT

Bulb ReplacementEKS00164
1. Remove rear combination lamp mounting bolts.
2. Pull rear combination lamp toward rear of vehicle. Disengage
locating pins.
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb.
5. Installation is the reverse order of removal.
Removal and InstallationEKS00165
REMOVAL
1. Remove luggage-side lower finisher. Refer to EI-35, "BODY
SIDE TRIM" in “EI EXTERIOR & INTERIOR” section.
2. Disconnect rear combination lamp connector.
3. Remove rear combination lamp mounting bolts.
4. Pull rear combination lamp rearward the vehicle. Disengage
locating pins.
5. Pull harness grommet and remove harness.
INSTALLATION
Installation is the reverse order of removal.Stop/tail lamp : 12V - 21/5W
Rear turn signal lamp : 12V - 21W
Back-up lamp : 12V - 21W
PKIC0923E
PKIA8620E
Rear combination lamp mounting bolts
: 5.4 N·m (0.55 kg-m, 48 in-lb)

LT-152
BULB SPECIFICATIONS

BULB SPECIFICATIONSPFP:26297
HeadlampEKS003GS
Exterior LampEKS003GT
Interior Lamp/IlluminationEKS003GU
Item Wattage (W)
Xenon typeLow 35 (D2R)
High 55 (H1)
Conventional type High/Low 60/55 (H4)
Driving lamp65 (H1R1)
Item Wattage (W)
Front combination lamp Clearance lamp 5
Front turn signal lamp21 (amber)
Side turn signal lamp5
Fog lampFront fog lamp 55 (H11)
Rear fog lamp 21
Rear combination lampStop/Tail lamp 21/5
Rear turn signal lamp 21
Back-up lamp 21
License plate lamp5
High-mounted stop lamp5
Item Wattage (W)
Interior room lamp10
Map lampWithout sunroof 8
With sunroof 10
Luggage room lamp10
Ste p lamp2.7
Ashtray illumination lamp1.4
